AV615BHM
INSTALLATION/OWNER'S MANUAL
®
DVD Multimedia Receiver with Bluetooth
featuring a
6.2"
Touch Screen Display
Safety Notes:
The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature
to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the
parking brake is engaged. It is illegal in most states for the driver to view video while the vehicle is in motion.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AV615BHM and is the answer not in the manual?

Questions and answers

Candace Dixon
May 22, 2025

where is the radio fuse located?

1 comments:
Mr. Anderson
May 25, 2025

The radio fuse in the Axxera AV615BHM is located inside the in-line filter box and is a 15 amp ATM mini style fuse.

This answer is automatically generated

Bart
March 9, 2025

How to brighten up backup camera

1 comments:
Mr. Anderson
March 9, 2025

To brighten the backup camera on the Axxera AV615BHM, adjust the video settings by increasing the Brightness level. Go to the Setup Menu, navigate to Video, and drag the Brightness slider up to a higher value (between -20 and 20) to enhance the display brightness.

This answer is automatically generated

Danny Null
March 7, 2025

Can I adjust the speakers. Turn one off or down

1 comments:
Mr. Anderson
March 7, 2025

Yes, you can adjust the speakers on the Axxera AV615BHM. The unit allows you to adjust the Fader and Balance settings, which control the front-rear and left-right sound distribution, respectively. You can set the Fader between 10F (front) and 10R (rear) and the Balance between 10L (left) and 10R (right). However, it does not mention an option to turn off individual speakers completely.

This answer is automatically generated

Summary of Contents for Axxera AV615BHM

  • Page 1 AV615BHM INSTALLATION/OWNER’S MANUAL ® DVD Multimedia Receiver with Bluetooth featuring a 6.2" Touch Screen Display Safety Notes: The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the...
  • Page 2 Copyright Notes This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.
  • Page 3: Table Of Contents

    AV615BHM PREPARATION Table of Contents Page Warning Statement ..........
  • Page 4: Warning Statement

    AV615BHM PREPARATION WARNING Upon installation of this Monitor/DVD player (“unit”) into a vehicle, the driver of the vehicle must not operate this unit by watching videos or playing video games while driving. Failure to follow this instruction could lead to driver distraction which could result in serious injury or death to the vehicle’s occupants or persons outside...
  • Page 5: Safety Information/Precautions

    Please read all instructions carefully before attempting to install or operate. Due to its technical nature, it is highly recommended that your Axxera AV615BHM is installed by a professional installer or an authorized dealer. This product is only for use in vehicles with 12VDC negative ground only.
  • Page 6: Preparation/Mounting

    AV615BHM INSTALLATION Preparation Before You Start Disconnect negative battery terminal. Consult a qualified technician for instructions. Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
  • Page 7: Wiring Diagram

    AV615BHM INSTALLATION Wiring Diagram - Inputs/Outputs V-IN V-OUT 2 V-OUT 1 L-IN R-IN HDMI Dual Mirror Input USB Input (Charging Only) SUBWOOFER GREY SUBWOOFER GREY REAR CAMERA INPUT YELLOW SWC - GND (BLACK) SWC 1 (BROWN) SWC 2 (BROWN/BLACK) ORANGE...
  • Page 8: Control Locations

    AV615BHM OPERATION Control Locations Power/Mode IR Sensor Play/Pause/Channels 1-6 USB Port Select/Volume Up/Down Reset Mute Auxiliary Input Microphone Eject Go to / * Key Power & Mode Talk Mute Adjust Angle End / Reject Setup Clock Select Subtitle & Local/Distance...
  • Page 9: Remote Control Preparation

    AV615BHM OPERATION Remote Control Preparation Remove battery insulation tape . Notes: • The remote control uses one 3 volt Lithium CR2025 battery. Remove the battery if the remote will not be used for a month or longer. • Remove and dispose of battery properly.
  • Page 10: General Operation

    AV615BHM OPERATION General Operation Power On/Off Momentarily press to turn the unit on or off. Volume Rotate the volume knob to increase or decrease the volume level. Mute Momentarily press MUTE to silence the audio. Momentarily press MUTE again to return to the previously selected volume.
  • Page 11 AV615BHM OPERATION General Operation From the Main Menu screen, press SETUP in the bottom right corner to Setup Menu access the Setup menu and select from six categories across the bottom: General, Time, Video, Language, Illumination and Calibration. General: • Animation - Select Off, 10 second, 30 second, 1 minute, 90 second, 2 minute, 3 minute or 4 minute to set animation length.
  • Page 12 AV615BHM OPERATION General Operation Setup Menu Time: • Hour - Press < or > to adjust the hour down or up. • Minute - Press < or > to adjust the minutes down or up. • Format - Select between a 12HR or 24HR clock display.
  • Page 13: Am/Fm Tuner Operation

    AV615BHM OPERATION AM/FM/RDS Tuner Operation Radio Operation Select the Radio icon from the Main Menu screen. Press to return to Main Menu screen. Main Menu Displays current mode of operation. Current Mode Indicator Press << to tune radio to a lower frequency. Press < to tune the unit Tune Frequency Down down one step at a time.
  • Page 14 AV615BHM OPERATION AM/FM/RDS Tuner Operation Press to adjust the following Audio options: Audio • EQ - Select from the preset EQ options: JAZZ, CLASSIC, POP, ROCK, BEAT OR FLAT, or select USER to manually adjust Bass, Middle and Treble options between -7 and 7.
  • Page 15 AV615BHM OPERATION AM/FM/RDS Tuner Operation Local / Distance Press to toggle between LOCAL and DX (distance) tuning. Program Type (PTY) Press to select Program Type / Genre. Traffic Announcements Press to turn on/off Traffic Announcements. Alternative Frequencies Press to select Alternative Frequencies.
  • Page 16: Cd/Usb Operation

