Team C TS4 Manual

1:10 scale radio 4wd electric short-course
Hide thumbs

Advertisement

Quick Links

Download this manual
1:10 Scale Radio 4wd electric
short-course
Length
......................................................................................................515mm
Width
......................................................................................................290mm
Height
......................................................................................................160mm
All manuals and user guides at all-guides.com
TS4

Advertisement

loading

Related Manuals for Team C TS4

Summary of Contents for Team C TS4

  • Page 1 All manuals and user guides at all-guides.com 1:10 Scale Radio 4wd electric short-course Length …………………………………………………………………………………………515mm Width …………………………………………………………………………………………290mm Height …………………………………………………………………………………………160mm...

  • Page 2: Transmitter Preparation

    All manuals and user guides at all-guides.com Transmitter Preparation 27MHzTransmitter Crystal Power Switch Antenna Transmitter crystal(TX) Receiver crystal(RX) Extend the antenna to the maximum Length for best performance The crystal can be replaced to change frequencies. Note : You must also change receiver crystals! Do not use AM crystals Battery Level Indicator Good Batteries...

  • Page 3: Tools Required

    All manuals and user guides at all-guides.com Transmitter Preparation A new Ni-MH battery must be charged before it is used.Refer to the charger instruction manual for charging. Set up the radio control system as indicated below Motor Battery Electronic Speed Controller Transmitter Switch...
  • Page 4 All manuals and user guides at all-guides.com TR4010 Chassis TS4044 Rear Arm Mount-Rear Upper deck column Upper TS4015 TS4044 Right Side plate-R Upper deck column Below TS4015 Left Side plate-R TS4022 Battery mount TS4028 TS4015 Chassis Right Side plate-F TR4058 M3x10 TR4058 TR4058 M3x10...
  • Page 5 All manuals and user guides at all-guides.com Diff TS4039 16T gear TS4040 3.0 E-ring TS4039 Diff shaft TS4039 5.1x13x0.2 TS4040 3.0 ………………………3 TS4039 5.1x13x0.2 Washer T04040 4.8x1.6 …………………3 T04040 4.8x1.6 O-ring T04040 Diff housing TS4039 ……………………3 10T gear T02099 10x15x4 Ball Bearing ……………3 T02099 10x15x4 TS4039 Diff shaft...
  • Page 6 All manuals and user guides at all-guides.com Diff T04040 M2.5x6 T04040 M2.5x6 30000# for Front 10000# for Rear T04040 M2.5x6 Screw ……………12 Mid CVD Center Front TS4032 105mm center front CVD TS4032/TS4033 M3x8 Screw T02100 5x10x4 ……………2 86000 T04041 5.1x8x0.2 16T gear 86000 5.1x8x0.2 Washer TS4032...
  • Page 7 All manuals and user guides at all-guides.com Center Diff Steering Servo T02081 3x7x0.8 TR4059 M3x10 TS4043 Ball stud-short TS4021 TR4059 M3x8 Screw Servo Mount ……………1 Servo TR4059 M3x10 Screw Select the servo horn matching the servo being used. ……………4 TS4043 Ball stud-Short ……………1 T04006 Steering servo horn...
  • Page 8 All manuals and user guides at all-guides.com Steering Servo Receiver TS4021 M3x8 T02087 Double-sided tape TS4021 Electronic equipment mount TR4058 M3x8 TR4058/TS4021 M3x8 Screw ………………7 Buffer T04003 Servo Saver-left TR4049 TS4042 Servo Saver Body Ball stud-Long T04003 Servo Saver-Top T04004 Steering Rack T04038 M3 TS4042...
