GT8LE-RA
Instruction manual
1:8 Scale GP 4WD TOURING CAR
Dimensions
Length
....................................................................................630mm
長度
Width
....................................................................................320mm
寬度
Height
....................................................................................160mm
高度
www.teamcracing.net
尺寸：
Advertisement
Related Manuals for Team C GT8LE-RA
Summary of Contents for Team C GT8LE-RA
- Page 1 GT8LE-RA Instruction manual 1:8 Scale GP 4WD TOURING CAR Dimensions 尺寸： Length …………………………………………………………………………630mm 長度 Width …………………………………………………………………………320mm 寬度 Height …………………………………………………………………………160mm 高度...
-
Page 2: Transmitter Preparation
Transmitter Preparation 调整遥控器 Motor Battery 馬達 電池 Battery Charger (Not Included) 充電器（不包括） Install Transmitter Batteries 安裝發射電池 Electronic Speed Controller / Switch Connect Battery to ESC 電子變速器 連接電池到電調 Servo 伺服 Switch on Transmitter First 首先接通發射機 Receiver 接收機 Switch on ESC Second 其次接通電調... - Page 3 Servo Saver Turnbuckle Select the servo horn matching the servo being used. 伺服拉杆 根据伺服机选择伺服臂 Approx.27mm 大约27mm TG8019 3x45 Turnbuckle 3x45拉杆 ▲Projection.Note direction Futaba-25T Hitec-24T Sanwa/JR/KO-23T 注意方向 …………1 T08666 M3 T08759 T08760 5.8 Ball End 5.8 Ball stud 5.8 球头座 5.8球头 …………2 T08759 5.8 Ball stud TG8019...
- Page 4 Servo Saver Post/Side Plate 缓冲柱/侧板 TG8003 Side Plate-Right 侧板-右 T08840 Chassis 底盘 T08650 Servo Saver Post 缓冲柱 TG8003 Side Plate-Left 侧板-左 T08674 M3x8 T08674 M3x8 T08674 M3x8 Screw M3x8螺丝 …………7 T08674 M4x10 Screw M4x10螺丝 …………2 T08674 M4x10 Screw Cement T08674 Buffer M4x10 Screw...
- Page 5 Front/Rear Differential 前/后差速器 T08636 M3x12 T08633 20T Diff Gear T08633 T08633 20T差速齿轮 20T Diff Gear 2.5x11.5 Pin T08633 20T差速齿轮 T08633 4.1x12x0.2 2.5x11.5 钢针 10T Diff Gear 10T差速齿轮 T08633 T08633 T08669 6.1x11x0.2 2.5x11.5 Pin Diff Shaft 2.5x11.5 钢针 差速轴 T08600 T08669 6.1x11x0.2 Differential Pads 差速垫片...
- Page 6 Front Swaybar T08756 前防倾杆 T08756 T08760 T08756 M3x3 Screw Cement T08674 M2.5x8 Screw M2.5x8螺丝 ………………3 T08601/T08756 M3x3 Screw M3x3螺丝 ……………………4 T08756 6.8 Ball stud 6.8球头 …………………2 T08601 T08755 6.8 Ball stud Swaybar Mount 6.8球头 防倾杆固定座 ………………………2 T08760 6.8 Ball End 6.8球头座...
- Page 7 Front Hub Carrie 前轮座 T08675 M4x10 T08607 Front Hub Carrier Bushing 前輪座軸套 T08675 M4x10 Screw M4x10 螺丝 ……………2 T08673 M4x16 T08607 Front Hub Carrier Bushing 前輪座軸套 ………4 T08607 T08673 M4x16 Screw Front Lower Arm 前下摆臂 M4x16 螺丝 ……4 T08673 M4x16 Front Suspension T08645 4x73 Arm Pin 前悬吊系统...
- Page 8 Front Shock Tower 前避震架 TU0884 M3.5 TU0884 Ball stud 球头 T08674 M3x12 T08842 Front Shock Tower 前避震架 T08674 M3x12 Screw TU0884 M3.5 Nylon Nut M3x12 螺丝 M3.5 尼龍螺母 ……4 ……………2 Front Upper Turnbuckle 前上拉杆 Front Upper-Left 1:1 x1 前上-左 Approx.32mm 大约32mm T08757 7.8 Ball stud...
