The new KatanaS 50E ARF was designed by Italy aerobatic pilot,
Sebastiano Silvestri and the design is based on of his successful
and famous KatanaS Tournament Of Champion's airplane.
This professional ARTF kit is the result of Sebastiano's long
research in 3D performance. This combined with an extremely
lightweight structure, the all wood airframe and the big control
surfaces give the KatanaS 50E an impressive thrust-to-weight
ratio and crisp control authority at any airspeed and flight
condition....That for this small class of airplane is revolutionary!
The KatanaS 50E can do it all...unbelievable easy harriers, torque
rolls, blenders, waterfalls and almost anything else you can dream
up are waiting you!
.....the only aerobatic limit is your fantasy!
Specifications
Wing Span:...................
Length:.........................
Wing Area:..................
Weight:...
2.250 g. RTF less battery (79,36 oz)
Radio:.....4-Channel with 4 standard servos
KatanaS
ASSEMBLY MANUAL
146 cm (57,84 in.)
146 cm (57,84 in.)
49 dm2 (75,95 sq.in.)
professional line
ARF
Recommended power set up:
Motor:...........................
ESC:.........................
Battery:
FlightPower 3300-5S or 3700-5S
Propeller: ...........
50E
Hacker A50-14S
X70 SBec-Pro
APC 16x8E or 16x10E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KatanaS 50E and is the answer not in the manual?

Questions and answers

Related Manuals for Sebart KatanaS 50E

Summary of Contents for Sebart KatanaS 50E

  • Page 1 KatanaS ASSEMBLY MANUAL The new KatanaS 50E ARF was designed by Italy aerobatic pilot, Sebastiano Silvestri and the design is based on of his successful and famous KatanaS Tournament Of Champion’s airplane. This professional ARTF kit is the result of Sebastiano’s long research in 3D performance.

  • Page 2: Table Of Contents

    Table of contents Table of contents.......................……….. 2 Required radio, motor and battery.....................…. 3 Additional required items, tools and adhesives................3 Warning............................3 Before starting assembly ......................… 3 Using the manual........................... 4 Warranty information…......................... 4 Section 1 – wing fillet installation…....................5 Section 2 –...

  • Page 3: Required Radio, Motor And Battery

    Before starting assembly Before starting the assebly of your KatanaS 50E, remove each part from its bag and protection for a prior inspection. Closely inspect the fuselage, wing panels, rudder, and stabilizer for damage. If you find any damage or missing parts, contact the place of purchase.

  • Page 4: Using The Manual

    Rember to take your time and follow the directions. Warranty information SebArt garantees this kit to be free from defects in both material and workmanship at the date of purchase. This warranty does not cover any parts damage by use or modification, and in no case shall SebArt’s liability exceed the original cost of the purchased kit.

  • Page 5: Section 1 - Wing Fillet Installation

    Section 1 – wing fillet installation step 1 Locate the carbon tube and the wing to the fuselage. Locate the corresponding wing fillet to the wing. Test fit the fillet and his alignment with the wing panel and fuselage. Once satisfied with the fit, glue the wing fillet to the wing panel using medium CA.
  • Page 6 step 2 Carefully glue, with some drops of thin CA, each of the four hinges in the aileron. step 3 Locate the aileron and carefully glue, with some drops of thin CA, each of the four hinges into the wing panel. step 4 Work the aileron up and down some times to work the hinges and check for proper movement.

  • Page 7: Section 3 - Aileron Servo & Control Horn Installation

    Section 3 – aileron servo & control horn installation step 1 Locate the following items included in the hardware pack and the servo (the servo is not included). step 2 Install the servo hardware (gommets and eyelets) and put the servo into the wing panel, as per pictures.

  • Page 8: Section 4 - Rudder Installation & Tail Wheel Installation

    step 4 Install the hardware and make the final adjustment as per picture. step 5 Repeat steps 1 through 4 for the remaining wing panel. Section 4 – rudder installation & tail wheel installation step 1 Test fit the rudder into the fuselage, check for a correct alignment and glue it with medium CA. step 2 Insert the three hinges in their appropriate slots and glue them with some drops of thin CA.
  • Page 9 step 3 Drill in the rudder, 20mm from the bottom, the location for the tail wheel using a 2mm drill bit. Than locate the items included in the hardware pack, and assemble them as per picture. step 4 With the hobby knife cut a groove of 20mm length into the rudder. Carefully put some drops of medium CA into the 2 mm hole and right after put in his rudder location the tail wheel.

