  • Page 3: Document Revision History

    No part of this publication may be reproduced, transmitted, translated in any from by any means without the written permission of Koden Electronics Co., Ltd. The technical descriptions contained in this publication are subject to change without notice. Koden assumes no responsibility for any errors, incidentals or consequential damages caused by misinterpretation of the descriptions contained in this publication.

  • Page 4: Important Notices

    Important Notices MDC-2000 Series Important Notices  The re-use and transcription of Operation Manual (hereafter called this manual) needs permission of our company. Our company prohibits the un-authorized re-use and transcription.  If this manual is lost or damaged, consult our dealer or our company.

  • Page 5: For Your Safe Operation

    MDC-2000 Series For Your Safe Operation For Your Safe Operation Symbol used in this Operation Manual This manual uses the following symbols. Understand the meaning of each symbol and implement the maintenance and inspection. Symbol Meaning Mark for warning This symbol denotes that there is a risk of death or serious injury when not dealing with it correctly.
  • Page 6 For Your Safe Operation MDC-2000 Series Caution Item on Equipment Caution on a high voltage inside. A high voltage, which may risk your life, is used. This high voltage remains in the circuit after you have powered off switch. To prevent...
  • Page 7 MDC-2000 Series For Your Safe Operation Caution Item on Handling Caution on the rotating aerial The radar antenna may start to rotate without notice. Please stand clear from the antenna for your safety. Caution on electromagnetic disturbance The operating Antenna & Scanner unit radiates high-energy electromagnetic wave.
  • Page 8 For Your Safe Operation MDC-2000 Series Do not disassemble or modify. It may lead to trouble, fire, smoking or electric shock. In case of trouble, contact our dealer or our company. In case of smoke or fire, switch off the power in the boat and the power of equipment.

  • Page 9: Table Of Contents

    MDC-2000 Series Contents Contents Document Revision History ....... i 1.12 Measuring the distance and Important Notices ........ii bearing between two points ..1-10 For Your Safe Operation ......iii Measuring the distance and Contents ..........vii bearing between two points ..1-10 Introduction ..........

  • Page 10: Contents

    Information Display ....2-13 NMEA ......... 3-7 Types and Meanings of ATA KGC-1 Setting (Connection with Symbols ........2-14 the KODEN GPS compass) ..3-7 Preset ......... 3-7 Chapter 3 How to use the system F1/F2 Key Set ......3-7 menu ........3-1 Select Range S/M/L ....
  • Page 11 MDC-2000 Series Contents Maintenance ......3-8 Cable connection to the Display Display Unit ........ 3-8 unit ........... 5-14 Antenna ........3-8 Pin Assignment of Rear Panel Test ........3-8 Connector ........ 5-15 LCD Test ........3-8 Connection of DC power Operation Hours Reset ....

  • Page 12: Introduction

    MDC-2000 Series Introduction Thank for your purchase of KODEN color LCD marine radar MDC-2000 Series. The quality and endurance of a unit is well considered. For the best performance, read this Operation Manual and operate a unit correctly and safely.

  • Page 13: System Configuration

    MDC-2000 Series System Configuration System Configuration Connection Diagram Antenna-Scanner unit RB715A/ RB716A/ RB717A/ RB718A MRD-104 Display unit With mounting bracket and hard cover External Monitor Navigation equipment External Buzzer KGC-1 or AIS Receiver Navigation equipment CCD camera Slave Display MRD-XXX *Be sure to connect the KGC-1 to J5 Power 10.8 to 31.2VDC...

