Multitech MultiVOIP MVP 800 User Manual page 9

Number Description
101 Headquarters
Trunk Ext 4
102 Headquarters
Trunk Ext 5
103 Headquarters
Trunk Ext 6
104 Headquarters
Trunk Ext 7
201 Sales
KTS 201
202 Sales
PSTN 202
301 Regional
301
302 Regional
302
401 Marketing
Trunk Ext 9
402 Marketing
Trunk Ext 10
From the phone directory data base you can build your VOIP dialing directory. For example, if a
person in our typical VOIP network at the headquarters picked up a telephone (for example extension
4123) and wanted to talk to some one at the Sales office, they would dial one of the four
headquarters extension numbers (4, 5, 6, or 7). It makes no difference which extension you choose,
because they all get you to the headquarters multiVOIP. A second dial tone is heard, then you would
dial 201 to access channel 1 of the Sales MultiVOIP. This would ring the Key Telephone System
(KTS) at the Sales office. An attendant at the Sales office would then direct your call.
Phone Directory Data Base
Channel
1
2
3
4
1
2
1
2
1
2
Chapter 1 - Introduction and Description
IP Address
201.23.122.118
201.23.122.118
201.23.122.118
201.23.122.118
205.24.123.119
205.24.123.119
206.25.124.120
206.25.124.120
207.26.125.121
207.26.125.121
9
