Kedacom LC Series User Manual

Hd ip camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
KEDACOM
User Manual for HD IP Camera of
LC Series
Version 01

Advertisement

Table of Contents
loading

Related Manuals for Kedacom LC Series

Summary of Contents for Kedacom LC Series

  • Page 1 KEDACOM User Manual for HD IP Camera of LC Series Version 01...
  • Page 2 Trademark Kedacom™ and are trademarks of Suzhou Keda Technology Co., Ltd. in China and various other countries. All other trademarks mentioned in this document are the property of their respective holders. Suzhou Keda Technology Co., Ltd. 131 Jinshan Road New District, Suzhou, 215011 People's Republic of China http://www.kedacom.com/en...
  • Page 3 Target Audience Administrators and Operators of Video Surveillance Products Document Version Version 01 Applicable Models LC2150 series, LC2250 series, LC2110 series, LC2210 series, LC211 series, and LC2240 series Related Document Quick Start Guide for LC2110 & LC2210 Quick Start Guide for LC2150 & LC2250 Quick Start Guide for LC211 LC2240 Convention Icon...

  • Page 4: Table Of Contents

    Contents Product Brief ........................... 1 Appearance .......................... 1 Main Functions ........................2 Start Up ............................3 Client Installation Conditions ....................3 Initial Configuration ......................3 Product Functions .......................... 6 Live View ..........................6 3.1.1 Toolbar Buttons on Main Menu ..................6 3.1.2 Image Adjustment ......................
  • Page 5 3.8.1 Firmware Upgrade ..................... 13 3.8.2 IPCCtrl Upgrade ......................14 Parameter ............................15 Network Access ......................... 15 4.1.1 Ethernet ........................15 4.1.2 PPPoE ........................15 Register to VMS ......................... 15 *BNC Output ........................16 User Management ......................17 Text Overlay ........................17 Camera Mode ........................

  • Page 6: Product Brief

    HD IP Camera User Manual Product Brief HD IP Camera (hereinafter referred to as Camera) is a remote video surveillance device based on IP network technologyofindependent research and development of Suzhou Keda Technology Co., Ltd. It encodes and transmitsHD video. Also, itcan be deployed at any point of a surveillance network and transmits videos via public or private IP network.

  • Page 7: Main Functions

    HD IP Camera User Manual 1.2 Main Functions Live View Apply high-performance progressive scan sensor, with clear image and vivid color; High-performance video processing chip and efficient video encoding, providing HD video; Dual-stream to fit different network bandwidth; Configurable text overlay on video IRIllumination Built-in IR illumination module to better satisfy different video surveillance requirements Networking...

  • Page 8: Start Up

    Start Up Please refer to the Quick Start Guide in the packing for device installation and wiring. 2.1 Client Installation Conditions Requirements of PC for installing the client: Operating System: Windows XP or newer versions Browser: IE6.0 or newer versions Processor: 2.0 GHz CORE®2 series or other equivalent processors RAM Memory: 2GB or above DirectX：9.0c...
  • Page 9 Picture2-2Modify Parameter After modification, will be disabled and the device will reboot automatically. Please wait patiently. After reboot, the button will be enabled again. Please select this device again and click or double click device name to enter web client. Interface is shown in Picture 2-3. Picture2-3IPCCtrl Login Interface Enter user name and password: IPCCtrlaccounts consist of bothadmin and guest users:...
  • Page 10 Interface after login is shown in Picture 2-4. Picture2-4IPCCtrl Interface...

  • Page 11: Product Functions

    Product Functions IPCCtrl can not only view live video, but also perform local snapshot and recording. Note: Functions of different cameras may differ, and this Manual will take camera with more functions as example. User operation is subject to the actual functions of the model. Disabled button in IPCCtrl means the model doesn’t support the function.

  • Page 12: Image Adjustment

    Notes: PU Snapshot: PU Snapshots an image and sends it to local client in .JPG format. The image quality is good, but there is some time delay caused by network. Local Snapshot: Client snapshots an image and save it locally. The image quality is ordinary, but there isn’t any time delay.
  • Page 13 In Image Adjustment part, user can drag Brightness slide bar to adjust image brightness. Or, enable Camera Mode to make camera transfer to preset value in a defined period of time. Slower Shutter Speed Camera shutter speed means the cycle of the sensor calculating light input amount.
  • Page 14 3.1.2.3 Day/Night Mode Day (Night) Mode means disabling (enabling) IR lamp, and the image shifts to color (B/W), thus to get optimal images for day (sufficient light source) and night (insufficient light source) conditions. Note: When a device without IR lamp enables Night Mode means the image shifts to B/W. Day Mode On Page 1 of function buttons, click (Day Mode) to disable IR lamp and...