  • Page 14: Configuration Of Equipment

    Configuration of Equipment MDC-2000 Series Configuration of Equipment Standard Equipment Configuration List Weight/ Name of item Type Remarks Quantity Length Display unit With mounting MRD-104 8.1 kg bracket and knobs Hard cover A30MB10250 390 g DC power cable 3-pin water...
  • Page 15 MDC-2000 Series Configuration of Equipment Types of Antenna-Scanner unit Transmitting Type Shape Remarks Weight/Length Power RB715A Radome Interconnecting 10kg / 2ft cable, 10m*, 242J158055A-10M RB716A with RW701A-03/04 Open Interconnecting 21kg / 3ft cable, 10m*, 242J159098A-10M 22kg / 4ft RB717A with RW701A-04/06...
  • Page 16 Configuration of Equipment MDC-2000 Series Optional List Item Name Type Remarks Cable Length GPS compass KGC-1 GPS/Heading measuring AIS interface board AIS-110 200 targets Cable for AIS receiver CW-387-5M 8-pin water resistant connector and one end plain ATA board MRE-340 Cable for external CW-576-0.5M...

  • Page 17: Chapter 1 Basic Operation

    Chapter 1 Basic Operation MDC-2000 Series Chapter 1 Basic Operation The basic operation of this unit is as follows. For detailed explanation, refer to each item in this manual. BRILL Press the [ ] to turn When [ST'BY] appears, press...
  • Page 18 MDC-2000 Series Chapter 1 Basic Operation Change the observation range with the [- RANGE +] key. When pressing the [+] key, the observation range expands. When pressing the [-] key, the enlarged surrounding around own ship can be observed. To make it easier to observe the range you desire, change the range.

  • Page 19: How To Read The Radar Screen

    Chapter 1 Basic Operation MDC-2000 Series How to read the radar screen Process Enhance Heading Range F2 key content Alarm Ship Off center Fixed marker interval F1 key content Trail speed Display mode Pulse width Interference Rejection Crosshair cursor Cursor position...

  • Page 20: How To Use The Keys

    MDC-2000 Series Chapter 1 Basic Operation How to use the keys (10) Various adjustment items can be set by operating each key. The menu is displayed by pressing the [MENU] key, and closes when pressing the [MENU] key again. 0093120005-02...
  • Page 21 Chapter 1 Basic Operation MDC-2000 Series Number Key name Explanation [F1]* Recalls directly the preset menu item. [ENT] * Press: measures bearing of distance between two points. Continuously pressing: Deletes the heading line. The crosshair cursor moves to the own ship’s position.

  • Page 22: Power On/Off

    MDC-2000 Series Chapter 1 Basic Operation Power On/Off Brilliance Adjustment BRILL The [ ] key is used for both the power on/off Brightness Adjustment of LCD and the change of brilliance of the LCD & panel. The brilliance of menu can be adjusted to make it easier to see.

  • Page 23: Switch-Over Of Range

    Chapter 1 Basic Operation MDC-2000 Series Switch-over of Range Result picture after adjustment by [GAIN] knob Result picture after adjustment by [GAIN] knob Land The observation range can be changed. Own ship Change of Range Press the [- RANGE +] key.

  • Page 24: Stc Adjustment

    MDC-2000 Series Chapter 1 Basic Operation In the PPI/PPI menu, when rotating the [STC] STC Adjustment knob, the STC functions effective in both displays. In the short distance menu, even if waves are low and the sea surface is calm, an echo...

  • Page 25: 1.10 Delete Of Heading Line

    Chapter 1 Basic Operation MDC-2000 Series Trail Time When pressing the [F1] / [F2] key, the Other Ship** When pressing the [F1] / [F2] key, the trail time changes. information of a target aligned with the crosshair cursor is displayed in the The On/Off display of EBL is toggled window.

  • Page 26: Measuring The Distance And Bearing Between Two Points

    MDC-2000 Series Chapter 1 Basic Operation 1.13 Camera Display The video of a CCD camera can be displayed on the radar screen. (CCD camera: Prepared by a customer) crosshair cursor How to connect a CCD camera Connect CW-405-0.3M cable (optional cursor position cable) to the J6 in the rear connectors.

  • Page 27: Chapter 2 How To Use The Menu

    Chapter 2 How to use the menu MDC-2000 Series Chapter 2 How to use the menu How to operate the menu Select an item you desire to change with the [ ] and [ ] keys. Display/Non-display of Menu ECHO...

