MIMAKI JV400-130LX Operation Manual
  1. Manuals
  2. Brands
  3. MIMAKI Manuals
  4. Printer
  5. JV400-130LX
  6. Operation manual
MIMAKI JV400-130LX Operation Manual

MIMAKI JV400-130LX Operation Manual

Jv400-lx series
Hide thumbs Also See for JV400-130LX:
Table of Contents

Advertisement

Quick Links

Download this manual
MIMAKI ENGINEERING CO., LTD.
URL: http://eng.mimaki.co.jp/
D202283-26
Original instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JV400-130LX and is the answer not in the manual?

Questions and answers

Related Manuals for MIMAKI JV400-130LX

Summary of Contents for MIMAKI JV400-130LX

  • Page 1 MIMAKI ENGINEERING CO., LTD. URL: http://eng.mimaki.co.jp/ D202283-26 Original instructions...

  • Page 2: Table Of Contents

    TABLE OF CONTENS CAUTION ................v DISCLAIMER OF WARRANTY ........v Requests ................. v FCC Statement (USA) ............. v Interference to televisions and radios ......v Foreword ................vi About usable ink ..............vi On This Operation manual ..........vi Safety Precautions ............. vii Symbols ................vii Safety interlock ..............
  • Page 3 Take-up device ...............2-12 Setting leaf media ............2-13 Changing the printing origin ..........2-15 Preparing for the Heaters ..........2-16 Changing the Temperature Settings for the Heaters ..2-16 Checking the Heater Temperature .........2-17 Changing the Temperature Settings for the Drying Heater ................2-17 Test Feeding ..............
  • Page 4 Chapter 4 Maintenance Maintenance ..............4-2 Precautions for Maintenance ..........4-2 About Maintenance washing liquid ........4-2 Cleaning the Exterior Surfaces ......... 4-3 Cleaning the Platen ............4-3 Cleaning of after heater cover and pre heater cover ..4-3 Cleaning the Media Sensor ..........4-4 Cleaning the Media Holder ..........
  • Page 5 Warning / Error Messages ..........5-11 Warning messages ............5-11 Error messages ..............5-14 Chapter 6 Appendix Specifications ..............6-2 Machine specifications ............6-2 Ink specifications ..............6-3 Setting orders depending on ink type ....... 6-4 Setting orders of ink cartridges .........6-4 Sheet for inquiry ..............6-5 Warning labels ..............

  • Page 6: Caution

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. In the case where MIMAKI-recommended cable is not used for connection of this device, limits provided by FCC rules can be exceeded.

  • Page 7: Foreword

    Foreword Congratulations on your purchase of MIMAKI color ink jet printer "JV400 Series" . “JV400 Series” is a color inkjet printer that can print with LX ink realizing high image quality. About usable ink Usable ink for this machine are LX100 ink (four-color / four-color+white model) and LX101 ink (four-color / six- color / six-color+white model: For white, LX100 is used.).

  • Page 8: Safety Precautions

    Safety Precautions Symbols Symbols are used in this Operation Manual for safe operation and for prevention of damage to the machine. The indicated sign is different depending on the content of caution. Symbols and their meanings are given below. Please follow these instructions as you read this manual. Examples of symbols Meaning Failure to observe the instructions given with this symbol can result in death or serious injuries...

  • Page 9: Warning For Use

    Check first that the machine no longer produces smoke, and then contact your distributor or a sales office of MIMAKI for repair. • Never repair your machine by yourself since it is very dangerous for you to do so.

  • Page 10: Cautions And Notes

    • The machine does not operate with any ink other than the Handling of media JV400 genuine ink. • Use media recommended by MIMAKI to ensure reliable, • Do not use the JV400 genuine ink with other printers, as high-quality printing.

  • Page 11: Safety Interlock

    Safety Precautions Cautions on Installation CAUTION A place exposed to direct A place where temperature or On an inclined surface sunlight humidity varies significantly • Use the machine under the following environmental conditions: • Operating environment: 20 to 30 °C (68 to 95 °F) 35 to 65 % (Rh) A place exposed to direct air...

  • Page 13: Before Use

    Chapter 1 Before Use This chapter describes the items required to understand before use, such as the name of each part of the machine or the installation procedures. Moving This Machine ........1-2 Connecting Cables ........1-10 Where to Install This Machine ..... 1-2 Connecting USB2.0 Interface Cable ..1-10 Working Environmental Temperature ..

  • Page 14: Moving This Machine

    1000 mm or more JV400-130LX: 3634 mm or more JV400-160LX: 3879 mm or more • When you usually use photographic fixer, do not install this machine in a room filled with vapor of photographic fixer. If you install this machine in such a room, ink adhering to the head hardens and it may cause image quality defect that cannot be improved even if you perform head cleaning many times and may cause nozzle clogging.

  • Page 15: Moving This Machine

    Moving This Machine Moving This Machine Move this machine according to the following steps when this machine needs to be moved on the same step- free floor. • When the machine is moved to any place other than on the same step-free floor, contact your distributor or our service office.

  • Page 16: Names Of Parts And Functions

    Names of Parts and Functions Front Side of the Machine Left maintenance cover Front cover Open the cover in maintenance. Open the cover in setting of medias, taking of measures Even when the power switch is off, keep all covers against jamming of medias or in maintenance inside the closed.