  • Page 9 All manuals and user guides at all-guides.com Buffer 15mm 4.0mm T04024 3x40 T04014 T04014 T04031 4x7x2.5 TR4058 M3x8 Screw T04031 4x7x2.5 ………………2 TR4049 T04031 4x7x2.5 Ball bearing …………………4 T04014 4.8mm Ball End-Long ……2 T04024 3x40 Turnbuckle …………1 TR4058 M3x8 TR4059 M3x10 Upper Deck-Front / Front Upper Suspension Arm Mount T04019 TR4004...
  • Page 10 All manuals and user guides at all-guides.com Upper Deck-Rear / Rear Upper Suspension Arm Mount TR4059 M3x12 T02087 TS4020 Center diff upper plate TR4059 M3x10 T08814 M3x5 TR4004 Upper Suspension Arm Mount-R TR4014 Upper Deck-R TS4042 Ball stud-Long T08814 M3x5 Screw TR4059 M3x8 ……...
  • Page 11 All manuals and user guides at all-guides.com Front Hub Carrier TR4007 TR4007 Front Hub Carriers Front Hub Carriers 10 Degree-Right 10 Degree-Left TS4027 M3x3 Screw TR4008 TR4008 TS4042 … ……… ……………2 Front Hub Carriers Front Hub Carriers Ball stud-Long 13 Degree-Left 13 Degree-Right TS4027 2X9.8 Pin …………………2...
  • Page 12 All manuals and user guides at all-guides.com Front Suspension T04002 Brace bushing T04002 Front arm mount-F TR4059 M3x10 Screw TR4059 ……………2 M3x10 T04034 3x48.5 T04034 3x48.5 Arm shaft ………………2 Turnbuckle Front upper Rod-L 29.5mm 1:1 x1 4.0mm T04014 3x51 Turnbuckle TS4035 3x56 Front upper Rod-R 29.5mm...
  • Page 13 All manuals and user guides at all-guides.com Turnbuckle Front suspension TS2026 Swaybay ball end TS2026 Swaybay ball TS2026 M3x10 TS2026 Swaybay ball end TS4026 M3x10 Screw ………………2 TS4026 Swaybar ball ……………………2 Assemble both Left and Right Ture-to -scale diagram Assemble as many times as specified...
  • Page 14 All manuals and user guides at all-guides.com Front suspension TS4025 M2x6 TS4025 Swaybar mount TS4041 1.8 Swaybar TS4026 M3x3 TS4026 M3x3 Screw ……………………2 TS4025 M2x6 Screw ………………2 Front suspension TR4055 M3 Nut ……………………2 TR4059 M3x22 TR4059 M3x12 Screw …………2 TR4059 M3x14 Screw TR4055 …………2 TR4059 M3x12...
  • Page 15 All manuals and user guides at all-guides.com Front bumper TR4059 M3x8 TS4017 Front bumper stick TR4059 M3x12 TS4017 Front bumper plate TR4059 M3x8 Screw ……………4 TR4059 M3x12 Screw TR4059 M3x8 …………4 TR4059 M3x12 Rear hub carriers < R > TS4027 M3x3 Screw …...
  • Page 16 All manuals and user guides at all-guides.com Rear hub carriers < L > TR4059 M2.5x4 Screw …………………2 TR4046 2.5x30 Arm pin TR4011 2.5x6x1 ………………2 TR4011 2.5x6x1 Washer TR4011 ……………………4 2.5x6x1 < R > TS4013 Rear lower arm-L TR4059 M2.5x4 TR4046 2.5x30 Rear suspension TR4058 M3x10 Screw ……………2...
  • Page 17 All manuals and user guides at all-guides.com Rear suspension T04014 4.8mm Ball End-Long ……4 TS4035 3x56 Turnbuckle …………2 Rear upper Rod 32.5mm T04014 T04014 TS4035 3x56 Projection.Note direction Rear suspension TS4026 Swaybay ball end TS4026 M3x10 Screw TS4026 ………………2 Swaybay ball TS4026 M3x10 TS4026 Swaybar ball TS4026...
  • Page 18 All manuals and user guides at all-guides.com Rear suspension TS4026 M3x3 Screw TS4018 ……………………2 T08795 M3x18 Rear bumper stick-below TS4025 M2x6 Screw ………………2 T08795 M3x18 Screw TS4026 Screw M3x3 Cement ……2 TS4025 M2x6 TS4025 Swaybar mount TS4041 1.8 Swaybar Rear suspension TR4059 M3x22 TR4059 M3x12 TR4055 M3...
  • Page 19 All manuals and user guides at all-guides.com Shock Absorber Rear-Short Front-Short TG2013/TG2014 2.3 E-ring TG2026 TG2025 ………………………8 Put a little oil TS4023 1.2x2 Front piston T02097 T02097 Put a little oil T02097(2.8x1.9) TG2014 ………………2 T02097(2.8x1.9) TG2013 T02097(3.1x1) T02097(3.1x1) TS4023 1.4x2 Rear piston T02097(2.8x1.9) T02097(2.8x1.9) TS4023...