  • Page 28: Ftc Adjustment

    MDC-2000 Series Chapter 2 How to use the menu FTC Adjustment Setting of Display Mode When raining or snowing, due to reflection from In the display mode, the bearing and the target rain or snow, an object is hard to be seen.

  • Page 29: N Up (North Up)

    Chapter 2 How to use the menu MDC-2000 Series N UP (North Up) WPT UP (Waypoint Up) The N UP is the display mode to orient the true The WPT is the display mode to always orient north to the top of the screen.
  • Page 30 MDC-2000 Series Chapter 2 How to use the menu Relative motion (RM): The own ship is fixed True motion (TM): Your ship moves and other surrounding targets move according to its speed and tidal on the screen. current on the screen.

  • Page 31: True Motion Reset

    Chapter 2 How to use the menu MDC-2000 Series True Motion Reset PPI Display When your ship exits from movable range of your The radar screen is displayed on the entire ship’s position, it moves to the opposite side display.

  • Page 32: Note On Ppi/Ppi Display

    MDC-2000 Series Chapter 2 How to use the menu Press the [MENU] key to close the menu. Note on PPI/PPI Display ● The movable range is limited. In the PPI/PPI display, to avoid risk, the following (See the movable range shown below.) functions do not work.

  • Page 33: Setting Of Pulse Width

    Chapter 2 How to use the menu MDC-2000 Series Setting of Pulse Width Relative Display (R) The relative speed of a target with respect of own The short pulse width is suitable for target ship is displayed as a trail.

  • Page 34: True Display (T)

    MDC-2000 Series Chapter 2 How to use the menu 2.10 EBL True Display (T) Irrespective of the motion of own ship, trails This mode is used when measuring the bearing representing the course and speed of moving from own ship to a target.

  • Page 35: 2.12 Display Color

    Chapter 2 How to use the menu MDC-2000 Series Setup: OFF, ONE SIDE, BOTH SIDES (Initial 2.12 Display Color value: OFF) Press the [MENU] key. When the display is hard to see due to the environment, changing the color of the display Select [DISPLAY] →...

  • Page 36: 2.17 Alarm

    MDC-2000 Series Chapter 2 How to use the menu shows the positions of own ship and other ships Change the distance direction with the [ ] after one minute. and [ ] keys and the bearing with the [ ] and [ ] keys.

  • Page 37: Operation During Executing The Sleep

    Chapter 2 How to use the menu MDC-2000 Series Press the [MENU] key. Operation during executing the sleep Select [AIS] → [INFO]. During executing the sleep, the transmitting for 30 seconds is repeated at the interval of the set Change the setting with the [ ] and [ ] time.

  • Page 38: 2.20 Ata

    MDC-2000 Series Chapter 2 How to use the menu Warning Warning The accuracy of the data provided The accuracy of the auto tracking by the AIS could be affected by the function provided by the ATA could following factors: be affected by the following factors:...

  • Page 39: Manual Acquisition

    Chapter 2 How to use the menu MDC-2000 Series Press the [ENT] key. Then, the acquisition of Manual Acquisition the designated target is released. Direct to acquire a target by designating a target When releasing acquisition of several on the display.

  • Page 40: Types And Meanings Of Ata

    MDC-2000 Series Chapter 2 How to use the menu Types and Meanings of ATA Symbols In the ATA, the symbols are displayed, overlaying on acquire-started targets. Normal Symbol Meanings Displayed when setting the acquisition. Displayed when in the stable tracking state.

  • Page 41: Chapter 3 How To Use The System Menu

    Chapter 3 How to use the system menu MDC-2000 Series Chapter 3 How to use the system menu Display of System Menu Setting of Assist Items There is a standard menu which is displayed for In the supplement items of the system menu, to...

  • Page 42: Wpt Display

    MDC-2000 Series Chapter 3 How to use the system menu WPT Display N UP/S UP Select ON or OFF of the WPT icon (flag mark) to Change the mode of the N UP or S UP of the be displayed on the radar screen.

