HIGH-EFFICIENCY WOODSTOVE
Le Manuel de langue francais est disponible a www.vogelzang.com
READ ALL INSTRUCTIONS CAREFULLY
BEFORE INSTALLING OR OPERATING
THIS STOVE. FAILURE TO FOLLOW
INSTRUCTIONS MAY RESULT IN
PROPERTY DAMAGE, BODILY INJURY, OR
EVEN DEATH.
REFER TO MARKINGS ON STOVE LABELS
FOR ADDITIONAL INFORMATION.
SAFETY NOTICE: IF THIS STOVE IS NOT PROPERLY INSTALLED, A HOUSE/BUILDING FIRE MAY
RESULT. FOR YOUR SAFETY, CONTACT LOCAL OR MUNICIPAL BUILDING OR FIRE OFFICIALS
ABOUT PERMITS, RESTRICTIONS AND INSTALLATION REQUIREMENTS FOR YOUR AREA.
PONDEROSA
EPA Certified (3.20 grams/Hr.)
Model TR007 Owner's Manual
(Save these Instructions)
French language manual is available at www.vogelzang.com
U.S. Environmental Protection Agency
Certified to comply with 2015 particulate emissions standards.
This stove meets test standards:
US: Ul1482-2011 & CDN: ULC-S627-00
NOTE: IT IS RECOMMENDED
INSTALLATION BE COMPLETED BY
A QUALIFIED HEATING EQUIPMENT
INSTALLER!
ROOM HEATER, SOLID FUEL TYPE,
ALSO FOR USE IN MOBILE (USA ONLY)
U.S. Stove Company
227 Industrial Park Road,
P.O. Box 151
South Pittsburg, TN 37380
Phone 1-800-750- 2723
www.Vogelzang.com
852201C-1903E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PONDEROSA TR007 and is the answer not in the manual?

Questions and answers

Related Manuals for Vogelzang International PONDEROSA TR007

Summary of Contents for Vogelzang International PONDEROSA TR007

  • Page 1 PONDEROSA HIGH-EFFICIENCY WOODSTOVE EPA Certified (3.20 grams/Hr.) Model TR007 Owner’s Manual (Save these Instructions) Le Manuel de langue francais est disponible a www.vogelzang.com French language manual is available at www.vogelzang.com U.S. Environmental Protection Agency Certified to comply with 2015 particulate emissions standards. This stove meets test standards: READ ALL INSTRUCTIONS CAREFULLY US: Ul1482-2011 &...
  • Page 2 This manual describes the installation and operation of the Vogelzang, TR007 wood heater. This heater meets the 2015 U.S. Environmental Protection Agency's crib wood emission limits for wood heaters sold after May 15, 2015. Un- der specific test conditions this heater has been shown to deliver heat at rates ranging from 11,913 to 34,108 Btu/hr. Note: The BTU ratings mentioned above are based on the EPA test protocol burning dimensional Douglas Fir lumber.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS 18. During the fi rst 12 to 15 fi res. Additional smoke and odor may be emitted from the light oils used in construction of the fi re box. This should disappear after a short period of time and not occur again. Persons with lung conditions or owners of susceptible domestic pets (such as birds) should take prudent precautions.

  • Page 4: Tools And Materials Required For Installation

    ASSEMBLY INSTRUCTIONS NOTICE: Vogelzang International Corp. grants no warranty, stated or implied, for the installation or maintenance of your wood stove and assumes no responsibility of any incidental or consequential damages. TOOLS AND MATERIALS REQUIRED FOR 2. Stove may be lightened for positioning by removing fi...
  • Page 5 ASSEMBLY INSTRUCTIONS 4. After assembly, check to make sure fi re brick are properly positioned and ash clean out cover is in place. 5. Route the power cord away from stove. Do not allow the power cord to touch any hot surfaces. Keep power cord at least 12˝...

  • Page 6: Clearances - Top View

    LOCATING STOVE CLEARANCES | TOP VIEW COMBUSTIBLE CONSTRUCTION IN ACCORDANCE WITH US NFPA 211 DASHED LINES SHOW HORIZONTAL CHIMNEY CONNECTOR BACKWALL AND ADDITIONAL FLOOR PROTECTOR REQUIRED BENEATH AND EXTENDING 2"/50.8mm BEYOND 17"/ 40"/ EACH SIDE OF CONNECTOR PIPE 43.2cm 102cm 8"/21cm min.

