Back Panel

Figure 2 shows the back panel of the PA-2000 Series and Table 2 describes the back panel
features.
AC power
Inlet
Figure 2. Back Panel
Table 2. Back Panel Features
Item
Hard disk drive tray
Power panel
Palo Alto Networks
Power
switch
Description
Removable hard disk drive tray.
Switch for powering the device and AC power inlet.
Removable
hard drive tray
Back Panel
Overview • 7
