- Page 1 Operation/Reference Guide NXA-ENET8POE Gigabit Ethernet Switch N e t w o r k / C o m m u n i c a t i o n Init ial Re le ase : 3/2 3 /20 1 1...
- Page 2 AMX is not responsible for products returned without a valid RMA number. AMX is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost savings, incidental damages, or consequential damages.
- Page 3 LICENSE GRANT. AMX grants to Licensee the non-exclusive right to use the AMX Software in the manner described in this License. The AMX Software is licensed, not sold. This license does not grant Licensee the right to create derivative works of the AMX Software.
-
Page 5: Table Of Contents
Table of Contents Table of Contents NXA-ENET8POE Gigabit PoE Ethernet Switch ...........1 Overview ........................1 Common Application ....................1 Features .......................... 1 NXA-ENET8POE Architecture................... 3 Power-over-Ethernet Capability................3 10/100/1000BASE-T Ports ..................4 SFP Slot ........................4 Port and Power Status LEDs ..................4 Power Supply Socket .................... - Page 6 IGMP Snooping....................... 41 Settings ......................... 41 Status ..........................42 LLDP ........................43 Settings ......................... 43 Neighbor ........................44 RSTP........................45 Settings ......................... 45 STA Introduction ......................46 Status ..........................47 QOS ........................48 Settings ......................... 48 NXA-ENET8POE Gigabit PoE Ethernet Switch...
- Page 7 Installation ......................53 In-Band Access ......................53 Forgot or Lost Password..................53 Changing a PC’s IP Address..................54 Resetting the NXA-ENET8POE to Factory Defaults..........54 Appendix B: Cables ..................55 Twisted-Pair Cable and Pin Assignments ..............55 10BASE-T/100BASE-TX Pin Assignments..............55 Straight-Through Wiring ..................
- Page 8 Table of Contents viii NXA-ENET8POE Gigabit PoE Ethernet Switch...
-
Page 9: Nxa-Enet8Poe Gigabit Poe Ethernet Switch
Switch Overview The NXA-ENET8POE Gigabit Ethernet Switch features 8 x 1000 Base-T ports and is designed for homes and businesses that require a managed network for efficient handling of voice, video, and data applications. The NXA-ENET8POE transmits both power and data through a single cable to eight remotely located Power-over-Ethernet (PoE) enabled devices such as AMX Touch Panels, Wireless Access Points, VoIP Phones and IP Surveillance cameras. - Page 10 NXA-ENET8POE Gigabit PoE Ethernet Switch SFP transceiver slot Power LED PoE LEDs PoE Ports (front) Link/ACT LEDs Status LED (rear) 120-240 VAC input FIG. 1 NXA-ENET8POE Gigabit PoE Ethernet Switch NXA-ENET8POE Specifications Dimensions (HWD): 1.7" x 13" x 8" (4.4 cm x 33 cm x 20.3 cm) Weight: 4 lbs.
-
Page 11: Nxa-Enet8Poe Architecture
(Dharan), Taiwan, Thailand, Uruguay (FG2255-60K) NXA-ENET8POE Architecture The NXA-ENET8POE employs a wire-speed, non-blocking switching fabric. This permits simultaneous wire- speed transport of multiple packets at low latency on all ports. The device also features full-duplex capability on all ports, which effectively doubles the bandwidth of each connection. -
Page 12: 10/100/1000Base-T Ports
The NXA-ENET8POE includes a display panel (FIG. 1) for key system and port indications that simplify installation and network troubleshooting. Power Supply Socket The power socket is located on the rear panel of the NXA-ENET8POE (FIG. 1). The standard power socket is for the AC power cord. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 13: Network Planning
IP telephones or access points. You can easily connect a PoE device to a switch port and allow power to be supplied over the connecting cable. Each of the eight ports on the NXA-ENET8POE can provide power to a connected device. -
Page 14: Meeting Room
Meeting Room Making VLAN Connections The NXA-ENET8POE supports VLANs that can be used to organize any group of network nodes into separate broadcast domains (FIG. 5). VLANs confine broadcast traffic to the originating group, and can eliminate broadcast storms in large networks. This provides a more secure and cleaner network environment. -
Page 15: Application Notes
1000BASE-LX: 5 km (3.1 miles) for single-mode fiber 1000BASE-LH: 70 km (43 miles) for single-mode fiber However, power budget constraints must also be considered when calculating the maximum cable length for your specific environment. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 16: Installing The Nxa-Enet8Poe
Network Planning Installing the NXA-ENET8POE Selecting a Site The NXA-ENET8POE can be mounted in a standard 19-inch equipment rack or on a flat surface. Be sure to follow the guidelines below when choosing a location. The site should: Be at the center of all the devices you want to link and near a power outlet. -
