- Page 1 KEDACOM User Manual for HD IP Camera of IPC121-Ei7N-X120 Series Version 02...
-
Page 2: 2015 Suzhou Keda Technology Co., Ltd. All Rights Reserved
Trademark Kedacom™ and are trademarks of Suzhou Keda Technology Co., Ltd. in China and various other countries. All other trademarks mentioned in this document are the property of their respective holders. Suzhou Keda Technology Co., Ltd. 131 Jinshan Road New District, Suzhou, 215011 People's Republic of China http://www.kedacom.com/en... -
Page 3: Target Audience
warranty of any kind, express or implied. Suzhou Keda Technology Co., Ltd. is not responsible for printing or clerical errors. Target Audience Administrators and Operators of Video Surveillance Products Document Version Version 02 Applicable Models IPC121-Ei7N-X120 series Related Document Quick Start Guide Convention Icon Convention... -
Page 4: Table Of Contents
Contents © 2015 Suzhou Keda Technology Co., Ltd. All rights reserved............2 Notice ............................... 2 Target Audience ............................3 Product Brief ........................... 1 Appearance ............................. 2 Start Up ............................3 Client Installation Conditions ....................3 Initial Configuration ......................3 3.2.1 Modify Parameter ...................... - Page 5 4.4.3 Disable Function ......................19 Alarm Linkage ........................19 4.5.1 Motion Detection Alarm Linkage ................20 4.5.2 Tempering Alarm Linkage ..................20 4.5.3 Alarm Input Linkage ....................20 4.5.4 Abnormality Linkage ....................21 Privacy Mask ........................22 4.6.1 Set Area ........................22 4.6.2 Clear Area........................
- Page 6 Text Overlay ........................30 Multi-stream ........................32 Appendix: Glossary of Terms ...................... 33...
-
Page 7: Product Brief
User Manual Product Brief IPC121-Ei7N series (hereinafter referred to as Camera) are 2MP intelligent feature-recognitive cameras based on IP network technology. It supports max resolution of 1920x1080, snapshot of moving targets, snapshots of people/vehicle/object, and snapshot abstraction by color, size and speed. -
Page 8: Appearance
HD IP Camera User Manual Appearance Picture 2-1 IPC121-Ei7N series... -
Page 9: Start Up
HD IP Camera User Manual Start Up Please refer to the Quick Start Guide in the packing for device installation and wiring. 3.1 Client Installation Conditions Requirements of PC for installing the client: Operating System: Windows XP or newer versions Browser: IE7.0 and above versions, Firefox, Google Chrome (41 and below) Processor: 3.3 GHz CORE®i3 series or other equivalent processors RAM Memory: 4GB or above... - Page 10 HD IP Camera User Manual Picture 3-2 Batch processing Select a camera to be configured, click “Modify Params” or right click the mouse. Interface is shown in Picture 3-3. During the modification, the user name (admin) and the password set before activation should be entered. Picture3-3 Modify Parameter...
-
Page 11: Login Web Client
HD IP Camera User Manual 3.2.2 Login Web Client After modification, camera will reboot automatically. Please wait patiently. After reboot, the button will be enabled again. Please select this device again and click “Login” or double click device name to enter web client. Interface is shown in Picture 3-4. -
Page 12: Focus
HD IP Camera User Manual Picture 3-6 Web Client Interface 3.2.3 Focus It is the process of imaging the target object clearly. Please focus according to the lens type of camera: Mechanical Focus: View live video on web client and adjust the focus knob on the lens till the image is clear enough. - Page 13 HD IP Camera User Manual Picture 3-7 Focus...
-
Page 14: Product Functions
HD IP Camera User Manual Product Functions By the web client, user can not only view live video, but also perform local snapshot and recording. Notice: Disabled button in Web Client means the model doesn’t support the function. Functions with “*” mean only some models support. 4.1 Live View The default interface after user login is live video view, or user can click Live View to enter the interface. - Page 15 HD IP Camera User Manual Click this button to start recording and click again to stop recording. Recording is saved on local PC. User can set or modify save path in Settings>Local. Notice: 1) Camera Snapshot: Camera snapshots an image and sends it to local client in .JPG format.
