PaloAlto Networks PA-200 Quick Start

Performing the Final Setup
CONFIGURING THE SECURITY POLICY
Click Policies > Security.
1
Review the default policies, which allow all traffic to flow from the trust zone to the
2
untrust zone while inspecting for viruses, vulnerability, and spyware. In addition, the
default policies deny the flow of traffic from the untrust zone to the trust zone.
DEPLOYING THE DEVICE AND VERIFYING THE NETWORK AND SECURITY
CONFIGURATION
Connect port 1 to the Internet.
3
Connect port 2 to your local network.
4
From a computer on your local network other than the computer you are using
5
to configure the PA-200 device, try to connect to the Internet to validate proper
connectivity.
CONFIGURING THE MANAGEMENT INTERFACE
Click Device > Setup. Click the Edit button of the first table (top right).
6
Enter the new MGT interface information for accessing the enterprise management
7
network. Click OK. Click Commit.
Disconnect your computer from the PA-200 device.
8
Connect the MGT port on the device to the enterprise management network.
9
VERIFYING THE MANAGEMENT CONFIGURATION
Connect your computer to the enterprise management network.
10
Open a browser window and type https://<MGT_port_IP_Address>.
11
Log in to the web interface of the PA-200 device.
12
Where to Go Next
•
To learn about device administration, refer to the Palo Alto Networks Administrator's
Guide.
•
To learn about the CLI, refer to the PAN-OS
•
To obtain a detailed description of the LEDs on a PA-200 device, refer to the
PA-200 Hardware Reference Guide.
Copyright ©2011-2017 Palo Alto Networks. All rights reserved.
Palo Alto Networks and PAN-OS are trademarks of Palo Alto Networks, Inc.
Part Number 810-000072-00B
Command Line Interface Reference Guide.
™
www.paloaltonetworks.com
Before You Begin
•
Register your PA-200 device at http://support.paloaltonetworks.com to obtain the
latest software and App-ID updates, and to activate support or subscriptions.
•
Obtain an IP address from your network administrator for configuring the
management port on the PA-200 device.
•
Have an RJ-45 Ethernet cable to connect your computer to the management port on
the PA-200 device.
•
Set your computer's IP address to 192.168.1.2 and the subnet mask to 255.255.255.0.
NOTE: This card assumes the device has been properly rack-mounted and powered up as
described in the PA-200 Hardware Reference Guide.
Performing the Initial Setup
Connect your computer to the management port (MGT) using an RJ-45 Ethernet cable.
1
Turn your computer on.
2
Launch the Internet browser on your computer and enter https://192.168.1.1.
3
The login page of the PA-200 management console appears.
Type admin in both the Name and Password fields.
4
Click Login.
5
Click Device > Administrators > admin.
6
Type the old password in the Old Password field.
7
Type the new password in the New Password field.
8
Type the new password again in the Confirm New Password field.
9
Click OK.
10
11 Proceed to the next section to choose a deployment option.
PA-200
Quick Start
