KEDACOM
User Manual for HD IP Camera of
IPC Series
Version 02

Advertisement

Table of Contents
loading

Related Manuals for Kedacom IPC Series

Summary of Contents for Kedacom IPC Series

  • Page 1 KEDACOM User Manual for HD IP Camera of IPC Series Version 02...

  • Page 2: 2015 Suzhou Keda Technology Co., Ltd. All Rights Reserved

    Trademark Kedacom™ and are trademarks of Suzhou Keda Technology Co., Ltd. in China and various other countries. All other trademarks mentioned in this document are the property of their respective holders. Suzhou Keda Technology Co., Ltd. 131 Jinshan Road New District, Suzhou, 215011 People's Republic of China http://www.kedacom.com/en...

  • Page 3: Target Audience

    warranty of any kind, express or implied. Suzhou Keda Technology Co., Ltd. is not responsible for printing or clerical errors. Target Audience Administrators and Operators of Video Surveillance Products Document Version Version 02 Applicable Models IPC113 series, IPC123 series IPC2151 series, IPC2251 series IPC2152 series, IPC2252 series IPC2110 series, IPC2210 series IPC2111 series, IPC2211 series, IPC2411 series...

  • Page 4: Table Of Contents

    Contents © 2015 Suzhou Keda Technology Co., Ltd. All rights reserved............2 Notice ............................... 2 Target Audience ............................3 Product Brief ........................... 1 Appearance ............................. 2 Start Up ............................3 Client Installation Conditions ....................3 Initial Configuration ......................3 3.2.1 Modify Parameter ......................
  • Page 5 4.4.4 Abnormality Linkage ....................16 Privacy Mask ........................16 4.5.1 Set Area ........................17 4.5.2 Clear Area........................17 4.5.3 Disable Function ......................17 Encoding Clipping ......................17 4.6.1 Set Area ........................18 4.6.2 Clear Area........................18 ROI ............................. 18 4.7.1 Set Area ........................
  • Page 6 5.4.1 User Management ..................... 26 5.4.2 IP Filter ........................26 Text Overlay ........................27 Multi-stream ........................28 Appendix: Glossary of Terms ...................... 31...

  • Page 7: Product Brief

    HD IP Camera User Manual Product Brief HD IP Camera (hereinafter referred to as Camera) is a remote video surveillance device based on IP network technology. It encodes and transmits HD video. Some features of the HD IP camera: Live View Apply high-performance progressive scan sensor, with clear image and vivid color;...

  • Page 8: Appearance

    HD IP Camera User Manual Appearance Picture 2-1 IPC113 and IPC123 series Picture 2-2 IPC2151 and IPC2251 series Picture 2-3 IPC2152 and IPC2252 series Picture 2-4 IPC2110 and IPC2210 series Picture 2-5 IPC2111/ IPC2211/ IPC2411 series...

  • Page 9: Start Up

    Start Up Please refer to the Quick Start Guide in the packing for device installation and wiring. 3.1 Client Installation Conditions Requirements of PC for installing the client: Operating System: Windows XP or newer versions Browser: IE7.0 and above versions, Firefox, Google Chrome (41 and below) Processor: 3.3 GHz CORE®i3 series or other equivalent processors RAM Memory: 4GB or above DirectX：9.0c...
  • Page 10 Picture 3-2 Batch processing Select a camera to be configured, click “Modify Params” or right click the mouse. Interface is shown in Picture 3-3. During the modification, the user name (admin) and the password set before activation should be entered. Picture3-3 Modify Parameter...

  • Page 11: Login Web Client

    3.2.2 Login Web Client After modification, camera will reboot automatically. Please wait patiently. After reboot, the button will be enabled again. Please select this device again and click “Login” or double click device name to enter web client. Interface is shown in Picture 3-4.

  • Page 12: Focus

    Picture 3-6 Web Client Interface 3.2.3 Focus It is the process of imaging the target object clearly. Please focus according to the lens type of camera: Mechanical Focus: View live video on web client and adjust the focus knob on the lens till the image is clear enough.
  • Page 13 Picture 3-7 Focus...