  • Page 17: Rear Side And Right Side Of The Machine

    Names of Parts and Functions Rear Side and Right Side of the Machine Pre-heater Clamp lever (rear) Preheats the media before printing. (Located inside the platen) Interlocks with the clamp lever in the font of this machine. Cleaning solution cartridge Set a dedicated Washings cartridge (optional: FL001-Z-22).

  • Page 18: Operation Panel

    Operation Panel Use the operation panel to make settings for printing or operate this machine. Display CONSTANT lamp Lights in green when the heater temperature Displays the status of the reaches the set temperature. machine, set items and errors. HEAT lamp Lights in orange during heating up of the heater.

  • Page 19: Heater

    Names of Parts and Functions Heater Pre-heater/Print heater/Post-heater are equipped on the platen. The Pre-heater is used for pre-heating of the media prior to printing to prevent rapid changes in temperature. The Print-heater improves the image quality in printing.The Post-heater and drying-heater dries ink after printing.

  • Page 20: Carriage

    Carriage The carriage is provided with the heads for printing, the cutter unit for cutting off the sheet of media, etc. A lever is also provided to adjust the height of Head in 3 stages according to the thickness of media. ( P.2-5) Carriage Cutter blade and slot for cutting...

  • Page 21: Capping Station

    Names of Parts and Functions Capping station • Be sure to wear the attached goggles in cleaning within the capping station to protect your eyes against ink. Otherwise, you may get ink in your eyes. The capping station consists of the ink caps, the wiper for cleaning the heads, etc.

  • Page 22: Connecting Cables

    Connecting Cables Connecting USB2.0 Interface Cable Connect the PC and this machine with the USB2.0 USB cable interface cable. • Your RIP must be compatible with USB 2.0. • Contact a RIP maker near your location or our office when the USB2.0 interface is not attached to the PC.

  • Page 23: Connecting The Power Cable

    Connecting Cables  Removing USB memory If a USB memory module is inserted in the personal computer to which a JV400 machine is connected, click "Stop" in the "Safely Remove Hardware" window by following the instructions given there first and then remove the module.

  • Page 24: Inserting Ink Cartridges

    Inserting ink cartridges Insert an ink cartridges. Slowly shake the white ink cartridge more than twenty times right and left. • To prevent ink from leaking when you shake the cartridge, wear gloves and firmly cover the A part of the upper surface of the cartridge and the B part of the bottom surface of the cartridge with paper towels.
  • Page 25 Inserting ink cartridges Changing an ink cartridge Perform as follows when [INK END] or [INK NEAR END] is displayed on the display.  When [INK END] is displayed (1) Pull out an ink cartridge to be replaced. (2) Insert a new ink cartridge, paying attention to the direction of IC chip. ...

  • Page 26: Caution In Handling Of Ink Cartridges

    • Do not shake ink cartridges violently. This may result in ink leakage from the ink cartridges. • Never refill the ink cartridges with ink. This may result in troubles. MIMAKI will not bear any responsibility for any damage caused by the use of the ink cartridges refilled with ink.

  • Page 27: How To Assemble Ink Cartridge

    Inserting ink cartridges How to assemble ink cartridge Before setting the ink cartridge, it is required to set the ink pack on the eco cartridge. By following the next procedures, assemble the ink cartridge. Open the cover of the eco cartridge. (1) Press the center part of the cover with your finger.
  • Page 28 Inserting ink cartridges (2) Peel the seal of double coated tape. Firmly fix the ink pack on the eco case with double coated tape so that it may not move. • Fix the ink pack after pulling it so that the ink pack may not go slack.

  • Page 29: Media

    Perform test feeding media status. • Use media recommended by MIMAKI to ensure reliable, high-quality printing. Set the heater temperature to meet the characteristics of the media. • Set the temperature of the Pre-heater, Print heater and Post-heater according to the type and characteristics of the media used.

  • Page 30: About Antistatic Sheet

    About antistatic sheet 130LX: three antistatic sheets, 160LX: four antistatic sheets are attached in this machine. The electrostatic sheet is used to prevent the media from clinging due to static. Use this when static or deflection of the media on the post heater occurs and affects the media feeding. ...

  • Page 31: About Antistatic Sheet

    About antistatic sheet If you removed the antistatic sheet, attach the sheet holder on the platen (130LX: three positions / 160LX:four positions). If you do not attach the sheet holder, the heater temperature drops and drying may become not enough. Sheet holder 1-19...
  • Page 32 1-20...

  • Page 33: Basic Operations

    Chapter 2 Basic Operations This chapter describes procedures and setting methods for ink and media preparation, and printing. Workflow ............2-2 Test Printing ..........2-19 Turning the Power ON/OFF ......2-3 Test Printing ..........2-20 Head Cleaning ..........2-21 Turning the Power ON ........ 2-3 Turning the Power OFF .......

  • Page 34: Workflow

    Workflow Turning the Power ON/OFF Referring to “Turning the Power ON/OFF” P.2-3). Setting a Media Referring to “Setting a Media” ( P.2-5). Preparing for the Heaters Referring to “Preparing for the Heaters” P.2-16). Test Printing Referring to “Test Printing” ( P.2-19).

