IMPORTANT: The supply to this unit should by wired via a double pole
isolation switch in accordance with BS EN60730-1, i.e. one which provides
air gaps of at least 3mm in both poles of the mains, and incorporates a 3
amp fuse. It is strongly recommended that solid conductors be used.
30mm minimum
Clearance for
screwdriver
access

Thermostat and Remote Room Sensor:

Fix at a height of approximately 1.5m from the fl oor, away from
draughts or heat sources such as radiators, open fi res or direct
sunlight.
DANFOSS HEATING
Outline of unit
C/L
Surface fixed cable
bottom entry knockouts
Terminal block
Wall or
Plaster box
fitting
N &
looping
terminals
Rear entry
cable access
GB
PL
5