- Page 9 Steering Turnbuckle T08754 转向拉杆 6.8 Ball stud Steering-Left 1:1 x1 6.8球头 Approx.27mm 转向-左 大约27mm ▲Projection.Note direction 注意方向 T08753 T08760 6.8 Ball stud 6.8 Ball End-Steering Steering-Right 6.8球头 1:1 x1 6.8 球头座-转向 转向-右 Approx.27mm T08776 大约27mm 4x53 Turnbuckle 4x53 拉杆 T08760 ▲Projection.Note direction 6.8 Ball End-Steering 6.8 球头座-转向...
- Page 10 T08674 M4x10 Front Suspension T08674 M3x18 前悬吊系统 T08674 M3x18 T08666 M4 Nylon Nut M4 尼龙螺母 ………………1 T08674 M3x18 Screw M3x18 螺丝 T08666 M4 ……2 T08674 M4x10 Screw M4x10 螺丝 …………3 T08674 T08674 M4x14 Screw M4x14 螺丝 M4x14 T08829 Front Bumper Plate-Lower ………4 T08674 T08674 M4x14...
- Page 11 Solid Axle Gear Set 直轴齿轮组 T08673 M3x10 Screw T08673 M3x10 螺丝 M3x10 Screw Cement …………4 T08865 Center Differential Plate 中央差速器固定板 T08686 Center Differential Mount-Rear 中央差速器固定座-后 T08686 Motor Mount 马达固定座 Motor 马达 Motor 马达 T08686 Motor Mount 马达固定座 Tighten the screws with one sheet of paper inserted between both gears.
- Page 12 Solid Axle Gear Set 直轴齿轮组 T08674 M3x8 Screw M3x8 螺丝 ………………2 T08674 M4x10 Screw M4x10螺丝 ……………4 T08681 Motor Mount 马达扶持座 T08674 M4x10 T08674 M3x8 Rear Differential Case 后差速箱 T08849 128mm Center Rear CVD 128mm中后CVD T08849 M5x4 Screw Cement T08663 T08601 Differential Case 6x13x5 差速箱...
- Page 13 T08756 Rear Swaybar T08755 Screw M3x3 后防倾杆 Cement T08756 T08760 T08601/T08756 M3x3 Screw M3x3 螺丝 ……………………4 T08601 M2.5x8 Screw M2.5x8 螺丝 ………………3 T08756 6.8 Ball stud-Swaybar T08601 6.8 球头-防倾杆 Swaybar Mount 防倾杆固定座 …………………2 T08601 M2.5x8 T08647 T08755 6.8 Ball stud-Swaybar Rear Swaybar 6.8 球头-防倾杆...
- Page 14 Rear Suspension 后悬吊系统 T08674 M3x35 T08613 Rear Arm Mount-R 后摆臂固定座-后 T08613 T08608 +1 Degree Bushing-Right +1 度轴套-右 T08646 4x77 T08613 T08666 M4 Nylon Nut +1 Degree Bushing-Left M4 尼龙螺母 +1 度轴套-左 ………………2 T08673 M3x16 Screw M3x16 螺丝 ……2 T08674 M3x12 Screw T08674 M3x12 T08613 M3x12 螺丝...
- Page 15 Rear Upper Turnbuckle Rear Upper-Left 1:1 x1 后上拉杆 Approx.14mm 后上-左 大约14mm T08760 7.8 Ball End-Rear Upper 7.8 球头座-后上 ▲Projection.Note direction 注意方向 T08760 T08758 7.8 Ball End-Rear Upper 7.8 Ball stud Rear Upper-Right 1:1 x1 7.8 球头座-后上 Approx.14mm 7.8 球头 后上-右 大约14mm T08778 5x40 Turnbuckle...
