Circuit Diagram; Installation - Simadre CT5200D Owner's Manual

NOTE: This circuit diagram is provided only for informational purposes.
ONLY a qualified technician approved by Simadre TECHS LLC should

INSTALLATION

To set up your new CT5200D/DX, you will need certain additional components that
typically are not supplied with the machine:

CIRCUIT DIAGRAM

perform repairs to the CT5200/DX 3-in-1 System.
 Argon tank (needed for TIG welding)
 Argon flow regulator with a 1/4" barb connector
 air compressor (needed for plasma cutting)
 air regulator (40 to 60 PSI)
 air dryer on compressed air line
 air hose for compressed air
 adaptor connector from the air hose to a 1/4" barb
 electrical plug (male) for 110V or 220V
 Optional foot pedal