  • Page 14: Product Functions

    Product Functions By the web client, user can not only view live video, but also perform local snapshot and recording. Note: Functions of different cameras may differ, and this Manual will take camera with more functions as example. User operation is subject to the actual functions of the model. Disabled button in Web Client means the model doesn’t support the function.
  • Page 15 Recording Click this button to start recording and click again to stop recording. Recording is saved on local PC. User can set or modify save path in Settings>Local. Note: 1) Camera Snapshot: Camera snapshots an image and sends it to local client in .JPG format.

  • Page 16: Image Adjustment

    screen. Left click and drag toward upper left to draw an area, then image will recover. Click the button to zoom. Left click and drag toward lower right to draw an area. The pixels of this area will be amplified and will cover the whole screen. Left click and drag toward upper left to draw an area, then the image will recover.
  • Page 17 Note: However, the higher the gain is, the worse the image will be. User is advised to select Auto for default values, or select Auto and set Gain Upper Limit in Settings>Camera>Image. If user selects “Manual”, drag the slide bar to adjust gain level. *Enable WDR WDR can provide optimal exposure in intense backlight conditions.

  • Page 18: Auxiliary Function

    In this mode, camera switches to day/night mode automatically in a specified period of time. When select Scheduled Day/Night mode, click Edit Time, and check Start Time and End Time in the popup interface. Alarm Triggered Cut In this mode, night cut is triggered by alarm input. 4.1.2.4 Noise Reduction When there are many noise points caused by environment and camera lens,...

  • Page 19: Set Area

    Picture 4-3 Motion Detection 4.2.1 Set Area Motion detection supports full area detection and maximum 4 user-defined areas. Go to Settings>Event>Video Analysis>Motion Detection, check “Enable”. Click “Edit” and the image will be divided into 16 columns and 12 rows of squares. Click a square and drag an area from it, then the area will turn purple and is the motion detection area.

  • Page 20: Alarm Linkage

    Picture 4-4 Shield Area Alarm 4.4 Alarm Linkage Alarm Linkage is the system reaction after an alarm signal is received. It is to raise watch man’s attention to handle the event. The alarm signal comes from Motion Detection (details in Chapter 4.2) or Alarm Input Device (such as smoke detector) in the surveillance area.

  • Page 21: Motion Detection Alarm Linkage

    4.4.1 Motion Detection Alarm Linkage Enable Motion Detection, and set the detection area and sensitivity. Please refer to Chapter 4.2 Motion Detection for details. Check the Linkage Type for motion detection. For example, if user checks Snapshot, when alarm is triggered, the system will take a snapshot. In Settings>Storage>Snapshot interface, user can set picture format, resolution, interval and quantity.

  • Page 22: Abnormality Linkage

    Make sure the alarm input device is always enabled or disabled, and that it is rightly connected to the alarm input port of camera. Go to Settings>Event>Alarm Input, and select an alarm input ID from the dropdown list (in accordance with the alarm input port). Input alarm name, and select “Always Enabled”...

  • Page 23: Set Area

    Picture 4-7 Privacy Mask 4.5.1 Set Area The image is divided into 16 columns and 12 rows of small squares. The maximum number of Privacy Mask area is 4. Go to Settings>Camera>Video >Privacy Mask, and check “Enable”. Click “Edit”, and the image is divided into 16 columns and 12 rows of small squares. Click any square and drag an area from this square, then this area is the privacy mask area, which is in purple red.

  • Page 24: Set Area

    Picture 4-8 Encoding Clipping 4.6.1 Set Area Go to Settings>Camera>Video >Encoding Clipping, and check “Enable”. Click “Edit”, and drag an area as the clipping area. Click “Save” to make settings effective. 4.6.2 Clear Area Click “Clear” to clear edition and reset area. 4.7 ROI Only encode specific area to ensure normal surveillance and constant resolution of key area under poor network.

  • Page 25: Set Area

    4.7.1 Set Area Go to Settings>Camera>Video >ROI, and check “Enable”. Click “Edit”, and drag an area as the clipping area. Select encoding grade from the dropdown list. Click “Save” to make settings effective. 4.7.2 Clear Area Click “Clear” to clear edition and reset area. Note: When ROI Encode is enabled, if user modifies image resolution or aspect ratio (standard screen/widescreen), the device will quit ROI Encode automatically.