  • Page 10: Section 5 - Elevator Installation

    Section 5 – elevator installation step 1 Insert in the elevator the four hinges into their appropriate slots and verify the correct position and alignment of the elevator with the stabilizer. Than carefully glue the hinges, with some drops of thin CA, in the elevator only.
  • Page 11 step 4 Glue carefully the hinges in the stabiliser with some drops of thin CA. step 5 Locate the carbon tube in his position and carefully check the alignment of the stabilizer with the fuselage, as per pictures. step 6 Once satisfied with the alignment, glue carefully with thin CA the stabilizer at the fuselage.

  • Page 12: Section 6 - Elevator Servo & Control Horn Installation

    Section 6 – elevator servo & control horn installation step 1 Locate the following items included in the hardware pack, servo extension 300mm long and servo (servo and extension are not included). step 2 With the hobby knife open the servo bay in the fuselage. Than install the servo hardware (gommets and eyelets) and install the servos into the fuselage using a Phillips screwdriver.

  • Page 13: Section 7 - Rudder Servo & Control Horn Installation

    Section 7 – rudder servo & control horn installation step 1 Locate the following items included in the hardware pack, servo extension 300mm long and servo. step 2 With the hobby knife open the servo bay in the fuselage. Than install the servo hardware (gommets and eyelets) and install the servos into the fuselage using a Phillips screwdriver.

  • Page 14: Section 8 - Landing Gear & Wheels Installation

    Section 8 – landing gear & wheels installation step 1 Locate the following items included in the hardware pack. step 2 Locate the landing gear on the fuselage and fix it with the screws included in the hardware pack. step 3 Sand with the sanding paper the inside of the wheel pant;...
  • Page 15 step 4 Install wheel and wheel pant as per pictures. step 5 Drill the location for the wheel pant fixing screw using a 1,5mm drill bit and than fix the wheel pant with the screw included in the hardware pack. step 6 Glue carefully the landing gear fillet with some drops of medium CA, as per picture.

  • Page 16: Section 9 - Electric Motor Installation

    step 7 Repeat steps 3 to 6 for the other side of the landing gear and than install the tail wheel. Section 9 – electric motor installation For best performance, we recommend to use HACKER motor. step 1...
  • Page 17 Locate the engine mount on the fuselage and glue it carefully with medium CA, than fix it using the four screws included in the hardware pack. step 2 Locate the motor and fix it with the four screws included in the motor hardware pack. step 3 Fix the controller in the area shown in the picture.

  • Page 18: Section 10 - Glow Engine Installation (Option)

    If you want to install a glow engine, you need the hardware pack and the reinforcement wood parts set, that is available as optional. Visit the website www.sebart.it for price and for download the manual instructions for this special application.
  • Page 19 step 2 Slide the cowling onto the fuselage and install the spinner back plate. Position and hold the cowl so there is 3mm gap between the back plate and the cowl. Then apply another piece of masking tape on the same line of the one applied before. step 3 Drill the location for the four self-tapping screws using a 1.5mm drill bit.

  • Page 20: Section 12 - Final Radio Installation

    Section 12 – final radio installation step 1 Glue with some drops of medium CA on side of the Velcro strip included in the hardware pack. step 2 With the hobby knife open the cooling holes in the fuselage as per picture. step 3 Install the receiver, two extension 100mm for aileron servos and the battery pack as per the picture.

  • Page 21: Wings Installation

    Wings installation Locate the wing panels and fix them using the two nylon screws, included in the hardware pack, and a Phillips screwdriver. Decal set application...

  • Page 22: Control Throws

    Control throws Please, follow carefully the recommended linkage setups for ailerons and elevators. For the AILERON we recommend the following throws: Low rate: 20° up / 20° down Expo: 40% 3D rate: 45° up / 45° down Expo: 80% For the ELEVATOR we recommend the following throws: Low rate: 20°...

  • Page 23: Recommended Cg

    Finally... Finally... Finally... Finally... have a nice flight! have a nice flight! have a nice have a nice flight! flight! SebArt di Sebastiano Silvestri Via Roma 83/85 38017 Mezzolombardo (TN) – Italy www.sebart.it...