- Page 16 Rear Suspension 后悬吊系统 T08666 M3 T08666 M3 Nylon Nut M3尼龙螺母 ……………1 T08674 M3x10 Screw M3x10螺丝 ………1 T08674 M3x12 Screw M3x12 螺丝 ……1 T08674 M3x10 T08674 M4x14 Screw T08674 M3x12 M4x14螺丝 T08674 …4 M4x14 Shock 避震器 T08627 2.75mm Plastic Washer 2.75mm 塑胶垫片 T08844/T08625 …………………4 Shock Bottom cover...
- Page 17 Shock T08844/T08625 18.5x1.5 O-Ring 避震器 18.5x1.5 O环 ……………4 T08844/T08625 Shock Top cover 避震上盖 Front-Short T08628 前-短 Front Shock Spring-Short Rear-Long 前避震弹簧-短 T08622 后-长 Rear Shock Spring-Long Diaphragm 后避震弹簧-长 气室 Front-Short 前-短 Rear-Long 后-长 T08844/T08625 Front-Short 前-短 18.5x1.5 Rear-Long 后-长 T08622 Spring Mount 弹簧固定座...
- Page 18 Rear Shock 后避震器 T08622 Plastic Bushing 塑胶衬套 87005 M3 87005 M3 Flanged Nylon Nut M3帶邊尼龍螺母 ………………2 T08622 Plastic Bushing 塑胶衬套 ………………………2 T08673 M3x18 Screw M3x18 螺丝 ……2 T08673 M3x18 T08673 M3x8 Front Bumper 前防撞 T08829 Front Bumper Plate-Upper 前防撞板-上 T08932 Front Bumper Sponge 前防撞海绵...
- Page 19 Rear Bumper Plate 后防撞板 T08666 M4 T08832 Rear Bumper Plate 后防撞板 T08674 M4x12 Screw M4x12螺丝 …………2 T08666 M4 Nylon Nut M4 尼龙螺母 T08674 M4x12 ………………2 Body Mount T08863 M2.5x15 Screw 车壳架 M2.5x15螺丝 …………10 T08666 M2.5 Nylon Nut T08833 Body Washer M2.5 尼龙螺母...
- Page 20 Front Body Mount T08673 M3x12 Screw 前车壳架 M3x12 螺丝 …………2 T08673 M3x12 Rear Body Mount 后车壳架 T08673 M3x12 T08673 M3x12 Screw M3x12 螺丝 …………2...
- Page 21 Receiver/Servo T02087 T08674 M3x8 T08673 M3x8 接收机/伺服机 Antenna Pipe T08614 天线管 Receiver Cover T02081 3x7x0.8 Washer 接收机盖 3x7x0.8 垫片 ……………………4 Receiver T08673 M3x8 Screw 接收机 M3x8 螺丝 ……………1 T08793 M3x15 Screw M3x15 螺丝 T08675 M3x5 …………4 T08674 M3x8 Screw M3x8螺丝 ……………1 T08793 T08675 M3x5 Screw...
- Page 22 Battery 电池 T08821 Velcro Tape 魔鬼粘 Battery 电池 T08821 Battery Mount 电池固定座 Battery 电池 T08674 M3x8 Screw M3x8螺絲 ………………8 T08674 M3x8 Must be purchased separately Assemble as many times as specified 需另购物品 需组装数量...
- Page 23 Electronic speed controller 电子变速器 Electronic speed controller 电子变速器 T02087 Double-sided tape 双面胶 Tyre 轮胎 T08929 Tyre 轮胎 T08929 Sponge 海棉 T08912 轮框 Must be purchased separately Assemble as many times as specified 需另购物品 需组装数量...
- Page 24 Tyre 轮胎 Tyre 轮胎 T08913 17mm Hex Nut 17mm 六角螺帽 ……4 T08913 17mm Hex Nut 17mm 六角螺帽 Assemble as many times as specified Assemble both Left and Right 需组装数量 组装左和右...
- Page 25 Body 车壳 T08931 Body-Lexan 车壳-PC Car Light / Wing 车灯/尾翼 T08931 Wing 尾翼 Paint the wing from the inside using spray colors. 在尾翼内臂喷漆。 T08931 Wing 尾翼...