  • Page 35: Turning The Power On/Off

    Turning the Power ON/OFF Turning the Power ON This machine is provided with the following two power switches: Main power switch:Two switches are located on the side of this machine.Keep this switch ON all the time. Power switch : Normally, use this switch to turn the power ON/OFF. The power switch lights in green when the power is ON.

  • Page 36: Turning The Power Off

    Turning the Power ON/OFF Turning the Power OFF When having ended the operation of the machine, turn the power OFF by pressing the power switch located on the front side. Check the following items when turning the power OFF. • If the machine is receiving data from the PC or if there is any data that has not been output yet •...

  • Page 37: Setting A Media

    Setting a Media This machine can be used with a roll media and leaf media. For usable medias, refer to P.1-17 “Usable sizes of media”. Adjusting the Head Height Adjust the head height according to the thickness of the media you use. •...
  • Page 38 Fix the carriage. • Fastening the screw in front, you can fix the carriage. • Fasten the screw securely. Fix the carriage. Return the carriage to the station position. • When the power supply is off, return the carriage to the station manually.

  • Page 39: Note For Media Setting

    Setting a Media Note for media setting When setting media, read the following notes carefully. • Take care not to drop the media on a foot or so when the media is set. It may cause an injury due to the media. •...

  • Page 40: Setting A Roll Media

    Setting a roll media Roll holder Move the roll holder located in the back of the device to the direction of the middle of the device. • Loosen the roll holder fixing screw and then move it. Roll holder fixing screw Check the clamp lever located in the back of the device is lowered.
  • Page 41 Setting a Media Tighten the roll holder fixing screw. • Check the Step 2 to 3 again. Set the left end of the core of the roll media on the left roll holder. • Push the roll media onto the roll holder until the roll core is all the way seated.
  • Page 42 Pull out the roll media out. (1) Open the front cover. (2) Raise the clamp lever from the back of this machine. (3) Pull out the roll media gently and then stop pulling when locked lightly. • When setting a medium, be sure to cover the medium sensors located on the rear of the platen.
  • Page 43 Setting a Media Hold the media with the media guide gently. • If the printing result indicates that drying is not enough, use the media guide to improve adhesion of the media to the platen. • Use the media guide with it hit slightly against the sheet Media press holder.

  • Page 44: Take-Up Device

    Entering the media remaining amount When [MEDIA RESIDUAL] of the maintenance function is "ON" ( P.3-14), the screen for entering media remaining amount is displayed after detecting the media width. Display the screen for entering media remaining amount. I n p u t o f Me d i a L e n g t h 5 0 .

  • Page 45: Setting Leaf Media

    Setting a Media Setting leaf media Unlike roll media, leaf media does not need to be retained with the roll holders. • After printing, in case that there is not a margin of more than 600mm from the edge, drying feed cannot be fully performed.
  • Page 46 Hold the media with the media guide gently. • If the printing result indicates that drying is not enough, use the media guide to improve adhesion of the media to the platen. • Use the media guide with it hit slightly against the sheet holder.

  • Page 47: Changing The Printing Origin

    Setting a Media Changing the printing origin The position of the printing origin can be changed. Moving the LED pointer to the changing position and deciding the position. In Local, Press OR I G I N SE T UP 0 . 0 - - - - •...

  • Page 48: Preparing For The Heaters

    Preparing for the Heaters Changing the Temperature Settings for the Heaters Set the heater temperature. Depending on the media and the profile to use, set the heater temperature. • It may take several minutes to tens of minutes for the set temperature to be reached, depending on the ambient temperature.

  • Page 49: Checking The Heater Temperature

    Preparing for the Heaters Checking the Heater Temperature Press the key. PR T POS T 3 5 ° C 4 0 ° C 5 0 ° C • The current heater temperature is displayed. Press the key at the end of confirmation. •...

  • Page 50: Test Feeding

    Test Feeding Since heater is used at high temperature, cockles may occur in some of your media. ( P.5-10) Perform this function before printing, and check whether the media can be fed normally. Press the key in LOCAL three T E S T F E ED [ EN T ] times.

  • Page 51: Test Printing

    Test Printing Print a test pattern to check that there are no discharging defects such as nozzle clogging (slight touching of ink or nozzle missing). Relationship between head row and test pattern The relations between head row and test pattern print position are as follow. Head 1 Head 2 •...
  • Page 52 Test Printing Test Printing Print a test pattern to check that there are no discharging defects such as nozzle clogging (slight touching of ink or nozzle missing). In addition, you can select the orientation of the test pattern to print from two types in order to perform test printing repeatedly.

  • Page 53: Head Cleaning

    Head Cleaning About head cleaning Check the printed test pattern result and perform cleaning depending on the status. Select one from the three types below: SOFT : When lines are bent, when any line is missing NORMAL : When any line is missing, when colors are mixed HARD : When poor image quality cannot be improved even by NORMAL or SOFT cleaning Perform head cleaning depending on the test printing result...

  • Page 54: Set The Media Feeding

    Set the media feeding Correct the feeding rate of media. If the correction value is not appropriate, stripes may appear on the printed image, thus resulting in a poor printing. • When you have changed the media type, check the pattern and perform adjustment depending on the status.
  • Page 55 Set the media feeding Press the key. F E ED COMP . PR I N T [ EN T ] • Print a correction pattern again and check it. • When media correction is needed, perform the operation in Step 5 to make correction.