  • Page 26: Snapshot

    When user wants to set resolution as 1080i, please go to Settings>Camera>Image>Image Quality, and select “Interlacing (same as main stream resolution)” in Rotate and BNC part. Picture 4-11 Image Quality 4.9 Snapshot Click “Snapshot” to enter snapshot management interface. User can view or download snapshots in SD card.

  • Page 27: Playback

    Note: User can set recording durations in Settings>Storage>Recording. Check “Enable” and click “Edit” to set durations. Picture 4-12 Recording 4.10.1 Playback Select recording duration from the calendar. If there is background color on a date, it means there is recording on that day. Select duration of the date and the video will be displayed directly in the right window.
  • Page 28 Go to Settings>System>System Maintenance>Upgrade, as shown in Picture 4-13. Picture 4-13 Firmware Upgrade Select local upgrade file (<*.pkg> or <*.img> format). During upgrading, please do nothing but waiting. After upgrading, please download ActiveX control again. After finishing it, reboot browser. Note: Please click “Upgrade”...

  • Page 29: Web Client Upgrade

    Method 2 Run IPCSearch. Click “Upgrade” to upgrade firmware of cameras of the same model simultaneously. 4.11.2 Web Client Upgrade After firmware upgrade, please login web client again. The page will prompt to download a new ActiveX control. After downloading it, client upgrade will be completed.

  • Page 30: Settings

    Settings 5.1 Network Access 3.2 Initial Configuration has introduced how to modify parameters via IPCSearch to make camera access network. Camera accepts multiple network access methods (via Ethernet and PPPoE). The following introduces how to configure camera network parameters in Web Client.

  • Page 31: Register To Vms

    Picture 5-2 PPPoE Setting 5.2 Register to VMS Go to Settings>Network>Access Protocol>VSIP, as shown in Picture 5-3 to enter VMS address and port. Save settings and reboot device. Picture 5-3 Register to VMS 5.3 BNC Output Camera with BNC output can output analog image directly when local display function is enabled.

  • Page 32: User Security

    Picture 5-4 BNC Output Note: For cameras with HD-SDI output, when BNC is enabled, the web client will stop image output. 5.4 User Security 5.4.1 User Management Go to Settings>System>User Security>User. Add: Click “Add”, and enter user name and password in the popup interface. Select user type from the dropdown list, and assign operation rights to newly added user from the Authorization List.

  • Page 33: Text Overlay

    Enable IP Filter: Select filter method from the dropdown list according to request, or select “Disable” to disable IP filter. Add Black/White List: After select filter method, click “Add” and input IP address in the popup interface, and click “Confirm”. Modify Black/White List: Select the IP address from the list and click “Modify”...

  • Page 34: Multi-Stream

    Edit OSD texts: for example, if user checks OSD1, double click OSD1 textbox and input characters in the popup interface. Click “OK”. Click “Save” to save OSD setting. Click “Load” to load default font or China GB font. Click “Advanced” to set “Format”, “Font” and “Margin”. Picture 5-6 Advanced Setting of OSD 5.6 Multi-stream Camera supports multiple streams encoding and decoding.
  • Page 35 Picture 5-7 Advanced Configuration Click “Save” and reboot camera to make setting take effect. After reboot, re-login; Go to Settings>Camera>Video>Encoding Format, as shown in Picture 5-8. In Multi-stream option, select Single Stream, Dual-stream, Triple-stream or Quad-stream from the dropdown list, and the selection takes effect after reboot. After enable, user can set parameters below the option accordingly.
  • Page 36 Picture 5-8 Stream Type...

  • Page 37: Appendix: Glossary Of Terms

    Appendix: Glossary of Terms Term Explanation 720P Resolution of 1280*720 pixels Resolution of 352*288 pixels QCIF Resolution of 176*144 pixels Region Of Interest Key Frame defines the important frame when change happens in a video. This frame will be completely Key Frame encoded.