  • Page 7: Firebrick Assembly

    LOCATING STOVE FIREBRICK ASSEMBLY Firebrick extends the life of your stove and radiates heat more evenly. Check to see that all fi rebricks are in their correct positions and have not become misaligned during shipping or assembly. If removed for ease of locating stove, fi...

  • Page 8: Connector Pipe Installation

    CONNECTOR PIPE INSTALLATION NOTE: CONNECTOR PIPE IS NOT INCLUDED. TO PURCHASE, VISIT YOUR LOCAL HARDWARE, HOME, OR BUILDING CENTER. SEE “LOCATING STOVE” PAGE 6 FOR ADDITIONAL SPECIFICATIONS. Connector pipe is used to make the connection from the final positioning of your stove to an approved chimney. Con- nector pipe is NOT included as part of the stove.

  • Page 9: Mobile Home Installation Instructions

    MOBILE HOME INSTALLATION INSTRUCTIONS 10. The chimney shall be attached directly to the room This stove is approved for mobile home installa- heater and shall extend at least 3 ft./91.4cm above tion in the USA only (DO NOT INSTALL IN MOBILE the part of the roof through which it passes.

  • Page 10: Chimney Connections

    CHIMNEY CONNECTIONS The stove must be connected to either a lined masonry or manufactured metal chimney built and tested to the specifi- cations listed on the previous pages. Chimneys perform two functions: As a means of exhausting smoke and flue gases which are the result of fuel combustion. 2.
  • Page 11 CHIMNEY CONNECTIONS MANUFACTURED CHIMNEY REFER TO CHIMNEY AND CHIMNEY CONNECTOR MAKER’S INSTRUCTIONS FOR INSTALLATION AND USE. Use only 6˝/152mm diameter manufactured chimney system listed to UL 103 HT (US) or ULC-S629 (CDN). Chimney made to this listing is High Temperature rated to 2100°F/1149°C.

  • Page 12: Fireplace Installation

    CHIMNEY CONNECTIONS CAUTION: NOT ALL FIREPLACE CHIMNEYS ARE SUITABLE FOR CONVERSION TO ACCOMMODATE CONNECTION TO A WOOD STOVE. CHECK WITH A QUALIFIED EXPERT. Many prefabricated fireplaces are of the “zeroclearance fireplace” category. These consist of multi layered metal construction. They are designed with enough insulation and/or air cooling on the base, back and sides so they can be safely installed in direct contact with combustible floors and walls.
  • Page 13 CHIMNEY CONNECTOR SYSTEMS & CLEARANCES NFPA 211 (US) NOTE: In Canada, installation must conform to CAN/CSA-B365 when passing through combustible construction. A. Brick Masonry Minimum 3.5˝/89mm thick brick masonry all framed into combustible wall with a minimum of 12˝/305mm brick separation from clay liner to combustibles.

  • Page 14: Operating Safety Precautions

    OPERATING INSTRUCTIONS CAUTION: HOUSE FIRE HAZARDS • DO NOT STORE WOOD ON FLOOR PROTECTOR, UNDERNEATH STOVEPIPE OR ANYWHERE WITHIN MINIMUM CLEARANCES FROM COMBUSTIBLE SURFACES SPECIFIED FOR THIS STOVE. • OVERFIRING MAY CAUSE A HOUSE FIRE. YOU ARE OVERFIRING IF A UNIT OR CHIMNEY CONNECTOR GLOWS RED.

  • Page 15: Optimal Fuel Consumption

    OPERATING INSTRUCTIONS NOTICE: USE SOLID WOOD MATERIALS ONLY. DO NOT BURN GARBAGE OR FLAMMABLE FLUIDS SUCH AS GASOLINE, NAPHTHA OR ENGINE OIL. DO NOT USE COAL. THIS STOVE IS NOT DESIGNED TO ACCOMMODATE THE AIR FLOW (DRAFT) NECESSARY TO PROPERLY BURN COAL OR COAL PRODUCTS. DO NOT ELEVATE FIRE OR USE GRATES OR ANDIRONS.

  • Page 16: Starting A Fire

    OPERATING INSTRUCTIONS STARTING A FIRE DO NOT LEAVE STOVE UNATTENDED WITH DOOR OPEN! The top down method of fire building is recommended for this appliance. After making sure that the stove air intake controls are fully open (completely pull-out towards you), Place the largest pieces of wood on the bottom, laid in parallel and close together.

