AV7115B
INSTALLATION/OWNER'S MANUAL
®
DVD Multimedia Receiver with Bluetooth
featuring a
7"
Touch Screen Display
Safety Notes:
The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature
to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the
parking brake is engaged. It is illegal in most states for the driver to view video while the vehicle is in motion.
Advertisement
Table of Contents
Related Manuals for Axxera AV7115B
Summary of Contents for Axxera AV7115B
- Page 1 AV7115B INSTALLATION/OWNER’S MANUAL ® DVD Multimedia Receiver with Bluetooth featuring a 7" Touch Screen Display Safety Notes: The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the...
- Page 2 Copyright Notes This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.
-
Page 3: Table Of Contents
AV7115B PREPARATION Table of Contents Page Warning Statement .......... -
Page 4: Warning Statement
AV7115B PREPARATION WARNING Upon installation of this Monitor/DVD player (“unit”) into a vehicle, the driver of the vehicle must not operate this unit by watching videos or playing video games while driving. Failure to follow this instruction could lead to driver distraction which could result in serious injury or death to the vehicle’s occupants or persons outside... -
Page 5: Safety Information/Precautions
Please read all instructions carefully before attempting to install or operate. Due to its technical nature, it is highly recommended that your Axxera AV7115B is installed by a professional installer or an authorized dealer. This product is only for use in vehicles with 12VDC negative ground only. -
Page 6: Preparation/Mounting
AV7115B INSTALLATION Preparation Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. -
Page 7: Wiring Diagram
AV7115B INSTALLATION Wiring Diagram - Inputs/Outputs RL OUTPUT VIDEO OUTPUT RR OUTPUT VIDEO OUTPUT FL OUTPUT REAR CAMERA INPUT FR OUTPUT AUX INPUT L SUBWOOFER AUX INPUT R SUBWOOFER VIDEO INPUT SWC - GND (BLACK) SWC 1 (BROWN) SWC 2 (BROWN/BLACK) -
Page 8: Control Locations
AV7115B OPERATION Control Locations Release Volume Knob / Push Select Eject Mode IR Sensor Power USB Port Play / Pause / Band Microphone Tune / Track Up Auxiliary Input Answer Call Mute / End Call Open Tune/Track Down Go to / * Key Power &... -
Page 9: Remote Control Preparation
AV7115B OPERATION Remote Control Preparation Remove battery insulation tape . Notes: • The remote control uses one 3 volt Lithium CR2025 battery. Remove the battery if the remote will not be used for a month or longer. • Remove and dispose of battery properly. -
Page 10: General Operation
AV7115B OPERATION General Operation Installing the Faceplate Align the faceplate with the front of the unit, then snap in place beginning with the left side. Power On/Off Momentarily press to turn the unit on or off. Volume Rotate the volume knob to increase or decrease the volume level. - Page 11 AV7115B OPERATION General Operation From the Main Menu screen, press SETUP in the bottom right corner to Setup Menu access the Setup menu and select from six categories across the bottom: General, Time, Video, Language, Illumination and Calibration. General: • Animation - Select Off, 10 second, 30 second, 1 minute, 90 second, 2 minute, 3 minute or 4 minute to set animation length.
- Page 12 AV7115B OPERATION General Operation Setup Menu Time: • Hour - Press < or > to adjust the hour down or up. • Minute - Press < or > to adjust the minutes down or up. • Format - Select between a 12HR or 24HR clock display.
-
Page 13: Am/Fm Tuner Operation
AV7115B OPERATION AM/FM/RDS Tuner Operation Radio Operation Select the Radio icon from the Main Menu screen. Press to return to Main Menu screen. Main Menu Displays current mode of operation. Current Mode Indicator Press << to tune radio to a lower frequency. Press < to tune the unit Tune Frequency Down down one step at a time. - Page 14 AV7115B OPERATION AM/FM/RDS Tuner Operation Press to adjust the following Audio options: Audio • EQ - Select from the preset EQ options: JAZZ, CLASSIC, POP, ROCK, BEAT OR FLAT, or select USER to manually adjust Bass, Middle and Treble options between -7 and 7.
- Page 15 AV7115B OPERATION AM/FM/RDS Tuner Operation Local / Distance Press to toggle between LOCAL and DX (distance) tuning. Tilt Screen Up Press to adjust the screen angle up. Tilt Screen Down Press to adjust the screen angle down. Program Type (PTY) Press to select Program Type / Genre.
