  • Page 1 A SS EMB LY M AN UAL Manual en Español Latino Americano: www.support.nautilus.com...

  • Page 2: Table Of Contents

    | outside U.S. technics@nautilus.com | Printed in China | © 2008 Nautilus, Inc. | ® indicates trademarks registered in the United States. These marks may be registered in other nations or otherwise protected by common law. Bowflex, the B logo, Bowflex Xtreme, Nautilus, Schwinn, and...

  • Page 3: Important Safety Instructions - Assembly

    When attaching two pieces, gently lift and look through the bolt holes to help guide the bolt through the holes. • As a general rule, and for all bolts and nuts on your Bowflex Xtreme 2 SE home gym, turn bolts or nuts toward the ®...

  • Page 4: Parts

    Parts IMporTANT: LEAvE ALL CABLES CoILEd ANd wrAppEd UNTIL YoUr BowfLEx xTrEME 2 SE HoME GYM IS fULLY ASSEMBLEd. ® Note: Cables are not shown for clarity. Assembly Manual...
  • Page 5 Parts / Tools Item Description Item Description Base Frame Assembly Lock Knob Rod Pack 210# Seat Backbone Assembly Lower Lat Tower Seat Bottom Seat Support Rail Ab Crunch Crossbar Squat Frame Left Ab Crunch Bracket Squat Frame Right Pulley, Pair Floating Squat Platform Lat Double Pulley / Housing Pulley Slider, 4”...

  • Page 6: Hardware

    Hardware (NOTE: Drawings not to scale.) Item Description Item Description Flat Washer 1/4” Regular Button Head Screw 5/16” X 2 1/2” Flat Washer 3/8” Regular Button Head Screw 5/16” X 3/4” Flat Washer 1/2” Wide Threaded Stud 1/2” X 9 1/2” Flat Washer 1/2”...

  • Page 7: Assembly

    Assembly 1. Install power rod pack to Lower Lat Tower Assembly ® parts: • Lower Lat Tower (3) • Rod Box with Power Rod Pack (2) ® Hardware: • 3 Phillips Screws #10 X 1” (F) • 3 Flat Washers 1/4”(A) Tool: Phillips Screw Driver Lay parts on floor as shown.
  • Page 8 3. Install Seat Support rail parts: • Seat Support Rail (4) • Base Frame Assembly Hardware: • 2 Button Head Screws 3/8” X 3/4” (I) • 2 Flat Washers 3/8” (B) Tool: 7/32” Hex Wrench Slide the bottom of the Seat Support Rail onto the Base Frame connector as shown.

  • Page 9: Install Squat Pulley Frame

    4. Install Squat pulley frame parts: • Left Squat Pulley Frame (5) • Right Squat Pulley Frame (6) • Main Assembly • 2 Slider Pulleys w/o Decal (8) • Squat Platform (7) Hardware: • 1 Button Head Screw 3/8" X 5" (H) •...

  • Page 10: Install Pulley Arms/Slider Pulleys

    5. Install pulley Arms parts: • Right Pulley Arm (12) • Left Pulley Arm (13) • Main Assembly Hardware: • 2 Threaded Studs 1/2" X 9 1/2" (M) • 4 Nylock Nuts 1/2" (N) • 4 Washers 1/2" (D) Tools: 7/32"...

  • Page 11: Seat Assembly

    7. Seat Assembly parts: • Seat Backbone (17) • Seat Bottom (18) Hardware: • 4 Button Head Screws 5/16" X 3/4" (L) • 4 Washers 5/16" (E) Tool: 3/16" Hex Wrench Install the Seat Backbone to the underside of the Seat Pad using screws and washers as shown.
  • Page 12 9. Install Leg Extension Assembly parts: • Leg Extension Assembly • Lock Knob (16) • Seat Assembly Insert Leg Extension Backbone into open end of Seat Backbone as shown. Align one hole of the Leg Extension with the hole in the Seat Backbone to fit your height and secure with the Lock Knob as shown.
  • Page 13 11. Install Seat Assembly parts: • Seat Assembly • Seat Locking Pin (P) • Main Assembly 11-1 Align the top two hooks on the Seat Backbone (17) with one of the pairs of pins on the Seat Support Rail (4), as shown in Detail 11a.
  • Page 14 12. Upper Lat Tower Assembly parts: • Upper Lat Tower (11) • Lat Cross Bar (10) • Rear Lat Crossmember (9) Hardware: • 2 Button Head Screws 3/8" X 3" (G) • 4 Washers 3/8" (B) • 2 Nylock Nuts 3/8” (O) •...

  • Page 15: Install Upper Lat Tower Assembly

    14. Install Upper Lat Tower Assembly, Ab Crunch Station and Lat pulley parts: • Upper Lat Tower Assembly Figure 14a • Ab Crunch Station • Lat Pulley Housing (22) • Main Assembly Hardware: • 5 Button Head Screws 3/8" X 3/4" (I) •...

  • Page 16: Cable And Pulley Routing

    15. Cable and pulley routing – overview The figure below shows all Pulleys on the Bowflex Xtreme 2 SE home gym. Subsequent images show how to connect and route each of the Cables through the Pulleys. (The Ab Crunch Station is not shown for clarity.) Connecting the Cables is much easier with a second person assisting you.

  • Page 17: Prepare Cables To Lat Pulley Housing

    16. Cable and pulley routing – prepare Cables to be installed to the Lat pulley Housing Locate the following items on the Lat Pulley Housing assembly: • (2) Pulleys – already installed, labeled as item 2 in figure • 3/8” X 4 1/2” Hex Head Bolt – installed •...
  • Page 18 17. Cable and pulley routing – Connect pulleys and Cables to the Lat pulley Housing Locate the following items for the Lat Pulley Housing assembly: • (2) Pulleys from step 16 • 3/8” X 4 1/2” Hex Head Bolt – uninstalled in Step 16 •...
  • Page 19 18. Cable and pulley routing – Connect rod Cables through the right floating and Lat Tower pulleys Locate the following items for the Lat Pulley Housing assembly: • 3 & 8 Floating Pulleys (connected unit) • (2) Cable End Stop Balls with Core (see Detail) 18-1 Locate the Right Rod Cable that you ran through the Lat Pulley Housing.

  • Page 20: Cable End Stop Ball With Core

    18b. Cable and pulley routing – Connect Cable End Stop Ball with Core Figure 18b - Detail 18c. Cable and pulley routing – Connect rod Figure 18c Cables through Left (3) floating and Lat Tower pulleys 18-4 Repeat with Left Rod Cable and (3) and (8) Floating Pulleys, as shown in Figure 18c.

  • Page 21: Connect Right Squat Cable

    19. Cable and pulley routing – Connect right Squat Cable through the floating and Main Assembly pulleys Slide the Right Squat Frame Pulley (6) to the furthest back hole, as indicated in Figure 19. Unwrap the Right Squat Cable from the (6) Pulley and guide the Cable, threading under and through the Rear Cross Bar Pulley (7), and up through the Floating (8) Pulley.
  • Page 22 19b. Cable and pulley routing – Connect Left Squat Cable through the floating and Main Assembly pulleys Repeat the same procedure completed during Step 19 for the Left Squat Cable. Assembly Manual...

  • Page 23: Final Inspection

    20. Cable & pulley routing Attach the hooks on the ends of the Left and Right Squat Cables to the Hook installed onto the Leg Extension, as shown in Figure 20. 21. final Inspection Inspect your machine to ensure that all fasteners are tight and components are properly assembled. Review all warnings affixed to machine.