Page 17: Connecting To A Power Source
Check the front-panel LEDs as the device is powered on to be sure the Power LED is on. If not, check that the power cable is correctly plugged in. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 18: Making Network Connections
The NXA-ENET8POE controls the power and data on a port independently. Power can be requested from a device that already has a data link to the switch. Also, the switch can supply power to a device even if the port’s data connection has been disabled. -
Page 19: Fiber Optic Sfp Devices
50/125 or 62.5/125 micron multimode fiber optic cabling with an LC connector at both ends. The NXA-ENET8POE use lasers to transmit signals over fiber optic cable. The lasers are compliant with the requirements of a Class 1 Laser Product and are inherently eye-safe in normal operation. -
Page 20: Connectivity Rules
100 m (328 ft) RJ-45 10 Mbps Ethernet Collision Domain Maximum Ethernet Cable Length Type Cable Type Maximum Cable Length Connector 10BASE-T Categories 3, 4, 5 or better 100-ohm UTP 100 m (328 ft) RJ-45 NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 21: Cable Labeling And Connection Records
Use sequential numbers for cables that originate from the same equipment. Differentiate between racks by naming accordingly. Label each separate piece of equipment. Display a copy of your equipment map, including keys to all abbreviations at each equipment rack. NXA-ENET8POE Gigabit PoE Ethernet Switch... - Page 22 Network Planning NXA-ENET8POE Gigabit PoE Ethernet Switch...
-
Page 23: Browser-Based Configuration Pages
To configure it with an IP address other than the default: Place the NXA-ENET8POE close to the PC that you intend to use for configuration. It helps if you can see the front panel of the switch while working on your PC. -
Page 24: Configuration Page Interface
Browser-Based Configuration Pages Configuration Page Interface The NXA-ENET8POE provides an embedded HTTP web agent. Using a web browser, you can configure the device and view statistics to monitor network activity. The web agent can be accessed by any computer on the network using a standard web browser (Internet Explorer 5.5 or above, or Mozilla Firefox 1.0 or above). -
Page 25: Status
Status - Overview page Refresh: Click this button to refresh the displayed information. System Information System Name: The name assigned to the NXA-ENET8POE. System Location: The current location of the NXA-ENET8POE. System Contact: The contact information for the device administrator. - Page 26 VLAN ID: A number in the range 1 - 4094 which identifies the VLAN. VLAN Members: A list of the ports that are members of the VLAN. By default, all ports are members of VLAN 1. NXA-ENET8POE Gigabit PoE Ethernet Switch...
- Page 27 Browser-Based Configuration Pages Status - Overview page (Cont.) Help: Links directly to web help. Refresh: Refreshes the workspace. NXA-ENET8POE Gigabit PoE Ethernet Switch...
-
Page 28: Statistics
You can display statistics on network traffic from the ports. These statistics can be used to identify potential problems with the NXA-ENET8POE (such as a faulty port or unusually heavy loading). All values displayed have been accumulated since the last system reboot, but can be reset to zero by clicking the Clear button. The current statistics are not displayed until you click the Refresh button. -
Page 29: System
Browser-Based Configuration Pages System From the System section, you can get the name of the NXA-ENET8POE, set the LAN IP address, subnet mask, and gateway IP address, and change the password. Name You can easily identify the system by displaying the device name. -
Page 30: Lan Settings
1. However, the management station can be attached to a port belonging to any VLAN, as long as that VLAN has been assigned an IP address. Help: Links directly to web help. Apply: Sets specified values to the system. Cancel: Discards all changes and restores current values. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 31: Password
System - Password page Current Password: Specifies the user password. (Range: 1-16 characters plain text, case sensitive) Help: Links directly to web help. Apply: Sets specified values to the system. Cancel: Discards all changes and restores current values. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 32: Secure Mac
System - Secure MAC page Secure MAC Configuration: Secure MAC Enabled: Click this box to allow the NXA-ENET8POE to access secure MAC addresses. Uplink Ports: Click the appropriate boxes to allow uplink from particular ports on the device. Add Static MAC Address: MAC Address: Enter the MAC address of the device to be added. -
Page 33: Tools