-
Page 16: Cd/Usb/Sd Card Operation
AV7115B OPERATION CD/USB/SD Card Operation To play audio files from a disc or MP3/WMA files from a disc, USB device CD/MP3/WMA or JPG Operation or SD card, insert disc or device and playback will begin automatically. To return to disc, USB or SD card playback from another mode of operation, select the corresponding icon from the Main Menu. - Page 17 AV7115B OPERATION CD/USB/SD Card Operation Camera Press to access the Camera when the camera function is enabled. Previous Options Press to see the previous screen of options. Mute Press to mute the unit's sound. Press again to unmute, or sound can be restored by adjusting the volume knob of the front panel.
- Page 18 AV7115B OPERATION Media Compatibility - USB/SD Card File Type FAT 12 File System FAT 16/FAT 32 .mp3/.MP3/.Mp3/.mP3 File .wma/.WMA Extension .rmp/.m4a MPEG 1 MPEG MPEG 2 Format MPEG 2.5 MPEG 1 32/44. 1 /48kHz MPEG 2 12/16/22.05/24kHz...
- Page 19 AV7115B OPERATION Media Compatibility - CD/DVD File Type Level 1, Level 2 ISO9660 Level 3 Playback ISO9660 JOLIET File System Extension Filename 32 bytes 32 bytes Playback ROMEO Other Filename Extensions Apple ISO .mp3/.MP3/.Mp3/.mP3 File .wma/.WMA...
- Page 20 AV7115B OPERATION Media Compatibility The following types of discs/files are compatible: Media Compatibility • CD-DA, CD-ROM (ISO), CD-R, CD-RW • DVD Video, DVD+R/RW, DVD-R/RW • AVI - Max video resolution: 720x480, Max video bit rate: 5000 kbps • Mpeg2: Max video resolution: 720x480, Max video bit rate: 5000 kbps •...
- Page 21 AV7115B OPERATION WARNING Upon installation of this Monitor/DVD player (“unit”) into a vehicle, the driver of the vehicle must not operate this unit by watching videos or playing video games while driving. Failure to follow this instruction could lead to driver distraction which could result in serious injury or death to the vehicle’s occupants or persons outside...
-
Page 22: Dvd Operation
AV7115B OPERATION DVD Operation Inserting a Disc Insert disc into the slot, and playback will begin automatically. Sub- menus may have to be pressed to access the DVD content. Read the directions of your specific DVD disc for other features. -
Page 23: Dvd Operation
AV7115B OPERATION DVD Operation Next Chapter Press to advance to the next chapter. Fast Reverse Press to fast reverse playback at various speeds: FRx2, FRx4, FRx8 or FRx20. Fast Forward Press to fast forward playback at various speeds: FRx2, FRx4, FRx8 or FRx20. -
Page 24: Bluetooth Operation
AV7115B OPERATION Bluetooth Operation Preparation Before you can use a Bluetooth device, it must be paired and connected. Make sure that Bluetooth is activated on your device before you begin the pairing process. Pairing a New Device The unit broadcasts the pairing signal constantly when no devices are currently connected. -
Page 25: Bluetooth Operation
AV7115B OPERATION Bluetooth Operation Make a Call Press to display the keypad and make a call. Dialed Call Log Press to display a log of dialed calls. Use the icons on the right to search for a specific contact or scroll through the list. -
Page 26: Auxiliary Inputs/Rear Camera Operation
AV7115B OPERATION Front 3.5mm Aux Input & Rear RCA A/V Input Auxiliary Input Connect an optional audio source into the 3.5mm (front panel) input. Select auxiliary input from the Main Menu to listen to audio. Adjust volume on the external audio source as needed (if connected to the headphone output of the device). -
Page 27: Warranty
AV7115B OPERATION Limited One Year Warranty This warranty gives you specific legal rights. You What to do? may also have other rights which vary from state to 1. Before you call for service, check the state. troubleshooting guide in your owner’s manual. A slight adjustment of any custom controls may save Dual Electronics Corp. -
Page 28: Specifications
AV7115B OPERATION Specifications Disc Frequency response: 20Hz-20kHz Channel separation @ 1kHz: >80dB D/A converter: 24 Bit FM Tuner Tuning range: 87.5MHz-107.9MHz Usable sensitivity: 10dBf 50dB quieting sensitivity: 20dBf Stereo separation @ 1kHz: 38dB Frequency response: 30Hz-13kHz AM Tuner Tuning range:... -
Page 29: Troubleshooting
Please keep your original sales receipt and be prepared to provide this receipt in the event you require service, as your original receipt is considered the best proof of purchase and indicates the date you purchased your Axxera product. Dealer Name... - Page 30 Dual Electronics Corp. Toll Free: 1-866-382-5476 Monday-Friday, 9AM-5PM EST www.axxeraaudio.com ©2015 Dual Electronics Corp. All rights reserved. NSA0415-V01 Printed in China...