  • Page 56: Correct The Ink Drop Position For Bidirectional Printing

    Correct the ink drop position for bidirectional printing When the condition for printing (media thickness/head height/etc.) has been changed, perform the following operation to correct the ink drop position for bidirectional (Bi) printing and obtain the proper printing result. Example of a Drop Position correct Printed Pattern Output direction The dots at the fourth position counted from the zero...
  • Page 57 Correct the ink drop position for bidirectional printing Press the key. • Next test pattern is printed. • Repeat step6 and step7. Press the key several times to end the setting. Performing to correct the dot position without You can select “DROP.POScorrect” by using the key in the Local without pressing the key.

  • Page 58: Printing Data

    Printing Data Starting a Printing Operation • When using a roll media, rewind the media by hand before printing so that it is not loose.When the roll media has not been rewound tightly, it may cause the image quality to deteriorate. Setting a Media ( P.2-5) Checking the Heater Temperature...

  • Page 59: Stopping A Printing Operation Halfway

    Printing Data Stopping a printing operation halfway Perform the following operation when stopping a printing operation halfway. Press the key during printing. < L OCA L > w i d t h : 1 2 7 2 mm • The printing operation stops. •...

  • Page 60: Cutting A Media

    Printing Data Cutting a media For a roll media, two ways are available to cut the media after printing is completed, as follows. • When a media is cut, be careful that the printed side does not touch the floor or the printed side of other already cut media.
  • Page 61 Chapter 3 Extended Functions This chapter describes the operation procedures for using the machine more conveniently and each setting procedure. List of Functions ..........3-2 Setting Time..........3-21 Setting Logical Seek ........3-3 Setting Units ..........3-22 Setting a KEY BUZZER ......3-23 Setting Drying Time ........

  • Page 62: List Of Functions

    List of Functions This section describes the overview of each function to be set and set values that can be registered in user types. • About default “HOST” function You can operate this by the setting value specified in RIP software. When you set to other than “HOST”, it operates by that setting value, not by the instruction from RIP software.

  • Page 63: Setting Logical Seek

    Setting Logical Seek The motion of Head varies depending on the set of Logical-seek. • You cannot specify the logical seek at the RasterLinkPro side. When you set this machine to “Host”, printing will be performed in “LOGICAL SEEK=OFF” status. •...

  • Page 64: Setting Logical Seek

    Setting Logical Seek Press the key in LOCAL. F UNC T I ON S E TUP [ EN T [ Press the key. S E TUP F E ED COMP . [ EN T ] Press to select [LOGICAL SEEK]. S E TUP L OG I CA L SE E K [ EN T ]...

  • Page 65: Setting Drying Time

    Setting Drying Time In the drying time setting, the following items for ink drying time are set. • SCAN : Ink drying time for each scanning is set. (During bidirectional printing, the machine stops for a certain period of time specified for each of the outward and return scanning.) •...

  • Page 66: Setting Margins

    Setting Margins Set a non-printing area along the right and left edges of the media. The offset value against the standard margin 15mm is set hereupon. • When you give priority to the setting at the RIP software side, make the setting value “Host”. •...

  • Page 67: Perform Setting To Reduce Stripes Between Passes

    In case that feeding stripes cannot be resolved even though media correction is performed, make P.2-22) “MAPS (Mimaki Advanced Pass System) valid. Feeding stripes become less visible by distributing the pass boundary. (Supported from the firmware ver.2.00) • Depending on the printing condition, the effect cannot be recognized.

  • Page 68: Setting Auto Cleaning

    Setting Auto Cleaning You can set items so that the head cleaning is automatically performed when printing has been completed for the set interval. When printing has been completed, the machine count the print count printed after the previous head cleaning and performs the cleaning automatically if necessary.

  • Page 69: Setting Nozzle Face Cleaning Time

    Setting nozzle face cleaning time When the set time has passed, nozzle face of the head is cleaned automatically to remove ink droplets on the nozzle face. In case that deflection, nozzle missing, or symptom which ink droplets fall down occurred, increase the level for each type.

  • Page 70: Other Settings

    Other Settings Change the settings according to the types of use. Press the key in LOCAL. F UNC T I ON S E TUP [ EN T ] Press the key. S E TUP F E ED COMP . [ EN T ] Press to select an item for setting.

  • Page 71: Machine Settings

    Machine Settings Common settings are functions for using this machine easily. The following items can be set in Machine settings. Item Set value Default Meaning When no operation has been performed AUTO Power-off NONE/ 30min for the set time, the power supply is P.3-13 ) 10 ~ 600min automatically turned “OFF”.
  • Page 72 Item Set value Default Meaning Set whether you send/ do not send the e- Mail Delivery ON / OFF mail when the set event occurs. Print Start Set whether you send/ do not send the e- ON / OFF Event mail at the start of printing.

  • Page 73: Setting A Auto Power-Off

    Machine Settings Setting a AUTO Power-off When no operation has been performed for the set time, the power supply is automatically turned “OFF”. Press the key in LOCAL. F UNC T I ON S E T UP [ EN T ] Press to select [MACHINE SETUP].