- Page 26 Body 车壳 T08931 Mask sticker 遮盖贴纸 Mask sticker the windows from the inside. 在车窗内臂贴上遮盖贴纸。 Body 车壳 Paint the body shell from the inside using spray colors. 在车壳内臂喷漆。...
- Page 27 Wing 尾翼 T08931 M3 T08931 M3 Nylon Nut M3尼龙螺母 T08931 M3x6 ………....…4 T08931 M3x6 Screw M3x6 螺丝 …………………4 Body 车壳 T08660 Mid Clip 中号固定夹 T08660 Mid Clip 中号固定夹 ……4 T08660 Mid Clip 中号固定夹...
- Page 29 Parts list for GT8LE-RA 1/8 EP 4WD Touring Car-1 GT8LE-RA 1/8电动四驱房车配件包-1 T08823 T08827 T08828 T08829 T08932 Buffer Plate-Plastic 1pcs 1pcs 缓冲顶板-塑胶 1pcs 1pcs 1pcs Arm Mount Front-R Front Bumper Sponge 摆臂固定座前-R Front Bumper Plate 前防撞海绵 1pcs 42T Gear Aluminium Buffer Plate-Black 前防撞板...
- Page 30 Parts list for GT8LE-RA 1/8 EP 4WD Touring Car-2 GT8LE-RA 1/8电动四驱房车配件包-2 T08686 TG8030 H396 Center Differential Mount / Motor Mount 中央差速器固定座/马达固定座 M3x12 Screw M3x12 螺丝 1pcs 1pcs M3x14 Screw 1pcs 1pcs M3x14 螺丝 1pcs M3x6 Screw M3x6螺丝 3x7x0.8 Washer 8pcs 3x7x0.8 垫片...
- Page 31 Parts list for GT8LE-RA 1/8 EP 4WD Touring Car-3 GT8LE-RA 1/8电动四驱房车配件包-3 T08663 T08664 T08665 T08666 M2.5 Nylon Nut M3.5 Nylon Nut M2.5 尼龍螺母 6pcs M3.5 尼龍螺母 6pcs M4 Nylon Nut 13x19x4 Ball Bearing 6x13x5 Ball Bearing 8x16x5 Ball Bearing M3 Nylon Nut M4 尼龍螺母...
- Page 32 Parts list for GT8LE-RA 1/8 EP 4WD Touring Car-4 GT8LE-RA 1/8电动四驱房车配件包-4 T08760 T08759 T08762 T08763 1pcs 7.8 Ball End-Rear Upper 2pcs 7.8 球头座-后上 Rear Chassis Stiffener Mount 2pcs 后支撑杆固定座 6.8 Ball End-Swaybar 6.8 球头座-防倾杆 6.8 Ball End-Steering Top 1pcs 2pcs Left 1pcs 6.8 球头座-转向...
- Page 33 Parts list for GT8LE-RA 1/8 EP 4WD Touring Car-5 GT8LE-RA 1/8电动四驱房车配件包-5 T08637 T08912 M3x12 Cap Head Screw T08913 83001 8pcs M3x12圆柱头螺丝 M3x14 Cap Head Screw T08219 8pcs M3x14圆柱头螺丝 M3x18 Cap Head Screw T08220 8pcs M3x18 圆柱头螺丝 Mid Clip 511129 10pcs 中号固定夹...
- Page 34 Parts list for GT8LE-RA 1/8 EP 4WD Touring Car-6 GT8LE-RA 1/8电动四驱房车配件包-6 TU0875 TU0876 TU0877 TU0878 TU0879 4pcs M3x12 4pcs 4pcs Diff Shaft -Aluminium 2pcs 2pcs Servo Saver Shaft-Aluminium 差速轴-铝 6.8 Swaybar Ball Stud- Aluminium 7.8mm Arm Ball Stud-Aluminium 2pcs 缓冲柱-铝...
- Page 35 GT8LE-RA Driver Track / City Event Date SETUP SHEET for the TeamC GT8LE-RA Track Condition Smooth Bumpy Low traction Med traction High traction Sandy Soft dirt Grass Hard soil Clay Dusty Other Front Suspension Front Shocks Shock Mounting&Camber link Anti-roll bar: °...
- Page 36 www.teamcracing.net...