-
Page 16: Image Adjustment
HD IP Camera User Manual Click this button to enable the e-PTZ function. Left click and drag toward lower right to draw an area. The pixels of this area will be amplified and will cover the whole screen. Left click and drag toward upper left to draw an area, then image will recover. - Page 17 HD IP Camera User Manual Upper Limit in Settings>Camera>Image. If user selects “Manual”, drag the slide bar to adjust gain level. *Enable WDR WDR can provide optimal exposure in intense backlight conditions. Go to Settings>Camera>Image>Image Enhancement, enable WDR in the drop-down list of Dynamic Adjustment and drag the WDR Sensitivity slide bar to adjust.
-
Page 18: Intelligent Display
HD IP Camera User Manual Alarm Triggered Cut In this mode, night cut is triggered by alarm input. 4.1.2.4 Noise Reduction When there are many noise points caused by environment and camera lens, Noise Reduction function can be enabled to adjust images. Go to Settings>Camera>Image>Image Enhancement, enable 3D Noise Reduction. - Page 19 HD IP Camera User Manual Picture 4-4 Toolbar buttons on intelligent display interface Notice: Some buttons are the same as those in the live view interface on main menu, so we will not explain again. Please refer to 4.1.1 for detailed explanation. Stop Click this button to stop live view.
-
Page 20: Intelligent Settings
HD IP Camera User Manual Picture 4-5 Path settings 4.3 Intelligent Settings To ensure that the recognitive camera could capture people’s head and body, we need to login to the web client and configure some parameters. 4.3.1 Calibration Setting Go to Intelligent> Intelligent> Calibration, the calibration setting interface is shown below: Picture 4-6 Calibration setting Calibration setting steps: 1) Check “Enable”. - Page 21 HD IP Camera User Manual [Notice]: 1. Choose adults of the same or similar height(s); 2. Pedestrians’ positions should be as scattered as possible such as at the top, the bottom, the left, the right or the middle of the image; 3.
-
Page 22: Guard Area Setting
HD IP Camera User Manual Picture 4-8 Improper calibration 5) If you want to delete a calibration line segment, select the line segment and click “Delete”. 6) Set “Reference Height” (cm) as required. For example, if it is set 170, the reference height of targets is 170cm. -
Page 23: Shield Area Setting
HD IP Camera User Manual Picture 4-9 Guard area setting [Notice]: 1. Guard areas can overlap with each other. The neighboring guard areas are better overlapped to enable seamless surveillance and ensure continuous tracking; 2. The set guard area should be larger than the actual guard area to avoid target missing; 4.3.3 Shield Area Setting Shield area is one or more polygon areas set in the surveillance image to mark areas where... -
Page 24: Motion Detection
HD IP Camera User Manual Picture 4-10 Shield area setting [Notice]: 1. When there are lots of uninterested moving objects in the guard areas, you can add shield areas inside the guard areas and the shield area could be larger than the uninterested area; 2. -
Page 25: Set Area
HD IP Camera User Manual Picture 4-11 Motion Detection 4.4.1 Set Area Motion detection supports full area detection and maximum 4 user-defined areas. Go to Settings>Event>Video Analysis>Motion Detection, check “Enable”. Click “Edit” and the image will be divided into 16 columns and 12 rows of squares. Click a square and drag an area from it, then the area will turn purple and is the motion detection area. -
Page 26: Motion Detection Alarm Linkage
HD IP Camera User Manual The alarm signal comes from Motion Detection (details in 4.4 Motion Detection) or Alarm Input Device (such as smoke detector) in the surveillance area. Alarm Linkage reaction includes Alarm Text Overlay, Snapshot or triggering alarm output device (such as alarm bell). -
Page 27: Abnormality Linkage
HD IP Camera User Manual Picture 4-12 Alarm Input Make sure the alarm input device is always enabled or disabled, and that it is rightly connected to the alarm input port of camera. Go to Settings>Event>Alarm Input, and select an alarm input ID from the dropdown list (in accordance with the alarm input port). -
Page 28: Privacy Mask