  • Page 74: Setting The Display Of Media Residual

    Setting the Display of Media Residual Whether the screen displays the remaining amount of a media is set. the remaining amount of a media is displayed in Remote. When the media remaining amount (However, when a leaf media is used, the length of the media to be display is turned to "ON"...
  • Page 75 Machine Settings Press to input the media remain. I NPU T MED I A L ENGT H 5 0 . 0 m • Set Value : 0.0 to 500.0 min Press the key several times to end the setting. Printing the Remaining Amount of a Media The present remaining amount of a media can be printed.

  • Page 76: Adjusting The Remaining Amount In The Ink Cartridge

    Adjusting the Remaining Amount in the Ink Cartridge The remaining amount of ink in the ink cartridge can be adjusted. (available for the firmware Ver.3.40 and later) • You need a scale (which can weigh up to 1200g in 1g) to adjust the remaining amount of ink. Please prepare your scale.
  • Page 77 Machine Settings Press to select [INK REMAIN]. MACH I NE SE T UP I NK REMA I N [ EN T ] Press the key. Press to select [SET UP]. I NK REMA I N : S E T UP Press the key.
  • Page 78 Registering the case weight When using the eco case, you need to register the case weight. Follow the steps below to register the case weight. • If you replace the eco cartridge because the eco case is damaged, you need to register the case weight again in order to set the remaining amount in the ink cartridge correctly.
  • Page 79 Machine Settings Press the key. Press the key several times to end the setting. Registering the cartridge weight Calculate the remaining amount of ink from the ink cartridge weight including the IC chip and ink pack, and adjust the amount. •...
  • Page 80 Press the key. C a r t . S l o t 1 Press to enter the weight checked at the I NK REMA I N = 6 4 0 g Step 1. Check the weight and press the key. Press the key several times to end the setting.

  • Page 81: Setting Time

    Machine Settings Setting Time You can set time of your country (time difference). Press the key in LOCAL. F UNC T I ON S E T UP [ EN T ] Press to select [MACHINE SETUP]. F UNC T I ON MACH I NE SE T UP [ EN T ] Press the...

  • Page 82: Setting Units

    Setting Units Units used by this machine are set. Press the key in LOCAL. F UNC T I ON S E TUP [ EN T ] Press to select [MACHINE SETUP]. F UNC T I ON MACH I NE SE T UP [ EN T ] Press the key.

  • Page 83: Setting A Key Buzzer

    Machine Settings Setting a KEY BUZZER You can turn off the buzzer sound when pressing the key. Press the key in LOCAL. F UNC T I ON S E T UP < EN T > Press to select [MACHINE SETUP]. F UNC T I ON MACH I NE SE T UP [ EN T ]...

  • Page 84: Set The Network

    Set the network You can also perform network setting with “Network Configurator”, the tool to perform network setting of Mimaki’s product. To download the Network Configurator, check " Driver / Utility" on the download page at Mimaki Engineering (http://eng.mimaki.co.jp/download/). Press the key in LOCAL.
  • Page 85 Machine Settings Press the key. DHCP : ON • Press to set ON/ OFF. • When it is ON, the IP address given by the DHCP server is used. Press the key. NE TWORK DHCP [ EN T ] Press to select [AutoIP].

  • Page 86: Setting Event Mail Function

    You can also perform network setting with “Network Configurator”, the tool to perform network setting of Mimaki’s product. To download the Network Configurator, check " Driver / Utility" on the download page at Mimaki Engineering (http://eng.mimaki.co.jp/download/). Disclaimer •...
  • Page 87 Machine Settings Set the event to send an event mail Press the key in LOCAL. F UNC T I ON S E T UP [ EN T ] Press to select [MACHINE SETUP]. F UNC T I ON MACH I NE SE T UP [ EN T ] Press the key.
  • Page 88 Press the key several times for terminating this function. Set the e-mail address Press the key in LOCAL. F UNC T I ON S E TUP [ EN T ] Press to select [MACHINE SETUP]. F UNC T I ON MACH I NE SE T UP [ EN T ] Press the...
  • Page 89 Machine Settings Set the subject Press the key in LOCAL. F UNC T I ON S E T UP [ EN T ] Press to select [MACHINE SETUP]. F UNC T I ON MACH I NE SE T UP [ EN T ] Press the key.
  • Page 90 Set the server Press the key in LOCAL. F UNC T I ON S E TUP [ EN T ] Press to select [MACHINE SETUP]. F UNC T I ON MACH I NE SE T UP [ EN T ] Press the key.
  • Page 91 Machine Settings Press the jog key S ERV ER S E T UP select [Authentication] . A u t h e n t i c a t i o n [ EN T ] Press the key. A u t h e n t i c a t i o n : POP b e f o r e SMT P Press to set authentication method .
  • Page 92 Press the key. P a s s Wo r d * * * * * * * * * * * * * * * • Press to set the password to use for the authentication. • Set it with alphanumeric characters and symbols within 15 characters. •...
  • Page 93 Machine Settings Send a test e-mail Press the key in LOCAL. F UNC T I ON S E T UP [ EN T ] Press to select [MACHINE SETUP]. F UNC T I ON MACH I NE SE T UP [ EN T ] Press the key.
  • Page 94 • The sent result of the test e-mail is the result of e-mail sending process performed by this machine to the e-mail server. It does not indicate that the e-mail was received at the address. • If the spam e-mail filter etc. has been set in the terminal in which e-mails are received, even if “Sending has been completed”...