  • Page 43: Bearing Setting

    Chapter 3 How to use the system menu MDC-2000 Series displayed on the screen. Bearing Setting Adjust the bearing of the radar image on the screen. Setup: -180.0 to +180.0 (Initial value: 0.0) Press the [STBY/TX] key to start the transmission.

  • Page 44: Stc Curve

    MDC-2000 Series Chapter 3 How to use the system menu range that can display the entire sea surface reflected echo can be displayed. Adjust the [STC] knob and stop it just before the sea surface reflected echo completely disappears (In the state that the sea surface reflected echo is sparsely displayed.) As...

  • Page 45: Tune Select

    Chapter 3 How to use the system menu MDC-2000 Series The STC curve set value is applied to all Manual Tune Adjustment ranges. Due to a sudden environment change, the Note: The setting of STC characteristics automatic tuning may be detuned. In this case, needs to be performed in the ocean.

  • Page 46: Interference Rejection

    MDC-2000 Series Chapter 3 How to use the system menu Change the setting of [Pulse Width Press the [MENU] key. Adjustment] with the [ ] and [ ] keys. Move to the system menu. Refer to 3.1 Display of System Menu.

  • Page 47: Nmea

    Chapter 3 How to use the system menu MDC-2000 Series NMEA Preset In the NMEA item of the system menu, the In the Preset of the system menu, the radar is transmission speed of the external input/output customized. can be changed.

  • Page 48: Maintenance

    MDC-2000 Series Chapter 3 How to use the system menu Maintenance The self-diagnosis of the system menu is the menu for maintenance. Normally, it is not used. Perform the self-diagnosis of the Display unit and the antenna. Display Unit The state of the Display unit is displayed.

  • Page 49: Chapter 4 Maintenance

    Chapter 4 Maintenance MDC-2000 Series Chapter 4 Maintenance 4.1 Maintenance To operate the radar equipment in a good condition for a long period of time, perform the inspection and cleaning periodically. 4.1.1 Monthly Inspection Caution: Do not turn on the power of the radar during inspection.

  • Page 50: 4.1.2 Yearly Inspection

    MDC-2000 Series Chapter 4 Maintenance 4.1.2 Yearly Inspection In case of Open antenna (RB716A, RB717A, RB718A), check the brush of the antenna drive motor inspect every 2,000 hours of transmission. If the length is shorter than 6mm, replace it with a new one.

  • Page 51: Fuse Replacement

    Chapter 4 Maintenance MDC-2000 Series Fuse Replacement WARNING Use the specified fuse. If a fuse other than the specified one is used, it leads to a serious accident. If the input voltage is too high, hyper-current flows or a trouble occurs inside, the fuse blows out.

  • Page 52: Self-Diagnostic Function

    MDC-2000 Series Chapter 4 Maintenance Error Content Error Display Causes The latitude and longitude is not entered. L/L NO SIGNAL The bearing signal is not entered. HDG NO SIGNAL The ship speed signal is not inputted. SPD NO SIGNAL The trigger signal is not inputted from the antenna.

  • Page 53: Inspection At Each Location

    Chapter 4 Maintenance MDC-2000 Series 4.4.4 Inspection at Each Location After finishing the inspection by the self-diagnosis, according to the table, check each location of the radar. Trouble conditions Suspected causes of troubles Countermeasures The radar cannot be The power cable is not connected.

  • Page 54: Chapter 5 Equipment

    MDC-2000 Series Chapter 5 Installation Chapter 5 Equipment Antenna Installation Determining the location of the installation The search capability of the radar varies largely, depending on the position of the antenna installation. The ideal installation position is the high place over the keel line where no obstacle surrounds. Actually, though there are many limitations in a ship, determine the installation position, considering the following items.

  • Page 55: How To Shift The Antenna From An Obstacle

    Chapter 5 Installation MDC-2000 Series How to shift the antenna from an obstacle 1. How to shift the antenna from the keel line By shifting the antenna from keel line to the starboard, the blind moves to the port and the visibility in the heading can be secured.