HD IP Camera User Manual Picture 4-13 Abnormality Linkage Check “Enable”. Select Abnormality Type from the dropdown list. Check “Linkage Method”. Click “Save”. 4.6 Privacy Mask Mask sensitive and private part of the image so as to keep sensitive information private. Picture 4-14 Privacy Mask 4.6.1 Set Area... -
Page 29: Clear Area
HD IP Camera User Manual Go to Settings>Camera>Video >Privacy Mask, and check “Enable”. Click “Edit”, and the image is divided into 16 columns and 12 rows of small squares. Click any square and drag an area from this square, then this area is the privacy mask area, which is in purple red. -
Page 30: Playback
HD IP Camera User Manual Picture 4-15 Recording 4.8.1 Playback Select recording duration from the calendar. If there is background color on a date, it means there is recording on that day. Select duration of the date and the video will be displayed directly in the right window. - Page 31 HD IP Camera User Manual Picture 4-16 Firmware Upgrade Select local upgrade file (<*.pkg> format). During upgrading, please do nothing but waiting. After upgrading, please download plug-in control again. After finishing it, reboot browser. Notice: Please click “Upgrade” when upgrading, and the upgrade file is usually in <*.pkg>...
-
Page 32: Web Client Upgrade
HD IP Camera User Manual 4.9.2 Web Client Upgrade After firmware upgrade, please login web client again. The page will prompt to download a new plug-in control. After downloading it, client upgrade will be completed. Login again to enter the latest Web Client. Notice: For detailed operation instructions of Web Client, please refer to the help document. -
Page 33: Settings
HD IP Camera User Manual Settings 5.1 Network Access 5.1.1 Ethernet Go to Settings>Network>IP and Port>IP Address, as shown in Picture 5-1 to configure IP address, subnet mask and default gateway. Picture 5-1 Ethernet Parameter 5.1.2 PPPoE Go to Settings>Network>Other Protocols>PPP E, as shown in Picture 5-2 to enter user name and password, and save. -
Page 34: Register To Dpss
HD IP Camera User Manual Picture 5-2 PPPoE Setting 5.2 Register to DPSS DPSS is used to store images and analyze intelligent data. It is an onvif-supported server for storing and getting intelligent data. Currently, DPSS can be used to manage the storage camera snapshots and intelligent analysis data. -
Page 35: Register To Vms
HD IP Camera User Manual Picture 5-4 DPSS settings Check “Enable” and input DPSS address and port. Click “Save”. Notice: DPSS setting is necessary only when there is EZVIEW VMS in the whole system. It’s unnecessary for other VMS. 5.3 Register to VMS Go to Settings>Network>Access Protocol>VSIP, as shown in Picture 5-5 to enter VMS address and port. -
Page 36: User Security
HD IP Camera User Manual 5.4 User Security 5.4.1 User Management Go to Settings>System>User Security>User. Add: Click “Add”, and enter user name and password in the popup interface. Select user type from the dropdown list, and assign operation rights to newly added user from the Authorization List. - Page 37 HD IP Camera User Manual Picture 5-6 OSD Check the options and preview the result in the window. For example, if user checks “Time”, time will be displayed in the window. Edit positions: drag the items in the window with mouse to change their positions. Edit OSD texts: for example, if user checks OSD1, double click OSD1 textbox and input characters in the popup interface.
- Page 38 HD IP Camera User Manual 5.6 Multi-stream Camera supports multiple streams encoding and decoding. Multi-stream means the same video source is encoded into different streams of videos with different resolutions. User can select proper resolution to view or record according to the network bandwidth. Operation steps: Go to Settings>System>System Maintenance;...
- Page 39 HD IP Camera User Manual Appendix: Glossary of Terms Term Explanation 1080P Resolution of 1920*1080 pixels 720P Resolution of 1280*720 pixels High definition Network Address Translation DDNS Dynamic Domain Name Server DHCP Dynamic Host Configuration Protocol Internet Protocol MPEG4 Moving Pictures Experts Group Resolution of 352*288 pixels QCIF Resolution of 176*144 pixels...
