Whalen WMFP60EC-7 Manual

60" rustic brown bow front media fireplace
Hide thumbs

Advertisement

Quick Links

Download this manual
60" Rustic Brown Bow Front Media Fireplace
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions
and parts list ready to provide the model name, part name or factory number:
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Manufacturing
Stock # WMFP60EC-7
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or e-mail your request to parts@whalenfurniture.com
Date 2015-06-09 Rev. 2 Factory: KONRIC
1-866-942-5362
www.whalenstyle.com
Page 1
LOT NUMBER:
DATE PURCHASED: /
Factory No. 16086
/

Advertisement

loading

Related Manuals for Whalen WMFP60EC-7

Summary of Contents for Whalen WMFP60EC-7

  • Page 1 LOT NUMBER: DATE PURCHASED: / 60" Rustic Brown Bow Front Media Fireplace Stock # WMFP60EC-7 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions...
  • Page 2 I M P O R T A N T I N F O R M A T I O N MANUFACTURER: Whalen Furniture Manufacturing CATALOG: 60” Rustic Brown Bow Front Media Fireplace (WMFP60EC-7) DATE OF MANUFACTURE: June 2015 MADE IN CHINA FITS UP TO MOST 65”...
  • Page 3 Stock # WMFP60EC-7 Important Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual.

  • Page 4: Parts And Hardware List

    Stock # WMFP60EC-7 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (1) B- Side Panel (2) C- Left Partition Panel (1) D- Right Partition Panel (1)
  • Page 5 Stock # WMFP60EC-7 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (1) Cam Lock (2) Cam Bolt (3) Ø8 x 30 mm Wood Dowel (19+1 extra)

  • Page 6: Assembly Instructions

    Stock # WMFP60EC-7 Assembly Instructions Cam Bolt (19 used in this step) ② A/C/D/E/G 1. Unpack the unit and confirm that you have all the hardware and required parts. Assembly the unit on a carpeted floor or the empty carton to avoid any scratch.
  • Page 7 Stock # WMFP60EC-7 Assembly Instructions Cam Lock Wood Dowel (3 used in this step) (2 used in this step) ① ③ 3. Insert two Wood Dowels (3) into the inner holes of Middle Crossbar (F). Tap it in with a rubber mallet, if necessary.
  • Page 8 Stock # WMFP60EC-7 Assembly Instructions Cam Lock Wood Dowel (4 used in this step) (4 used in this step) ① ③ 5. Insert four Wood Dowels (3) into the inner holes of Fixed Shelf (E) at both ends. 6. Align and attach the assembled Fixed Shelf (E) between the Left and Right Partition Panels (C and D) and fasten it in place by using four Cam Locks (1) as shown.
  • Page 9 Stock # WMFP60EC-7 Assembly Instructions Cam Lock Wood Dowel Ø4 x 40 mm Screw (4 used in this step) (8 used in this step) (4 used in this step) ① ③ ⑤ 7. Insert four Wood Dowels (3) into the bottom inner holes of assembled Partition Panels (C and D) and attach them to the Base (G) with four 40 mm Screws (5) as shown.
  • Page 10 Stock # WMFP60EC-7 Assembly Instructions Cam Lock Wood Dowel (8 used in this step) (8 used in this step) ① ③ 9. Insert eight Wood Dowels (3) into the top inner holes on the vertical panels (B, C and D). Position the Top Panel (A) onto the inserted Wood Dowels (3) and fasten it in place with eight Cam Locks (1).
  • Page 11 Stock # WMFP60EC-7 Assembly Instructions Ø3.5 x 12 mm Screw Metal Bracket (4 used in this step) (2 used in this step) ④ ⑧ 10. Stand the assembled unit upright. 11. Fasten the Middle Crossbar (F) to the stringers of Lower Partition Panels (C and D) by attaching two Metal Brackets (8) at the joints, using two 12 mm Screws (4) per Bracket.
  • Page 12 Stock # WMFP60EC-7 Assembly Instructions M3.5 x 15 mm Washer Head Screw (28 used in this step) ⑥ 12. Now, go back and securely tighten all the Cam Locks and Wood Screws. Make sure all the parts are tight and there are no gaps between the parts. This will help keep the unit square.
  • Page 13 Stock # WMFP60EC-7 Assembly Instructions B/C/D B/C/D Shelf Pin Cam Lock Cover (16 used in this step) (12 used in this step) ⑫ ⑬ 15. Insert eight Shelf Pins (12) into the holes at your desired height inside each side compartment. Tilt and rest the Adjustable Shelves (J) onto the Shelf Pins (12).
  • Page 14 Stock # WMFP60EC-7 Assembly Instructions H/ I H/ I H/ I Knob Rubber Bumper Knob Bolt (2 used in this step) (4 used in this step) (2 used in this step) ⑨ ⑪ ⑩ 17. Attach the Knob (9) to the outside of each Door (H and I) with the provided Knob Bolt (10).
  • Page 15 Stock # WMFP60EC-7 Assembly Instructions 22. Lift the Fireplace Insert carefully into the back of the assembled mantel and center it in the opening. DO NOT drag the insert across the Base (G) as it may scratch the unit. 1-866-942-5362...
  • Page 16 Stock # WMFP60EC-7 Assembly Instructions 2” Lag Bolt (2 used in this step) ⑦ 23. Align and attach the Firebox Support (M) to the Base (G) by screwing two 2” Lag Bolts (7) through the countersunk holes and screw into place.
  • Page 17 Stock # WMFP60EC-7 Assembly Instructions Acrylic Stopper (1 used in this step) ⑭ NOTE: You must install the Acrylic TV Stopper to prevent the TV from tipping when placing your flat panel television directly on the console. 24. Remove the paper backing of acrylic stopper (14), then properly align the acrylic stopper into the cut-out on the acrylic stopper template on the Top Panel (A).
  • Page 18 Stock # WMFP60EC-7 Assembly Instructions Tools required: Phillips screwdriver, Power Drill, 3/8” Drill Bit and Rubber Mallet. 26. Ask for assistance to position the assemble fireplace at the desired location against a wall. If necessary, adjust the pre-attached Floor Levelers at the bottom of the Base (G) to level the unit. Now, follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach the tip-over restraints to the unit and the wall.

  • Page 19: Care And Maintenance

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
  • Page 20 IF YOU NEED TO ORDER ANY REPLACEMENT PARTS, PLEASE USE THE LIST BELOW 60" Rustic Brown Bow Front Media Fireplace (WMFP60EC-7) *WMFP60EC-7-1-TP Top Panel *WMFP60EC-7-24-M8x30WD M8 x 30 mm Wood Dowel *WMFP60EC-7-2-SP Side Panel *WMFP60EC-7-25-MB Metal Bracket *WMFP60EC-7-3-LPP Left Partition Panel...