  • Page 95: Setting A Language

    Machine Settings Setting a LANGUAGE You can change the displayed language. Press the key in LOCAL. F UNC T I ON S E T UP [ EN T ] Press to select [MACHINE SETUP]. F UNC T I ON MACH I NE SE T UP [ EN T ] Press the key.

  • Page 96: Initializing The Settings

    Initializing the Settings You can return the setting of “SETUP”, “MAINTENANCE” and “MACHINE SETUP” to the status before shipment. Press the key in LOCAL. F UNC T I ON S E TUP [ EN T ] Press to select [MACHINE SETUP]. F UNC T I ON MACH I NE SE T UP [ EN T ]...

  • Page 97: Confirming Machine Information

    Confirming Machine Information The information of this machine can be confirmed. The following items can be confirmed as machine information. Item Description This displays the history of errors and warnings to date. When you press , the date of occurrence (year/ ERROR HISTORY month/day/hour/minute) and the error/warning information are displayed alternately in the order of occurrence.
  • Page 98 Press the key. • The wiping Information is displayed. • Every time when you press the key, the next machine information is displayed sequentially. WIPING WASTE INK TANK Displays wiping Displays waste ink WI P I NG W ASTE I NK TANK information.

  • Page 99: Check Such As The Machine Version Information

    Confirming Machine Information Check such as the machine version information Press the key in LOCAL. F UNC T I ON S E T UP [ EN T ] Press to select [INFORMATION]. F UNC T I ON I N FORMA T I ON [ EN T ] Press the key.

  • Page 100: Displaying The Information Of This Machine

    Confirming Machine Information Displaying the Information of this machine Press the key in LOCAL. * * * I NK MMCCY YK K REMA I N 9 9 9 9 9 9 9 9 The information is displayed sequentially with the key .
  • Page 101 Chapter 4 Maintenance This chapter describes the items required to use this machine more comfortably, which are the methods for the daily care, the maintenance of the ink unit etc. Maintenance ..........4-2 Automatic Maintenance Function ....4-29 Precautions for Maintenance ...... 4-2 Setting the Refreshing Intervals ....4-29 About Maintenance washing liquid ....

  • Page 102: Maintenance

    Maintenance Maintain the machine regularly or as necessary so that its accuracy will be maintained and it can continue to be used for a long time. Precautions for Maintenance Pay attention to the following items when maintaining this machine. • When using maintenance washing liquid for maintenance, be sure to wear the supplied protective glasses.

  • Page 103: Cleaning The Exterior Surfaces

    Maintenance Cleaning the Exterior Surfaces When the exterior surfaces of the machine are stained, dampen a soft cloth with water or a neutral detergent diluted with water, squeeze it, and wipe the surfaces with the cloth. Cleaning the Platen The platen easily gets dirty with lint, paper dust, etc. generated when a media is cut.

  • Page 104: Cleaning The Media Sensor

    Maintenance Cleaning the Media Sensor The media sensors are located on the platen in the backside and the bottom surface of the head. When the sensor is covered with dust, etc., it may cause false detection of media. Using a cotton swab, remove the dust, etc. accumulated on the surface of the sensor. When cleaning the sensor on the lower surface of the head is cleaned, move the carriage to the left end by the operations of step 1 of P.4-16 “Cleaning the Head and the Area around It (every day)”, and then clean it.

  • Page 105: Maintaining The Capping Station

    Maintaining the Capping Station Maintain the ink cap, wiper, etc. located in the capping station. (SATION MAINT.) • To keep the nozzle status normal, perform wiper cleaning C l e a n i n g WI P ER frequently. [ M N T ] •...
  • Page 106 • The shape of the area around the wiper has changed. Check the shape of the wiper slider of the machine you are using and perform maintenance in accordance with the shape. Wiper slider Wiper slider “Procedure1” of P.4-6 “Procedure2” of P.4-9 Procedure1 Press the key in LOCAL.
  • Page 107 Maintaining the Capping Station Put the wiper that you used for one day into a provided case or solvent-resistance- covered-container (glass, earthenware, etc.) and pour maintenance washing liquid LX. • Time to immerse the wiper shall be for 1 to 24 hours. •...
  • Page 108 Set the wiper at the original position. Projection • Insert the wiper by holding both ends of the wiper. Clean the cap rubber and cap rubber cover. • Wipe off the ink sticking to the cap rubber and cap rubber cover with a clean stick dipped in maintenance washing liquid LX for maintenance.
  • Page 109 Maintaining the Capping Station Procedure2 Press the key in LOCAL. CARR I AGE OU T MAINT. [ EN T ] Press the key. MOVE POS I T I ON : S T A T I ON MA I N T . Press to select [STATION MAINT.].
  • Page 110 Put the wiper that you used for one day into a provided case or solvent-resistance- covered-container (glass, earthenware, etc.) and pour maintenance washing liquid LX. • Time to immerse the wiper shall be for 1 to 24 hours. • If you leave the wiper immersed in maintenance washing liquid LX too long, the wiper may be deformed.
  • Page 111 Maintaining the Capping Station Clean the cap rubber and cap rubber cover. • Wipe off the ink sticking to the cap rubber and cap rubber cover with a clean stick dipped in maintenance washing liquid LX for maintenance. (Wipe off so that you can see color of the cap rubber.) Wipe off so that maintenance washing liquid LX for maintenance will not remain.