    AV615BHM OPERATION CD/USB Operation To play audio files from a disc or MP3/WMA files from a disc or USB CD/MP3/WMA or JPG Operation device, insert disc or device and playback will begin automatically. To return to disc or USB playback from another mode of operation, select the corresponding icon from the Main Menu.
  • Page 17: Cd/Usb Operation

    AV615BHM OPERATION CD/USB Operation Camera Press to access the Camera when the camera function is enabled. Previous Options Press to see the previous screen of options. Mute Press to mute the unit's sound. Press again to unmute, or sound can be restored by adjusting the volume knob of the front panel.
  • Page 18 AV615BHM OPERATION Media Compatibility - USB File Type FAT 12 File System FAT 16/FAT 32 .mp3/.MP3/.Mp3/.mP3 File .wma/.WMA Extension .rmp/.m4a MPEG 1 MPEG MPEG 2 Format MPEG 2.5 MPEG 1 32/44. 1 /48kHz MPEG 2 12/16/22.05/24kHz Sampling Frequency MPEG 2.5 8/11.025/12kHz...
  • Page 19 AV615BHM OPERATION Media Compatibility - CD/DVD File Type Level 1, Level 2 ISO9660 Level 3 Playback ISO9660 JOLIET File System Extension Filename 32 bytes 32 bytes Playback ROMEO Other Filename Extensions Apple ISO .mp3/.MP3/.Mp3/.mP3 File .wma/.WMA Extension .rmp/.m4a MPEG 1...
  • Page 20 AV615BHM OPERATION Media Compatibility The following types of discs/files are compatible: Media Compatibility • CD-DA, CD-ROM (ISO), CD-R, CD-RW • DVD Video, DVD+R/RW, DVD-R/RW • AVI - Max video resolution: 720x480, Max video bit rate: 5000 kbps • Mpeg2: Max video resolution: 720x480, Max video bit rate: 5000 kbps •...
  • Page 21: Dvd Operation

    AV615BHM OPERATION DVD Operation Inserting a Disc Insert disc into the slot, and playback will begin automatically. Sub- menus may have to be pressed to access the DVD content. Read the directions of your specific DVD disc for other features.
  • Page 22: Dvd Operation

    AV615BHM OPERATION DVD Operation Next Chapter Press to advance to the next chapter. Fast Reverse Press to fast reverse playback at various speeds: FRx2, FRx4, FRx8 or FRx20. Fast Forward Press to fast forward playback at various speeds: FRx2, FRx4, FRx8 or FRx20.
  • Page 23: Dualmirror Operation

    AV615BHM OPERATION DualMirror™ Operation The DualMirror™ technology allows you to mirror the screen of select Android smartphones as well as iPhone, iPod and iPad devices onto the receiver's screen and to charge your mobile device through the rear USB port. Simply plug in your device to the rear HDMI and USB inputs, and you are ready to view your favorite navigation or music apps directly on the receiver’s screen.
  • Page 24: Dualmirror Operation

    AV615BHM OPERATION DualMirror™ Operation Connecting an iPhone, iPod or iPad device DMH25 WiFi Dongle (sold separately) To HDMI Input...
  • Page 25: Bluetooth Operation

    The unit broadcasts the pairing signal constantly when no devices are currently connected. Complete the pairing sequence from your Bluetooth device. Refer to the owner's manual for your device for more details. The device name is "AXXERA BT". Bluetooth passcode "0000". The unit can be in any mode of operation when pairing is performed.
  • Page 26 AV615BHM OPERATION Bluetooth Operation Make a Call Press to display the keypad and make a call. Dialed Call Log Press to display a log of dialed calls. Use the icons on the right to search for a specific contact or scroll through the list.
  • Page 27: Auxiliary Inputs/Rear Camera Operation

    AV615BHM OPERATION Front 3.5mm Aux Input & Rear RCA A/V Input Auxiliary Input Connect an optional audio source into the 3.5mm (front panel) input. Select auxiliary input from the Main Menu to listen to audio. Adjust volume on the external audio source as needed (if connected to the headphone output of the device).
  • Page 28: Warranty

    AV615BHM OPERATION Limited One Year Warranty This warranty gives you specific legal rights. You What to do? may also have other rights which vary from state to 1. Before you call for service, check the state. troubleshooting guide in your owner’s manual. A slight adjustment of any custom controls may save Dual Electronics Corp.
  • Page 29: Specifications

    AV615BHM OPERATION Specifications Disc Frequency response: 20Hz-20kHz Channel separation @ 1kHz: >80dB D/A converter: 24 Bit FM Tuner Tuning range: 87.5MHz-107.9MHz Usable sensitivity: 10dBf 50dB quieting sensitivity: 20dBf Stereo separation @ 1kHz: 38dB Frequency response: 30Hz-13kHz AM Tuner Tuning range:...
  • Page 30: Troubleshooting

    Please keep your original sales receipt and be prepared to provide this receipt in the event you require service, as your original receipt is considered the best proof of purchase and indicates the date you purchased your Axxera product. Dealer Name...
  • Page 31 Dual Electronics Corp. Toll Free: 1-866-382-5476 Monday-Friday, 9AM-5PM EST www.axxeraaudio.com ©2016 Dual Electronics Corp. All rights reserved. NSA0316-V01 Printed in China...