  • Page 20 All manuals and user guides at all-guides.com Shock Absorber Front-Short for adjusting the spring tension TG2025/TG2026 Compress the spring and install TS4036 Front Shock Spring-Medium T02031 Below Spring mount TG2025/TG2026 12x1 O-ring T02031 …………4 Below Spring mount TS4036 Rear Shock Spring-Medium Rear-Short Front Shock Absorber TS4045...
  • Page 21 All manuals and user guides at all-guides.com Rear Shock Absorber T04015 Shock cap ball-Long TS4045 M3x12 Screw Versa tooth T02084 M3 T04015 Shock cap ball-Long …………2 T02084 M3 Nylon Nut …………………2 TS4045 M3x12 Screw-Versa tooth …………1 TR4059 M3x12 Screw TR4059 M3x12 …………1 Rear bumper set TS2026 M3x12...
  • Page 22 All manuals and user guides at all-guides.com Rear bumper set TR4059 M3x10 TR4059 M3x14 TR4059 M3x10 Screw ……………2 TR4059 M3x14 Screw …………2 Body mount TS4019 Body washer TS4019 Mid clip TR4059 M3x12 TS4019 Body mount TR4059 M3x12 TS4019 Mid clip …………4 TR4059 M3x12 Screw …………4...
  • Page 23 All manuals and user guides at all-guides.com Body support / Battery holder TR4019 Battery holder TR4059 M3x10 TS4016 TR4019 Body support-R Battery holder TR4059 M3x10 TR4059 M3x10 TR4059 M3x10 TR4058 M3x10 Screw ……………4 TS4016 Body support-L TR4059 M3x10 Screw TR4058 ……………4 TR4058 M3x10...
  • Page 24 All manuals and user guides at all-guides.com Tyre TS2028 TS2029 Tyre Sponge TS2029 Tyre Tyre HLM4FS M4 locknut with flange ………………4 HLM4FS M4 Assemble as many times as specified Must be purchased separately Assemble both Left and Right...
  • Page 25 All manuals and user guides at all-guides.com Body 11mm 11mm TS4024 Body-Lexan Body TS4024 Mask sticker Mask the windows from the inside. Paint the body shell from the inside using spray colors.
  • Page 26 All manuals and user guides at all-guides.com Body < R > TS4024 M3x8 Screw TS4024 M3 …………8 TS4024 M3 Nylon Nut < L > TS4024 M3x8 ………………8 Body H135B Mid clip ……………4 H135B Mid clip H135B Body pin holder Assemble as many times as specified Assemble Both Left And Right...
  • Page 27 All manuals and user guides at all-guides.com...
  • Page 28 All manuals and user guides at all-guides.com Parts list for TS4 1/10 4WD Short-Course-1 TS4010 TS4011 TS4012 TS4013 TS4014 Left Left Front shock tower 1pcs 1pcs 1pcs 1pcs Right Right 4.8x1.6 O-ring 1pcs 1pcs 1pcs Rear shock tower 1pcs 54T Center gear...
  • Page 29 All manuals and user guides at all-guides.com Parts list for TS4 1/10 4WD Short-Course-2 TS4039 TS4041 TS4042 TS4043 TS4040 3.0 E-ring 2pcs 1.6 1pcs 1.8 1pcs Ball stud-long Ball stud-short 6pcs 6pcs 2.0 1pcs Diff Connecting Cup Swaybar Gear Set...
  • Page 30 All manuals and user guides at all-guides.com Parts list for TS4 1/10 4WD Short-Course-3 TR4053 TR4019 TR4049 TR4011 TR4046 1pcs Servo Saver Nut 2pcs 1pcs 1pcs 1pcs 1pcs Servo Saver Spring 1pcs 2.5x30 Arm Pin Velcro Tape 1pcs 1 Set...
  • Page 31 All manuals and user guides at all-guides.com Parts list for TS4 1/10 4WD Short-Course-4 TU0413 TU0416 TU0418 TU0422 TU0418 1pcs 1pcs 2pcs 2pcs Front 1pcs Front 1pcs 4pcs Rear Washer 1pcs Washer Rear 1pcs 4pcs Front Upper Arm Mount 4pcs...
  • Page 32 All manuals and user guides at all-guides.com Driver Track / City Event Date SETUP SHEET for the TeamC TS4 Conditions Smooth Bumpy Low traction Med traction High traction Sandy Soft dirt Grass Hard soil Clay Dusty Other Front Suspension Front Shocks Shock Mounting&Camber link...
  • Page 33 All manuals and user guides at all-guides.com...
