2 Port Mini DisplayPort KVM Switch with USB
2.0 and KVM Cables
SV231MDPU2
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 01/21/2016
*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com SV231MDPU2
Summary of Contents for StarTech.com SV231MDPU2
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 01/21/2016...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Product Diagram ..................1 Front View ..............................1 Rear View ..............................1 Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Installation ....................3 Hardware Installation ..........................3 Software Installation ..........................4 Switch between computers ........................4 Operation ....................5 Switching between systems........................ -
Page 4: Product Diagram
Product Diagram Front View USB keyboard, PC select button mouse, and hub ports Rear View PC and server KVM Console monitor connections connection Instruction Manual... -
Page 5: Introduction
• DisplayPort display (monitor, projector, TV, etc.) • DisplayPort output and an available USB port per computer • USB keyboard and mouse • A video source and display that support 4K at 60 Hz Note: The SV231MDPU2 KVM switch supports DisplayPort 1.2. Instruction Manual... -
Page 6: Installation
Installation Hardware Installation 1. Connect a DisplayPort monitor into the DP OUT connector on the back of the KVM switch. 2. Connect a USB keyboard and mouse into the USB ports on the front of the KVM switch. 3. Connect the included DisplayPort USB KVM cables to each PC, and then to the PC1 and PC2 ports on the back of the KVM switch. -
Page 7: Software Installation
PCs by using the select button on the front of the KVM switch or by using hotkeys. 1. Open a browser and navigate to www.startech.com/Downloads. 2. In the Enter Product ID field, enter SV231MDPU2 and download the software. Instruction Manual... -
Page 8: Operation
3. Browse to the location where you saved the file and run the Setup.exe (Windows) or USB KVM.dmg (Mac OS) application. 4. Follow the on-screen instructions to complete the installation. Operation Switching between systems To switch between your connected systems, do any of the following: •... -
Page 9: Specifications
Specifications Number of KVM Ports PC Video Type DisplayPort 1.2 PC Interface Audio Support DisplayPort Audio 1 x Mini DisplayPort (20 pin) Female Console Connectors 3 x USB A (4 pin) Female Host Connectors 1 x Mini DisplayPort (20 pin) Female (per port) 1 x USB B (4 pin) Female LEDs... -
Page 10: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 11 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
