Technical Specifications - Chauvet COLORpalette User Manual

6. T
ECHNICAL
Dimensions and
Weight
Power
Light Source
Photometrics
Thermal
DMX
Ordering
Page 18 of 20
S
PECIFICATIONS
Length
16.8 in (425 mm) 9.8 in (248 mm)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power Supply Type
Switching (internal)
Parameter
Consumption
Operating Current
Power linking current
(products)
Fuse
Power I/O
Power input connector
Power output connector
Power Cord plug
Type
LED
Color
Red
Green
Blue
Parameter
Beam Angle
Field Angle
Illuminance @ 2 m
Maximum External Temp.
104 °F (40 °C)
I/O Connectors
3-pin XLR
Product Name
COLORpalette™
Width Height
7 in (178 mm)
Range
100 to 240 VAC, 50/60 Hz
120 V, 60 Hz
58 W
0.4 A
8 A (16 products)
F 1.6 A, 250 V
U.S./Worldwide
IEC
Edison
Edison (U.S.)
Power
0.25 W
Quantity
96
96
96
31° x 29°
56° x 54°
1,813 lux
Cooling System
Convection
Channel Range
3, 6, 9, 15 or 27
Item Code
1031089
COLORpalette™ User Manual Rev. 4
Weight
6.2 lb (2.8 kg)
Voltage Selection
Auto-ranging
230 V, 50 Hz
60 W
0.2 A
8 A (31 products)
F 1.6 A, 250 V
UK/Europe
IEC
IEC
Local plug
Lifespan
100,000 hours
Current
20 mA
20 mA
20 mA
UPC Number
781462214371