  • Page 17: Adding Fuel

    OPERATING INSTRUCTIONS ADDING FUEL If the coal bed is not hot and glowing, rake the coals to the front of the stove, close the door and adjust the primary air inlet control to the wide open position. Let the coals re-heat for 10–15 minutes. When hot and glowing, spread them out and place your next fuel load into the stove (make sure no coals or ashes block the LPAO).

  • Page 18: Operational Tips

    CHIMNEY CONNECTIONS OPERATIONAL TIPS • Get the appliance hot and establish a good coal bed before adjusting to a low burn rate (this may take 30 minutes or more depending on your wood) • Use smaller pieces of wood during start-up and a high burn rate to increase the stove temperature •...

  • Page 19: Service Hints

    SERVICE HINTS 1. Atmospheric Pressure and Air Supply Atmospheric pressure that affects the draft may occur from outside the structure, inside the structure, or both. High pressure weather (clear and cold) usually produces a better chimney draft than low pressure (overcast and damp) conditions. Negative pressure can be created inside a home by ap- pliances that expel air from within such as bathroom vents, range hoods, clothes dryers, and forced air furnaces.

  • Page 20: Air Tubes

    SERVICE HINTS AIR TUBES The air tubes assembled in this unit are designed to provide an accurate mix of secondary air to insure the highest efficiency. Any damage or deterioration of these tubes may reduce the efficiency of combustion. The air tubes are held in position by either screws or snap pins.

  • Page 21: Glass Replacement

    SERVICE HINTS WARNING: REPLACE GLASS ONLY WITH 5MM HIGH TEMPERATURE CERAMIC GLASS OF THE PROPER SIZE. DO NOT USE SUBSTITUTE MATERIALS SUCH AS TEMPERED GLASS OR DOUBLE THICKNESS WINDOW GLASS! CONTACT THE STOVE MANUFACTURER FOR REPLACEMENT GLASS. GLASS CARE Periodic cleaning of glass will be necessary to prevent accumulations of ash. Acidic ash buildup can eventually etch and weaken glass.

  • Page 22: Wiring Diagram

    WIRING DIAGRAM CAUTION: MOVING PARTS CAN CAUSE DANGER: SHOCK HAZARD. DISCONNECT INJURY. DO NOT OPERATE WITH COVER POWER SOURCE BEFORE INSTALLATION REMOVED. AND WHENEVER SERVICING BLOWER ASSEMBLY. NOTICE: ANY REPLACE- MENT WIRING MUST HAVE E Q U I VA L E N T I N S U L A - TION AND TEMPERATURE RATING (105°C).

  • Page 23: Ordering Parts

    ORDERING PARTS When ordering missing or replacement parts, always give the Model Number of the stove, Part Number, and Part Description. Use the illustrations and part lists provided to identify parts. Contact us at 800-750-2723 to order parts.

  • Page 24: Parts List

    PARTS LIST Ref. No. Part No. Description Qty. 07-01 Stove Body 892399 Left Side Heat Shield 07-03 C-Cast, Top 07-04 Nickle Trim, Top Plate 07-05 Kao Wool Ceramic Fiber Pad 07-06 Rear Heat Shield Defl ector 07-07 Kao Wool Retainer Assembly 892409 Pedestal Base 07-09...
  • Page 25 ORDERING PARTS WG-01 GK34 CAUTION: NEVER OPERATE STOVE WITH MISSING OR CRACKED FIRE BRICKS! Part Description Qty. Firebrick, A-size (9˝ x 4.5˝ x 1.25˝) Firebrick, M-size (9˝ x 2.25˝ x 1.25˝) 3 Firebrick, XD-size (8˝ x 4.5˝ x 1.25˝) 2 Firebrick, XE-size (9˝...
  • Page 26 FLOOR PROTECTOR MATERIAL CALCULATIONS This stove has been tested for and must be installed on a floor protector with the proper Thermal Resistance or R-value as stated in step 1 of the installation instructions under “Locating Stove” section of this manual. If the floor protector ma- terials listed in the instructions are not available, materials with an equivalent R-value may be substituted.
  • Page 27 NOTES...
  • Page 28 This Vogelzang heating appliance is safe when installed properly and will provide you with years of service. However, always exercise good judgement when you are using the stove. You are dealing with FIRE! Fire is inherently danger- ous and must be treated with respect. Stay warm and in good health! THIS STOVE MAY BE INSTALLED IN A MOBILE HOMW WITH SPECIFIC INSTALLATION INSTRUCTIONS FOR SUCH USE.