  • Page 56: Installation Of Antenna

    MDC-2000 Series Chapter 5 Installation Installation of Antenna After determining the location of the installation, install the antenna. When installing, if the bracket shown below is available, the installation is easier. If not available, install the antenna directly on the roof, paying attention to the air tube for drain at the bottom of the antenna.

  • Page 57: Setting Of Open Antenna

    Chapter 5 Installation MDC-2000 Series Chassis Radome (bottom) Bracket Flat washer Spring washer Accessory M10 hexagon bolt Install with four bolts Specification of bracket thickness-wise installation bolt (In case of Radome Antenna) Thickness of bracket Bolt for fixing the antenna...

  • Page 58: Installation Of Antenna

    Remove the protective cap covered on the output of the Scanner unit rotational shaft. Remove four bolts tentatively fixed to the base of the Antenna and install the Scanner unit to the rotating base. Match the direction of antenna radiation side (KODEN –mark side) with the projection mark on the rotating base.
  • Page 59 Chapter 5 Installation MDC-2000 Series Antenna radiatyion side (KODEN –mark side) Remove Antenna Protective cap Rotating base Projection mark Rotating base Flat washer Spring washer Installation bolt 0093120005-02...

  • Page 60: Cable Connection

    MDC-2000 Series Chapter 5 Installation Cable Connection Radome Antenna 4kW (RB715A) Confirm that the power of the Scanner unit is turned off. Install the antenna cable to the connector J7 at the rear of the Display unit. Remove the upper radome of the Scanner unit, lifting upward not to touch the aerial inside.
  • Page 61 Chapter 5 Installation MDC-2000 Series Open Antenna 4kW (RB716A) Please make sure power supply of the Scanner unit is OFF. Disassemble the front cover of the Scanner unit from the rear cover by loosening fixing bolts. Remove the TR unit by disconnecting the connector X1 and X2 after loosening fixing bolts of the TR unit.
  • Page 62 MDC-2000 Series Chapter 5 Installation Open Antenna 6kW (RB717A), 12kW (RB718A) Make sure power supply of the Scanner unit is OFF. Disassemble the front cover of the Scanner unit from the rear cover by loosening fixing bolts. Remove the TR unit by disconnecting the connector J3 and J4 after loosening fixing bolts of the TR unit.

  • Page 63: Mutual Connection Diagram

    Chapter 5 Installation MDC-2000 Series Mutual Connection Diagram Antenna Display unit RB715A/RB716A:X11, RB717A/RB718A:J2 Remark Color of lead wire Color of lead wire Remark +250 V VIOLET VIOLET +250 V BLUE +24V YELLOW ORANGE (wide cable) +12V +40V RED (wide cable)

  • Page 64: Display Unit Installation

    MDC-2000 Series Chapter 5 Installation Display Unit Installation The Display unit can be installed on the desktop or as flash mount. Please install the Display unit to the following procedure. In addition, please install the Display unit securing safety distance from the magnetic compass.

  • Page 65: Flush-Mount Installation

    Chapter 5 Equipment MDC-2000 Series Caution: When installing on the desktop, the maintenance space shown in the illustration below is required for cable lay-out, plugging-in/out of connector, fuse replacement and bolt tightening. Unit: mm (inch) Flush-mount Installation (1) Make a square hole (308mm x 308mm) at the location to be installed.

  • Page 66: Adjustment After Installation

    MDC-2000 Series Chapter 5 Equipment Fixing holes for M4 screw (4pcs) Unit: mm (inch) Work of fiush-mount instsllation hole Adjustment after Installation Before setup, confirm the following points to operate properly the equipment The ship’s power, to which the radar system is connected, should be the specified voltage.

  • Page 67: Wiring

    Chapter 5 Equipment MDC-2000 Series Wiring Cable connection to the Display unit Connect the power cable, antenna cable and cables of others to specified connectors of the Display unit. If optional navigation equipment and CCD camera are provided, connect also the cables of these equipments.
  • Page 68 MDC-2000 Series Chapter 5 Equipment Pin Assignment of Rear Connector The pin assignment is viewed from the rear of the Display unit. External monitor/External buzzer AIS Input Slave display NMEA/IEC61162 Input/Output +12V (Maximum 0.8A) can be supplied for GPS-20A, etc.

