Page 1: Technical Data
technical data RYS-B Pair Application Split Sky Air... - Page 2 Daikin Europe N.V. is participating Daikin Europe N.V. is approved by LRQA for its Quality in the EUROVENT Certification Programme. Management System in accordance with the ISO9001 Products are as listed in the EUROVENT standard.
-
Page 3: Table Of Contents
• Pair Application • R-410A • RYS20,25,35,50,60BVMB TABLE OF CONTENTS RYS-B Features ................. Specifications . -
Page 4: Features
• Pair Application • R-410A • RYS20,25,35,50,60BVMB Features Outdoor units for pair application + Daikin outdoor units can be mounted easily on a roof or terrace or simply placed against an outside wall. • Split - Sky Air • Outdoor Units... -
Page 5: Specifications
• Pair Application • R-410A • RYS20,25,35,50,60BVMB Specifications TECHNICAL SPECIFICATIONS OUTDOOR UNITS RYS20BVMB RYS25BVMB RYS35BVMB RYS50BVMB RYS60BVMB DIMENSIONS Unit WEIGHT Unit COLOUR Unit Ivory white SOUND LEVEL Sound pressure (1) (cooling) H/L dBA 47/* 49/* (heating) H/L dBA 48/* 49/*... -
Page 6: Electrical Specifications
• Pair Application • R-410A • RYS20,25,35,50,60BVMB Specifications ELECTRICAL SPECIFICATIONS OUTDOOR UNITS RYS20BVMB RYS25BVMB RYS35BVMB RYS50BVMB RYS60BVMB CURRENT Nominal running current cooling/heating A 3.22/3.92 4.32/4.82 5.82/6.72 7.12/7.32 9.12/9.02 Max. running current cooling/heating A Please refer to electrical data Starting current... -
Page 7: Electrical Data
• Pair Application • R-410A • RYS20,25,35,50,60BVMB Specifications ELECTRICAL DATA RYS+FTYS20B Power supply Compressor Indoor unit Outdoor unit Hz-Volts Voltage range MAX. 50Hz 253V FTYS20BVMB RYS20BVMB 50-230 13.0 2.91 0.35 0.20 MIN. 50Hz 207V 3D040467 RYS+FTYS25B Power supply Compressor Indoor unit... -
Page 8: Capacity Tables
• Pair Application • R-410A • RYS20,25,35,50,60BVMB Capacity tables RYS+FTYS20B 0.30 Cooling capacity 230V [50Hz] Indoor Outdoor temperature (°C) (°C) (°C) 14.0 1.86 1.36 0.52 1.80 1.31 0.58 1.74 1.27 0.64 1. 71 1.25 0.65 1.67 1.22 0.66 1.60 1.17 0.71 16.0 2.01... - Page 9 • Pair Application • R-410A • RYS20,25,35,50,60BVMB Capacity tables RYS+FTYS35B 0.17 Cooling capacity 230V [50Hz] Indoor Outdoor temperature (°C) (°C) (°C) 14.0 3.21 2.19 0.77 3.06 2.12 0.87 2.91 2.05 0.96 2.85 2.02 1.00 2.76 1.98 1.06 2.61 1.91 1.15 16.0 3.37 2.22...
- Page 10 • Pair Application • R-410A • RYS20,25,35,50,60BVMB Capacity tables RYS+FTYS60B 16.4 0.29 Cooling capacity 230V [50Hz] Indoor Outdoor temperature (°C) (°C) (°C) 14.0 6.06 3.97 1.77 5.91 3.90 1.87 5.76 3.83 1.96 5.70 3.80 2.00 5.61 3.76 2.06 5.46 3.69 2.15 16.0 6.22...
-
Page 11: Dimensional Drawings
• Pair Application • R-410A • RYS20,25,35,50,60BVMB Dimensional drawings unit (mm) RYS20,25,35B 4 x holes for anchor bolts (M8 or M10) Minimum space for air passage Wall height on air outlet side = less than 1200 Drain outlet (I.D. J 15.9 hose for connection) Name plate Terminal strip with earth Outdoor air thermistor... -
Page 12: Operation Range
• Pair Application • R-410A • RYS20,25,35,50,60BVMB Operation range RYS20,25,35B Cooling Heating Indoor temp. (°CWB) Indoor temp. (°CDB) Notes: The graphs are based on the following conditions: + Equivalent piping length 7.5 m + Level difference + Air flow rate high 3D039535 RYS50,60B... -
Page 13: Piping Diagrams
• Pair Application • R-410A • RYS20,25,35,50,60BVMB Piping diagrams RYS20,25B Outdoor unit Heat exchanger Outdoor temperature thermistor Heat exchanger thermistor Motor operated valve Capillary tube 1 Muffler with Filter Capillary tube 2 filter Propeller fan Liquid receiver with filter Muffler with filter Field piping Four way valve on:... - Page 14 • Pair Application • R-410A • RYS20,25,35,50,60BVMB Piping diagrams RYS50 Outdoor unit Heat exchanger Outdoor temperature thermistor Capillary tube 1 Refrigerant flow Muffler with filter Cooling Heat exchanger thermistor Capillary tube 2 Heating Capillary tube 3 Propeller fan Filter Four way valve on : heating Motor operated valve Muffler with...
-
Page 15: Wiring Diagrams
• Pair Application • R-410A • RYS20,25,35,50,60BVMB Wiring diagrams RYS20,25,35 Indoor Field wiring : Protective earth Outdoor C9, C11 (outdoor) (discharge) C12∼C15 : Capacitor : Current transformer (Condenser) DB1, DB2 : Diode bridge F1U, F2U : Fuse R1T, R2T, R3T, R4T : Thermistor : Live S10, S11, S20, S45... -
Page 16: Sound Level
• Pair Application • R-410A • RYS20,25,35,50,60BVMB Sound level Sound level data Cooling only: Sound pressure level 230V, 50Hz Sound power level Model Cooling/Heating Measuring location (Cooling/Heating) RYS20B 47/48 60/* RYS25B 47/48 60/* RYS35B 47/48 60/* RYS50B 47/48 63/64 RYS60B 49/49 64/64 * This information was not available at the time of publication. -
Page 17: Sound Level Data
• Pair Application • R-410A • RYS20,25,35,50,60BVMB Sound level Sound pressure spectrum RYS50B (Cooling) RYS50B (Heating) approximate approximate threshold hearing for threshold hearing continuous noise for continuous noise Legend 3D027645F 3D027645F Octave band center frequency (Hz) Octave band center frequency (Hz) 50/60Hz, 220-240/220-230V RYS60B (Cooling) RYS60B (Heating) -
Page 18: Accessories
Standard accessories RYS-B Accessories supplied with the outdoor unit: (B) Drain plug (Heat pump models) (A) Installation manual There is on the bottom packing case. Optional accessories RYS-B RYS20BVMB RYS25BVMB RYS35BVMB RYS50BVMB RYS60BVMB Air direction adjustment grille KPW937A4 KPW945A4 • Split - Sky Air • Outdoor Units... -
Page 19: Installation
