4. O
PERATION
Control Panel

Operation

Menu Map

DMX Linking

Configuration
(DMX)
DMX Personality
and Starting
Address
COLORpalette™ User Manual Rev. 4
To access the control panel functions, use the four buttons located underneath the display.
Please refer to the Product Overview
Button
<MODE> Press to back out of the current menu option
<ENTER> Press to activate a menu option or a selected value
<UP> Press to scroll up the list of options or to find a higher value
<DOWN> Press to scroll down the list of options or to find a lower value
Mode
DMX dxxx
Off
Static
A001–A007
Color
A008–A011
Auto
Program
A012–A024
Custom
A025 r000–r100
Color
The COLORpalette™ works with a DMX controller. Information about DMX is in the
CHAUVET® DMX Primer,
http://www.chauvetlighting.com/downloads/DMX_Primer_rev05_WO.pdf.
Set the product in DMX mode to control with a DMX controller.
1. Connect the product to a suitable power outlet.
2. Connect a DMX cable from the DMX output of the DMX controller to the DMX input
socket on the product.
When selecting a starting DMX address, always consider the number of DMX channels the
selected DMX mode uses. If you choose a starting address that is too high, you could
restrict the access to some of the product's channels.
The COLORpalette™ uses up to 27 DMX channels in a 27-CH DMX mode, which defines
the highest configurable address to 486. The DMX personality is selected by the position of
DMX channel 1.
If you are not familiar with the DMX protocol, download the DMX Primer from
www.chauvetlighting.com.
To select the starting address, do the following:
1. Press <MODE> until dxxx or Axxx shows on the display.
2. Use <UP> or <DOWN> to scroll through the menu until dxxx shows on the display.
3. Press <ENTER> and 001–485 will show on the display.
4. Use <UP> or <DOWN> to select the starting address.
5. Press <ENTER>.
to see the button locations on the control panel.
Function
Programming Steps
001–486
A000
F000–F100
P000–P100 F000–F100
P000–P100
G000–
b000–b100 F000–F100
G100
which is available
Description
Sets DMX address
No output
Static Colors and
Strobe setting
Auto programs and
Strobe and Speed settings
Auto programs and
speed setting
Custom color (red, green,
blue, and Strobe settings)
from the Chauvet website
Page 9 of 20