Browser-Based Configuration Pages Tools On the Tools page, you can restore the NXA-ENET8POE to default settings, upgrade the firmware of the device, or restart the device. FIG. 15 System - Tools page System - Tools page Restore to Factory Defaults: Forces the switch to restore the original factory settings. -
Page 34: Ports
Pages than usual. Power Saving Mode: Select Enable or Disable from the dropdown list. Port: The individual front port on the NXA-ENET8POE. Speed/Duplex: Allows you to manually set the port speed and duplex mode. Flow Control: Allows flow control to be enabled or disabled. When the box is checked, flow control is enabled. -
Page 35: Storm Control
When the threshold is exceeded, packets are dropped, irrespective of the flow-control settings. Help: Links directly to web help. Apply: Sets specified values to the system. Cancel: Discards all changes and restores current values. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 36: Port Mirroring
Input rate-limiting in conjunction with port flow-control should be used to ensure that the total ingress bandwidth never exceeds the egress bandwidth. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 37: Cable Diagnostics
Shows the length of the cable in meters. Status: Shows the operating conditions and isolates a variety of common faults that can occur on Category 5 twisted pair cabling. Help: Links directly to web help. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 38: Trunks
Browser-Based Configuration Pages Trunks From the Trunks section, you can select ports to group into static trunks, configure trunk connection settings, configure Link Aggregation Control Protocol (LACP) on the NXA-ENET8POE, and show the LACP groups status. Membership This page allows you to create a maximum of four trunks of up to eight ports per trunk. The Membership Table has one row for each port and six columns. -
Page 39: Settings
Allows flow control to be enabled or disabled. When the box is checked, flow control is enabled. Ports: Indicates which ports belong to the trunk. Help: Links directly to web help. Apply: Sets specified values to the system. Cancel: Discards all changes and restores current values. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 40: Lacp Setup
Browser-Based Configuration Pages LACP Setup The NXA-ENET8POE supports both static trunking and dynamic Link Aggregation Control Protocol (LACP). LACP configured ports can automatically negotiate a trunked link with LACP-configured ports on another device. You can configure any number of ports on the switch as LACP, as long as they are not already configured as part of a static trunk. -
Page 41: Lacp Status
Browser-Based Configuration Pages LACP Status This page displays the LACP status of the NXA-ENET8POE. FIG. 23 Trunks - LACP Status Trunks - LACP Status page Aggregation Information: Shows aggregation information for each LACP group. Aggregation Group: The ID number of the LACP group. -
Page 42: Vlans
VLANs based on the IEEE 802.1Q standard. Ports can be manually assigned to a specific set of VLANs. This allows the NXA-ENET8POE to restrict traffic to the VLAN groups to which a user has been assigned. By segmenting your network into VLANs, you can: ... -
Page 43: Vlan Membership
Lists all the current VLAN groups created for this system. Up to 64 VLAN groups can be defined. VLAN 1 is the default untagged VLAN. Help: Links directly to web help. Modify: Allows modification of the VLAN in the list. Delete: Deletes the VLAN. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 44: Vlan Port Config
Browser-Based Configuration Pages VLAN Port Config There are three different parameters that can be configured for each port on the NXA-ENET8POE; VLAN ID (VLAN membership), PVID and Packet Type. Note that the ports within a trunk cannot be configured individually; configure the trunk instead (trunks are labelled T1 to T4). - Page 45 Sets specified values to the system. Cancel: Discards all changes and restores current values. If you select “Tagged Only” mode for a port, it is recommended to set the PVID to “None” as the standard configuration. NXA-ENET8POE Gigabit PoE Ethernet Switch...
-
Page 46: 802.1X
Reauthentication Period: Sets the time period after which a connected client must be re-authenticated. EAP timeout: The time the switch shall wait for the supplicant response before re-transmitting a packet. Port Setting: Port: The port number. NXA-ENET8POE Gigabit PoE Ethernet Switch... - Page 47 The reason for the “quiet-period”: If a re-authentication fails, the IEEE 802.1X standard enforces a so-called “quiet-period” in which the authenticator (switch) shall be quiet and not re-try another authentication – also packets from the supplicant are discarded. In this way, “brute-force” attacks are prevented. NXA-ENET8POE Gigabit PoE Ethernet Switch...
