IRC-6 Infrared
Remote
Control

IRC-6 Operation

COLORpalette™ User Manual Rev. 4
The COLORpalette™ is compatible with the IRC-6 infrared remote control from Chauvet.
Make sure to point the IRC-6 directly at the receiver on the front of the product.
Static Color Mode
Static Color mode will enable the product to output a preset color.
To run Static Color mode:
Press <0> <9> to choose between the different preset static colors.
–
Automatic/Sound-Active Mode
Automatic/Sound-Active mode will enable you to run the automatic programs on the
product. The product will also respond to music if the sensitivity knob is set high enough.
To turn on Automatic/Sound-Active mode:
1. Press <AUTO> or <SOUND> on the IRC-6.
2. Press <0> <9>, or <FADE> to choose between the different programs.
–
To change the auto program speed:
Press <+> or <–> to increase or decrease the auto program speed.
To turn off Automatic/Sound-Active mode and return to Static Color mode:
Press <AUTO> or <SOUND> on the IRC-6.
COLORpalette™ IRC-6 Buttons:
Static Color Mode
<0> - A007 (White)
<1> - A001 (Red)
<2> - A025 (Amber)
<3> - A004 (Yellow)
<4> - A002 (Green)
<5> - A006 (Cyan)
<6> - A003 (Blue)
<7> - A005 (Purple)
<8> - A025 (Pink)
<9> - A025 (Sunflower)
<FADE> - No function
Manual Color Control
To manually control the RGB percentage:
1. Press <MANUAL> on the IRC-6.
2. Press <R> (red), <G> (green), or <B> (blue) to choose the color.
3. Press <+> or <–> to increase or decrease the percentage of each color.
Miscellaneous Operation
To adjust the strobe rate of the program:
1. Press <STROBE> on the IRC-6.
2. Press <+> or <–> to increase or decrease the strobe rate.
3. Press <STROBE> again to turn off the strobe.
To black out the lights:
Press <BLACK OUT> on the IRC-6.
This will turn off all the lights until the button is pressed again.
NOTE: The IRC will not respond to any inputs when Black Out is activated. If the remote
does not respond when a button is pressed, try pressing <BLACK OUT>. You
may have inadvertently activated Black Out.
Auto/Sound Mode
<0> - A008
<1> - A010
<2> - A011
<3> - A016
<4> - A017
<5> - A018
<6> - A020
<7> - A021
<8> - A022
<9> - A024
<FADE> - A023 (no response to sound)
Page 15 of 20