  • Page 15: Motion Detection

    Also, user can set Focus, Shutter and other parameter as Auto alone. 3.1.2.6 Video Freeze On Page 5 of function buttons, select this function and the video will display the last frame image before clicking. Click to disable freeze. 3.1.2.7 Drag to Zoom Definition: Drag to Zoom function centers the selected area and zooms in the area to full screen.

  • Page 16: Clear Area

    Check Parameter>Video Parameter>Intelligent Alarm to set motion detection area. Check Enable Intelligent Alarm, and select Motion Detection. Detection area can be full area or specific area. If user selects specific area, the user should define detection area on the below image. Click a squareand it will turn purple red.

  • Page 17: Roi Encode

    In the interface Parameter>Video Parameter>Clipping Area Encode, drag an area with mouse, click under the view window or click to reset the area. 3.5 ROI Encode Only encode specific area to ensure normal surveillance and constant resolution of key area under poor network.

  • Page 18: Playback

    Picture3-4Recording 3.7.1 Playback Select Recording Duration from Calendar. If there is background color on a date, it means there is recording on that day. Select duration of the date and the video will be displayed directly in the right window. 3.7.2 Download Select Recording Duration from calendar and download recording to local PC,...

  • Page 19: Ipcctrlupgrade

    Picture3-5Firmware Upgrade Select local upgrade file (<*.pkg> or <*.img> format). During upgrading, please do nothing but waiting. After upgrading, please download ActiveX control again. After finishing it, reboot browser. Note: Please click “Upgrade” during system upgrading, and the upgrade file is usually in <*.pkg> or <*.img> format.

  • Page 20: Parameter

    Parameter 4.1 Network Access 2.2 Initial Configuration has introduced how to modify parameters via IPCSearch to make camera access network. Camera accepts multiple network access methods (via Ethernet and PPPoE). The following introduces how to configure camera network parameters in IPCCtrl. 4.1.1 Ethernet Open Parameter>Network Setting>Ethernet Parameter, as shown in Picture 4-1 to...

  • Page 21: Bnc Output

    Picture4-3Register to VMS 4.3 *BNC Output Camera with BNC output can output analog image directly when local display function is enabled. Open Parameter>Video Parameter>Camera Parameter, select ‘Start’ from the BNC Output drop-down list and set the CVBS Video Mode, as shown below. Picture4-4BNC Output...

  • Page 22: User Management

    4.4 User Management Admin user has the authorization to modify passwords of IPCCtrl admin user and guest user. Modification method: Open Parameter>System Setting>User Management Check the checkbox of the item to be modified, the password area will be enabled and editable. Enter new password.

  • Page 23: Camera Mode

    Picture4-5Text Overlay 4.6 Camera Mode Open path: Parameter>Video Parameter>Camera Mode After enabling Camera Mode, user can define maximally 8 different non-overlapping durations, and all parameters will be adjusted to the preset values automatically. 4.6.1 Configure Parameter 4.6.1.1 Night Mode After enabling this function, device will shift toNight Mode in the defined duration automatically.

  • Page 24: Import/Export Configuration

    Picture4-6Camera Mode 4.6.2 Import/Export Configuration After completing configuration of camera mode, click to export and save the configuration; click to import local configuration file instead of manual configuration. 4.7 Dual-Stream Camera supports dual-stream encoding. Dual-stream means the same video source is encoded in 2 streams of video with different resolutions.
  • Page 25 Picture4-7Main Stream Encoding Note: For detailed operation instructions of the client IPCCtrl, please refer to the help document.

  • Page 26: Appendix: Glossary Of Terms

    Appendix: Glossary of Terms Term Explanation 720P Resolution of 1280*720 pixels Resolution of 352*288 pixels QCIF Resolution of 176*144 pixels Periphery Unit, such as camera and encoder used for video surveillance Region Of Interest Key Frame Key Frame defines the important frame when change Interval happens in a video.