  • Page 112: Washing The Ink Discharge Passage (Disway Wash)

    Washing the Ink Discharge Passage (DISWAY WASH) • Wash the ink discharge passage regularly(about once a week) to prevent the head nozzles from clogging due to ink coagulation inside the passage. Press the key in LOCAL. CARR I AGE OU T MAINT.

  • Page 113: When The Machine Is Not Used For A Long Time (Custody Wash)

    Maintaining the Capping Station When the Machine Is Not Used for a Long Time (CUSTODY WASH) When the machine is not going to be used for a week or more, use the cleaning function for custody to clean the head nozzles and ink discharge passage.After this, keep the machine in custody. •...
  • Page 114 Press the key. CA P C L E AN I NG COMP L E T ED ( NEX T ) [ EN T ] • The carriage moves onto the platen. • Until wiper cleaning is competed, [COMPLETED (NEXT): ENT] is displayed on the screen. After the work up to the step 6 is completed, press the key.
  • Page 115 Maintaining the Capping Station Open the right maintenance cover. Fill up the cap with maintenance washing liquid LX for maintenance． • Suck maintenance cleaning solution into a dropper and fill up the cap with it. Fill up the cap with cleaning solution on the verge of overflow from the cap.

  • Page 116: Cleaning The Head And The Area Around It (Every Day)

    Cleaning the Head and the Area around It (every day) Because the head employs a very precise mechanism, due care needs to be taken when it is cleaned. Using a clean stick, etc., rub off gelatinous ink or dust that may stick to the lower part of the slider and the area around the head.In doing so, never rub the nozzles of the head.
  • Page 117 Cleaning the Head and the Area around It (every day) Wipe ink sticking to the side of the head off with a clean stick. • To prevent gelled/ solid ink ground from pooling at the front of the carriage, scrape them off with clean stick etc.

  • Page 118: Replacing Method Of C Absorber Kit

    Replacing method of C absorber kit Dirty C absorber If ink adheres to the C absorber, it is required to replace the C absorber. Rough guide for replacement: Replace when the concavity and convexity of the surface of the absorber are filled with ink as indicated in the right photo. In addition, when you replace the C absorber, clean ink adhering to the capping station at the same time.
  • Page 119 Replacing method of C absorber kit Insert a new C absorber. C absorber • There are two types’ absorbers and four in total (C absorber x 1, C absorber 2 x 3). • Be careful not to mess up the positions to which they are inserted.

  • Page 120: When Nozzle Clogging Cannot Be Solved

    When Nozzle Clogging Cannot Be Solved When nozzle clogging cannot be solved even after the head cleaning ( P.2-21) has been done, perform the following two functions: NOZZLE WASH • Wash the head nozzle. ( P.4-20) Washing nozzle surface • Wash the nozzle surface. ( P.4-22) •...
  • Page 121 When Nozzle Clogging Cannot Be Solved Press the key. CA P C L E AN I NG COMP L E T ED ( NEX T ) [ EN T ] • The carriage moves onto the platen. • Until wiper cleaning is competed, [COMPLETED (NEXT): ENT] is displayed on the screen. After the work up to the step 6 is completed, press the key.

  • Page 122: Washing Nozzle Surface

    Washing nozzle surface Using dedicated washing liquid and a waste cloth, clean the nozzle surface of the head. • Perform this if discharging defect such as nozzle clogging (slight touching of ink or nozzle missing) cannot be improved even if you performed head cleaning ( P.2-21) and nozzle washing ( P.4- 20).
  • Page 123 When Nozzle Clogging Cannot Be Solved Open the left maintenance cover. Screw Rotate it left. (1) Turn four screws that fix the maintenance cover to the left, and remove them. (2) Remove the maintenance cover. • If the maintenance cover is hard to remove, use the Maintenance supplied screwdriver.

  • Page 124: When Nozzle Missing Occurs Due To Ink Mixture Or Aeration

    When nozzle missing occurs due to ink mixture or aeration Push out ink and air in the head from the port. Use this when ink has been mixed in the port, or nozzle missing due to aeration occurs. In addition, if nozzle missing cannot be solved even if you performed cleaning because it has not been used for long time (for about two weeks), perform air purge.
  • Page 125 When Nozzle Clogging Cannot Be Solved Press the key. A I R PG COMP L E T ED [ EN T ] • Start pushing ink out. • Flow ink in the jig by 10cm. • Flow ink from all ports of the damper selected in the Step 3. Reference value : About 10cm Terminate air purge by pressing the...

  • Page 126: Alternative Nozzles For Printing, When Nozzles Missing Can Not Be Improved

    Alternative nozzles for printing, when nozzles missing can not be improved NOZZLE RECOVERY: When nozzles missing can not be improved at specific points, other good nozzles can be used as alternatives for printing. Select [NOZZLE RECOVERY] of the maintenance menu. (1) Press the key in LOCAL.
  • Page 127 When Nozzle Clogging Cannot Be Solved Register the Nozzle number that needs NOZZLE H 1 - A RECOVERY and then press key. N o . 1 : 1 8 4 (1) Select the registration number from 1 to 10 by pressing key and press the Recovery nozzle No.: (2) Register the nozzle number that needs recovery by pressing...
  • Page 128 When Nozzle Clogging Cannot Be Solved Select the [CHECK] by pressing key.  NOZ Z L E RECOVERY : CHECK Press the key. Level at printing white layer • The mode for which nozzle recovery is invalid is displayed. • If there is no mode for which nozzle recovery is invalid, “NONE” is UNRECOV ERA B L E COND .

