Team C Patron Instruction Manual page 10

12
Buffer
Lenkung
B
-
Bag
TR4025
T04031
4x7x2.5
T04031 4x7x2.5
TR4049
Servo Saver Post
Servo Saver Pfosten
13
Upper Deck-Front / Front Upper Suspension Arm Mount
Upper Deck vorne / Vorderer oberer Querlenkerhalter
F
TR4023
Dust Cover Mount
Staubschutz Halter
TR4059
M3x6
Ture-to -scale diagram
1:1
Zeichnung in Originalgroesse!
TR4038 3x40
TR4025
TR4058 M3x8
B
-
Bag
T02059
Ball stud-Long
Kugelkopf lang
TS4014
Upper Deck-F
Chassis oben
1:1
TR4059 M3x10
TR4004
Upper Suspension Arm Mount-F
Querl. halter Vorne oben
TR4059 M3x8
6
15mm
▲Projection.Note direction
Drehrichtung beachten!
TR4058 M3x8 Screw
M3x8 Schraube
T04031 4x7x2.5 Ball bearing
4x7x2.5 Kugellager
TR4025 4.8mm Ball End-Long
4.8mm Kugelpfanne
TR4038 3x40 Turnbuckle
3x40 Gewindestange
TR4059 M3x6 Screw
M3x6 Schraube
TR4059 M3x8 Screw
M3x8 Schraube
TR4059 M3x10 Screw
M3x10 Schraube
T02059 Ball stud-Long
Kugelkopf lang
..................2
.....................4
......2
............1
..................1
...............2
............3
............2