  • Page 69: Connection Of Dc Power Cable

    Chapter 5 Equipment MDC-2000 Series Connection of DC power cable (CW-259-2M) DC+(White) DC- (Black) To [POWER] port To [POWER] connector GND (Gray) Grounding ● Use the large diameter cable for ground wire as possible. ● Connect the ground wire to the ground material at a shortest distance.

  • Page 70: Connection With The Ais

    Two NMEA0183/IEC61162 input/output ports are provided. Connect the navigation equipment and the external equipment such as KODEN made GPS sensor to them. The optional cable with connectors at both ends is available. The CW-376-5M of which one end is left untreated is also available. Prepare a cable suitable for the equipment you desire to connect.

  • Page 71: List Of Input/Output Sentence

    Chapter 5 Equipment MDC-2000 Series (NTSC/PAL/SECAM), Connect the video output terminal (RCA plug (In most cases, yellow)) of your CCD camera. Perform the waterproof treatment on the junction of the RCA terminal with a self-fusion tape. RCA jack (Yellow) List of Input/Output Sentence Input Sentence The sentences shown on the table below can be received.

  • Page 72: Chapter 6 Attached Table

    MDC-2000 Series Chapter 6 Attached Table Chapter 6 Attached Table Menu Configuration 0093120005-02...
  • Page 73 Chapter 6 Attached Table MDC-2000 Series 0093120005-02...

  • Page 74: Specifications

    MDC-2000 Series Chapter 6 Attached Table Specifications 0093120005-02...

  • Page 75: External View

    Chapter 6 Attached Table MDC-2000 Series External View Unit: mm (inch) 0093120005-02...
  • Page 76 MDC-2000 Series Chapter 6 Attached Table (1/4) Dia 5Holes Dimension drawing of table installation Unit: mm (inch) Fixing holes for M4 screw (4pcs) Unit: mm (inch) Dimension drawing of flush-mount installation 0093120005-02...
  • Page 77 Chapter 6 Attached Table MDC-2000 Series RB715A Unit: mm (inch) Weight: 10kg RB716A/ RB717A and RB718A with RW701A-03/04/06 Unit: mm (inch) Weight for RB716A: 21.5kg/ (RW701A-03): 22.5kg/ (RW701A-04) RB717A/RB718A: 22.5kg/ (RW701A-04): 24.5kg/ (RW701A-06) 0093120005-02...

  • Page 78: Chapter 7 Principle Of Radar System

    MDC-2000 Series Chapter 7 Principle of radar system Chapter 7 Principle of radar system What is the radar system? The radar system is a navigation device that transmits a very high frequency radio wave referred as microwave from antenna. The radar then receives the radio wave reflected by target(s) (e.g. other ship, buoy, island, etc) via the same antenna and converts the received radio wave to electronic signals and sends these signals to the Display unit.

  • Page 79: Characteristics Of Radar Radio Wave

    Chapter 7 Principle of radar system MDC-2000 Series Characteristics of radar radio wave The radio wave propagates slightly along the ground (primarily line of sight). This characteristic varies depending on the density of atmosphere but generally calculated according to the formula as shown below, considering that the distance with radar sight D is about 6% longer than the distance with optical sight.
  • Page 80 MDC-2000 Series Chapter 7 Principle of radar system ● Virtual image The image of a large physical object in a close proximity may appear in two different orientations. One is a real image and the other is a false image caused by wave reflected on the chimney stack or the mast, etc.

  • Page 81: Radar Interference

    Chapter 7 Principle of radar system MDC-2000 Series ● False image by sidelobe The microwave beam radiated from the antenna has a side lobe in different direction than that of the main beam. Since this side lobe is lower than that of main beam, the effect is negligible for targets at a long range, but a close, strong reflecting target may cause false image in a circular arc shape.
