2.3 Removal of
Procedure
disassembling work.
Step
1. Remove the shelter.
Undo the five hooks
1
and remove the shelter.
2. Remove the PCB.
Disconnect the ground
1
wire.
156
PCB and Electrical Box
Warning Be sure to turn off all power supplies at least 10 min. before
Procedure
SiBE04-302
Points
The shelter has five hooks.
Be sure to avoid forgetting to
restore the shelter and to
avoid loosing or damaging it.
Removal Procedure
