Team C Patron Instruction Manual page 9

10
Steering Servo
Lenkservo
B
-
Bag
TS4021 M3x8
I
-
Bag
B
-
11
Buffer
Bag
Lenkung
TR4049
Servo Saver Body
Servo Saver Gehäuse
TR4012
Servo Saver-Top
Servosaver oben
T02059
Ball stud-Long
Kugelkopf lang
T02059 Ball stud-Long
Kugelkopf lang
............3
TR4060 M3 Screw
M3 Schraube
............2
ESC
Regler
T02059
Ball stud-Long
Kugelkopf lang
TR4012
Servo Saver-Bottom
Servo Saver unten
TR4049
Servo Saver Spring
Servo Saver Feder
TR4049
Servo Saver Nut
Servo Saver Mutter
Receiver
Empfaenger
T02087
Double-sided tape
Doppelseitiges Klebeband
TS4021
Electronic equipment mount
Electronic Platte
TR4058 M3x8
TR4060 M3
Approx 5mm
Ca.5mm
5
TR4058/TS4021 M3x8 Screw
M3x8 Schraube
..................7
TR4012
Servo Saver-left
Servo Saver links
TR4013
Steering Rack
Lenkstange
T02059
Ball stud-Long
Kugelkopf lang
TR4060 M3