-
Page 48: Statistics
General statistics for authenticator. Backend Authenticator General statistics for RADIUS server. counters: 802.1X MIB counters: MIB module defined for 802.1X. Other statistics: This section collects the Last Supplicant identity statistics. Help: Links directly to web help. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 49: Igmp Snooping
The switch management interface is on VLAN 1 (this cannot be changed) All ports have a Port VLAN ID (PVID) of 1 All ports can send and receive both VLAN-tagged and untagged packets (i.e. they are “hybrid” ports) NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 50: Status
Show the number of received v2 Report packets. v3 Reports: Show the number of received v3 Report packets. v2 Leaves: Show the number of v2 leave packets received. Help: Links directly to web help. Refresh: Refreshes the statistics on the page. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 51: Lldp
You can choose to disable or enable LLDP for each port. Enabling LLDP will allow the port to receive and transmit TLVs. Help: Links directly to web help. Apply: Sets specified values to the system. Cancel: Discards all changes and restores current values. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 52: Neighbor
The port description and information of the neighboring device. System Capabilities: The system capabilities information of the neighboring device. Management Address: Displays the management address of the neighboring device. Help: Links directly to web help. Refresh: Refreshes the statistics on the page. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 53: Rstp
(i.e., discarding to learning to forwarding). Number between 4 - 30 (default is 15). Force Version: Set and show the RSTP protocol to use. • Normal - use RSTP • Compatible - compatible with STP. RSTP Port Configuration: NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 54: Sta Introduction
The spanning tree algorithms supported by this switch include these versions: STP - Spanning Tree Protocol (IEEE 802.1D) RSTP - Rapid Spanning Tree Protocol (IEEE 802.1w) NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 55: Status
(i.e., discarding to learning to forwarding). Number between 4 - 30 (default is 15). Topology: Shows the NXA-ENET8POE’s current state Root ID: The root port ID for the NXA-ENET8POE. RSTP Port Status: Port/Trunk: Port/Trunk ID number. VLAN ID: VLAN IDs of the port. -
Page 56: Qos
Note: Because end-stations, like PCs, are not usually VLAN aware, they do not create VLAN-tagged frames. As a result, this method of prioritization is not ideal when many PCs are connected to the NXA-ENET8POE. DSCP: The Differentiated Services Code Point (DSCP) is a six bit field that is con- tained within an IP (TCP or UDP) header. -
Page 57: Port-Based
Because end-stations, like PCs, are not usually VLAN aware, they do not create VLAN-tagged frames. As a result, this method of prioritization is not ideal when many PCs are connected to the NXA-ENET8POE. DSCP The Differentiated Services Code Point (DSCP) is a six bit field that is contained within an IP (TCP or UDP) header. -
Page 58: Snmp
MIB objects. SNMP Trap Community: Community string sent with the notification operation. Help: Links directly to web help. Apply: Sets specified values to the system. Cancel: Discards all changes and restores current values. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 59: Poe
Browser-Based Configuration Pages The NXA-ENET8POE can provide DC power to a wide range of connected devices, eliminating the need for an additional power source and cutting down on the amount of cables attached to each device. Once configured to supply power, an automatic detection process is initialized by the switch that is authenticated by a PoE signature from the connected device. -
Page 60: Logout
To log out of the Browser-Based Configuration Pages, open the Logout page. A prompt appears asking “Do you wish to log out?” (FIG. 37) Click OK to log out and return to the Login page. NXA-ENET8POE Gigabit PoE Ethernet Switch... -
Page 61: Appendix A: Troubleshooting
Forgot or Lost Password If you have forgotten the administration password to the NXA-ENET8POE, you can return it to its factory default state by following these steps: Remove the power cord from the back of the switch. -
Page 62: Changing A Pc's Ip Address
Disconnect the power cord and THEN disconnect the network cable. Reconnect the power cord. The NXA-ENET8POE is now reset to its factory defaults. After completing this procedure, the password will be admin and the network IP address will be returned to the default of 192.168.2.10. -
Page 63: Appendix B: Cables
Also be sure that the length of any twisted-pair connection does not exceed 100 meters (328 feet). The RJ-45 ports on the NXA-ENET8POE support automatic MDI/MDI-X operation, so you can use straight- through cables for all network connections to PCs or servers, or to other switches or hubs. In straight-through cable, pins 1, 2, 3, and 6, at one end of the cable, are connected straight through to pins 1, 2, 3, and 6 at the other end of the cable. -
Page 64: Straight-Through Wiring
(When auto-negotiation is enabled for any RJ-45 port on the NXA-ENET8POE, you can use either straight-through or crossover cable to connect to any device type.) You must connect all four wire pairs as shown in Straight-Through Wiring section on page 56 to support Gigabit Ethernet connections. -
Page 65: 1000Base-T Pin Assignments
TIA 568-B will allow the use of 50/125 micron multimode optical fiber in both the horizontal and backbone in addition to the types listed above. All optical fiber components and installation practices must meet applicable building and safety codes. NXA-ENET8POE Gigabit PoE Ethernet Switch... - Page 66 Appendix B: Cables NXA-ENET8POE Gigabit PoE Ethernet Switch...
- Page 67 Appendix B: Cables NXA-ENET8POE Gigabit PoE Ethernet Switch...
- Page 68 - Schedules and registration for any AMX University course - Travel and hotel information - Your individual certification requirements and progress 3000 RESEARCH DRIVE, RICHARDSON, TX 75082 USA • 800.222.0193 • 469.624.8000 • 469-624-7153 fax • 800.932.6993 technical support • www.amx.com...
