VJ-1628TD, VJ-2628TD OPERATION MANUAL
4.5

Changing ink setting modes

NOTE
• To change the ink color combination, contact your local MUTOH dealer.
• Do not perform the following operations during ink filling.
• Do not turn OFF the printer.
• Do not unplug the power cable.
• Do not open the front cover.
• Do not raise the media loading lever.
This section explains how to change the number of ink colors.
The following ink setting modes can be used for this printer.
• Eight color ink mode
• Six color ink mode
• Different types of inks four color mode (4Color Single: setting ink cartridges of two different types,
each having different ink characteristic)
• Same types of inks four color mode (4Color Double)
Refer to the following table for the ink cartridge alignment.
• "-A" and "-B" in the following table indicate the difference of ink types according to their ink
characteristics.
Slot No.
1
2
3
4
5
6
7
8
Follow the procedures below.
1. Perform a head cleaning.
5.1.17 Longstore menu
Eight color ink Six color ink
K (Black) K (Black)
C (Cyan) C (Cyan)
M (Magenta) M (Magenta)
Y (Yellow) Y (Yellow)
SP1 (Special color 1) SP1 (Special color 1) K-B (Black B)
SP2 (Special color 2) SP2 (Special color 2) C-B (Cyan B)
SP3 (Special color 3) Cleaning cartridge
SP4 (Special color 4) Cleaning cartridge
Different types of
four ink colors
K-A (Black A)
C-A (Cyan A)
M-A (Magenta A)
Y-A (Yellow A)
M-B (Magenta B)
Y-B (Yellow B)
4-33
4 Handling the printer
Same types of four
ink colors
K-A (Black A)
C-A (Cyan A)
M-A (Magenta A)
Y-A (Yellow A)
K-A (Black A)
C-A (Cyan A)
M-A (Magenta A)
Y-A (Yellow A)
