AMX NXA-ENET24POE Specifications

16.15 410.29
17.32 440
1.73 44
REV
REL APPR
NOTICE: This drawing is the UNLESS OTHERWISE SPECIFIED:
DS
property of AMX Corporation. DRAWN

TOLERANCE ON DECIMAL DIMENSIONS:

XX = .010
All information contained herein
XXX = .005 ENGR SERV
that is not generally known

TOLERANCE ON HOLE DIAMETERS:

ENGINEER
shall be confidential except UNDER .250 ú = +/- .005
.250 TO .500 = +.006 -.005
to the extent the information
PROD ENGR
OVER .500 = +.008 -.005
has been previously established.

FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64

MATL SUP
This drawing may not be copied, ANGLES: +/- 1.0°
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
reproduced, or used as the basis
QUALITY

ALL DIMENSIONS IN INCHES.

for manufacture or sale without
THIRD ANGLE
DO NOT SCALE THIS DRAWING.
written permission.

PROJECTION

REVISIONS

ECN DESCRIPTION DATE APPR
A
6689 INITIAL RELEASE 2/3/05 JAL
REL DATE REV APPR
AMX CORPORATION
02/03/05
3000 RESEARCH DRIVE
RICHARDSON, TX 75082
PICTORIAL,
NXA-ENET24POE
SIZE DWG. NO. REV.
D

SCALE: 1:1

95-2178-61
A
95-2178-61
SHEET 1 OF 1
R:\MECH\RELEASED\2178-60,-61_Lurtz\CURRENT\ 95-2178-61
