Introduction

Thank you for selecting the Martin™ MAC Quantum Wash™. This moving-head spotlight features:
• Fifty 15 Watt pre-mixed RGBW LEDs
• Full-spectrum RGBW color mixing and color temperature control
• 'Color wheel' effect with color presets
• Full-range dimming with four dimming curve options
• Electronic shutter effect with variable speed regular and random strobe
• Backlit graphic display and battery power (mains power not required for fixture setup)
• Auto-sensing switch-mode power supply.
For the latest firmware updates, documentation, and other information about this and all Martin Professional
products, please visit the Martin website at http://www.martin.com
Comments or suggestions regarding this document may be e-mailed to service@martin.dk or posted to:
Technical Documentation, Martin Professional, Olof Palmes Allé 18, DK-8200 Aarhus N, Denmark.

Unpacking

The MAC Quantum Wash is packaged in either a
cardboard box or a flightcase that is designed to protect
the product during shipment.
This Safety and Installation Manual is included with the
product. The MAC Quantum Wash User Guide,
containing full details of setting up, controlling and
monitoring the fixture, is available for download from the
MAC Quantum Wash Product Support page on the
Martin website at www.martin.com. If you have any
difficulty locating this document, please contact your
Martin supplier for assistance.
Tilt lock
Release the tilt lock before applying power to the fixture.
See Figure 1. Release the tilt lock by pushing the lock in
towards the yoke (you can reapply the tilt lock by first
checking that the power is off and then pushing the lock
back in towards the yoke from the other side).

Packing

Important! Release the tilt lock and allow the fixture to cool before packing it in its flightcase.
The anti-shock material in the MAC Quantum Wash flightcase is designed to protect the head without the tilt
lock applied. Release the tilt lock when transporting the fixture in the flightcase. Leaving the tilt lock applied
may cause damage that is not covered by the product warranty.
6 MAC Quantum Wash Safety and Installation Manual
Figure 1: Tilt lock
