Configuration
(Standalone)

Auto Programs

Master/Slave

Virtual Color
Wheel
Color
Temperature
Manual Color
Mixer

Focus Mode

Ovation E-910FC User Manual Rev. 2
Use standalone configuration to operate the product without a DMX controller.
Auto programs allow for dynamic RGBAL color mixing without a DMX controller.
1. Go to the Auto Show main level.
2. Select the desired auto (Auto 1–5)
3. Select the desired auto program speed (1–100)
You cannot edit any of the auto programs (Auto 1–5).
The Master/Slave mode allows a group of Ovation E-910FCs (the slaves) to simultaneously
duplicate the output of another Ovation E-910FC (the master) without a DMX controller.
1. Set each of the slaves:
a. Go to the Master/Slave main level.
b. Select Slave.
2. Set the master:
a. Go to the Master/Slave main level.
b. Select Master.
·
The master is the one that runs a program whether in Auto, Virtual Color Wheel,
Color Temperature, or Manual Color Mixer modes.
·
Do not connect a DMX controller to the products configured for Master/Slave
operation. The DMX controller may interfere with signals from the master.
·
The master should be the first product in the daisy chain.
The Ovation E-910FC offers over thirty pre-mixed colors based on Rosco gel colors. To select a
Rosco gel color, do the following.
1. Go to the Virtual Color Wheel main level.
2. Select Virtual Color Wheel.
3. Select the desired Rosco color (R4590, R11, R312, R03, R18, R20, R21, R26, R27, R33,
R337, R38, R41, R42, R44, R349, R54, R64, R364, R65, R80, R81, R82, R382, R83,
R383, R90, R91, R92, R93, or R393).
See the Color Chart section for details on specific values.
The Color Temperature mode offer preset white color temperatures that emulate a tungsten
lamp at the specified color temperature.
1. Go to the Virtual Color Wheel main level.
2. Select Color Temperature.
3. Select the desired color temperature (2800K, 3200K, 3500K, 4000K, 4500K, 5000K,
5600K, 6000K, or 6500K).
See the Color Chart section for details on specific values.
The Manual Color Mixer mode allows for permanent RGBAL color mixing without a DMX
controller.
1. Go to the Virtual Color Wheel main level.
2. Select Manual Color Mixer.
3. Select the desired color (Red, Green, Blue, Amber, or Lime).
4. Select the color value (000–255).
5. Repeat for the other colors.
Focus mode allows for focusing of the Ovation E-910FC without changing any menu settings.
1. Press and hold <ENTER> for 3 seconds. The intensity will increase to 100%.
2. Press <MENU> to exit to previous settings.
Operation
-13-
