Page 1: Configuration Guide
Tiptel 31XX IP Phone Configuration Guide Version 2.0 Date: September 28, 2015 Yeastar Information Technology Co. Ltd. - Page 2 Tiptel 31XX IP Phone Configuration Guide Contents 1. Introduction ......................3 2. Register with MyPBX Manually ................4 3. Configuring BLF on Tiptel ................... 7 4. Auto Provisioning ....................8 2/10...
-
Page 3: Introduction
1. Introduction This guide shows you how to manually configure Tiptel IP phones with MyPBX and how to provision the Tiptel IP phones with MyPBX. It has been tested with the latest firmware version supported by MyPBX firmware version X.19.0.47. -
Page 4: Register With Mypbx Manually
Tiptel 31XX IP Phone Configuration Guide 2. Register with MyPBX Manually Start up the phone and identify its IP address-press the OK key on the phone to get the Information. For this example the IP address of the phone is 192.168.5.126, and IP address of MyPBX is 192.168.5.150. - Page 5 Tiptel 31XX IP Phone Configuration Guide Figure 1-2 1) Set the "Active" field to "Enabled". 2) Set the "Label" field to the name you want to appear on the Phone display. 3) Set the "Display Name" field to the name you want to appear on another phone's display when calling other phones.
- Page 6 Tiptel 31XX IP Phone Configuration Guide Next, we need to configure the audio codecs. Click on the "Account/Codec" tab. Ensure that the "Enable codecs" list box contains first "G722", then "PCMU", and finally "PCMA". Click the "Confirm" button at the bottom of the page.
-
Page 7: Configuring Blf On Tiptel
Please choose the correct “Account” which is registered to MyPBX, or it will not work. You can also manually configure the Tiptel 31xx Memory Keys to monitor the status of other extensions or trunks on the system. 1) Click on the "Keys" tab, and then select the keys you want to configure (DSS Keys or EXT Keys at optional extension module). -
Page 8: Auto Provisioning
Tiptel 31XX IP Phone Configuration Guide 4. Auto Provisioning The easiest way to set up a Tiptel 31xx phone for MyPBX is to use the built-in plug and play provisioning functionality inside MyPBX. This will allow the phone to configure itself by retrieving a generated phone configuration file. -
Page 9: Figure
Step3. Search the MAC address you would like configure on the “Phone Provisioning” ”Not Configured Phone” page. Figure 3-3 In this case, the MAC address of Tiptel 31xx IP phone is 000cc4300000. Figure 3-4 Fill in the phone detail message on the pop-up window. Input Name, Call waiting, Line, Extension, Label, Line active and so on for the phone. -
Page 10: Figure
Click "OK" to reboot the IP phone and provisioning the phone. Figure 3-6 Then IP phone will reboot to apply the configurations. When done, you can find the account 500 is registered in MyPBX’s line status page and Tiptel 31xx IP phone’s status page. <END>...