  • Page 129: Automatic Maintenance Function

    Automatic Maintenance Function To use this machine comfortably, you can set various maintenances to be performed automatically. Here, set performing intervals of various automatic maintenances. You can prevent troubles such as ink clogging by performing automatic maintenance periodically (automatic maintenance function). For the auto maintenance functions, the following items can be set: •...

  • Page 130: Setting The Cleaning Intervals

    Setting the Cleaning Intervals The cleaning type and the interval between each cleaning operation are set. Select [AUTO MAINT.] of the maintenance menu. (1) Press the key in LOCAL. (2) Press to select [MAINTENANCE] and press the key. (3) Press to select [AUTO MAINT.].
  • Page 131 Automatic Maintenance Function Setting the Cleaning Intervals Set the cleaning type and intervals for cleaning of white ink. Select [AUTO MAINT.] of the maintenance menu. (1) Press the key in LOCAL. (2) Press to select [MAINTENANCE] and press the key. (3) Press to select [AUTO MAINT.].

  • Page 132: Replacing Consumables

    Replacing consumables Replacing the wiper The wiper is consumable.When the display indicates that it is necessary to < L OCA L > check and replace the wiper, immediately replace the wiper with a new one. R e p l a c e a WI P ER [ M N T ] Also, wipe ink sticking to the lower surface of the slider off.

  • Page 133: If A Waste Ink Tank Confirmation Message Appears

    Replacing consumables If a Waste Ink Tank Confirmation Message Appears Ink used in head cleaning, etc. is stored in the waste ink tank on the lower right side of the machine.This machine counts the accumulated amount of discharged ink. When that reaches a specified amount, the machine displays a confirmation message.(When this message is displayed, consider the replacement of the waste ink tank.) •...
  • Page 134 Replace the waste ink tank with another The message on the right is displayed. < L OCA L > C h e c k w a s t e i n k [ MN T ] Press the key and check the state of the waste C o n f i r m a w a s t e t a n k MAINT.
  • Page 135 Replacing consumables Close the waste ink tank guard. Press the key. COUN T C L EAR E X ECU T E [ MN T ] • The ink discharging amount that is controlled by the machine is reset and the message is cancelled. 4-35...

  • Page 136: Replacing The Waste Ink Tank Before The Waste Ink Tank Confirmation Message Is Displayed

    Replacing the waste ink tank before the waste ink tank confirmation message is displayed if you replace the waste ink tank before the waste ink tank confirmation message is displayed (before the 2L tank is 80% (1.6L) full), set the waste ink information to 0% in the Information menu. Perform steps 3 through 6 in "Replace the waste ink tank with another"...

  • Page 137: Replacing The Cutter Blade

    Replacing consumables Replacing the Cutter Blade The cutter blade is consumable.When the cutter blade gets dull, replace it with a new one (SPA-0107). • The blade is sharp.Be careful not to hurt yourself or anyone else. • Store the cutter blade in a place that is out of the reach of children.In addition, dispose of used cutter blades according to regional laws and regulations.
  • Page 138 Replacing consumables Close the right maintenance cover. Press the key. • The screen returns to step1. 4-38...
  • Page 139 Chapter 5 Troubleshooting This chapter describes the corrective measures to be taken for a phenomenon suspected to be trou- ble and the procedures to clear the error number displayed on the LCD. Troubleshooting ................5-2 Power does not turn on ..............5-2 The machine does not start printing ..........5-2 Media get jammed / media is soiled ..........5-3 [HEAT] or [CONSTANT] LED does not light up .......5-3...

  • Page 140: Power Does Not Turn On

    Troubleshooting Take appropriate actions as described below before taking the trouble as a failure. If still the problem is not solved after troubleshooting, contact your dealer or an office of MIMAKI. Power does not turn on In most cases, this is due to improper connection of the power cable for the machine or computer. Check that the power cable is connected properly.

  • Page 141: Media Get Jammed / Media Is Soiled

    Troubleshooting Media get jammed / media is soiled Media jamming or stained media is considered to be due to the use of an unsuitable media or improper setting of media. Is a recommended media used ? Use recommended media. Is the media not curled or bent ends ? Avoid using any media with curls or bent ends.

  • Page 142: Image Quality Is Poor

    This section describes the corrective actions to be taken in case the image quality is not satisfactory. Take remedy for particular problems with image quality. If the remedy does not work, contact your dealer or an office of MIMAKI. Phenomenon Measures (1) Execute the head cleaning.

  • Page 143: Ink Cartridge Warning Appears

    • Once cartridge trouble is displayed, do not leave the ink cartridge without replacing it for a long time; otherwise, the machine will lose the nozzle clogging prevention function. If nozzles are clogged, the machine must be repaired by MIMAKI's service engineer. Displaying the description of ink cartridge trouble The contents of cartridge error are confirmable by the following operations.

  • Page 144: Check Ink Pack" Appears

    “Check Ink Pack” appears When you are using the eco cartridge and there is a problem with the ink pack, the cartridge lamp lights up red, a warning message is displayed and all the operations related to the ink supply become unavailable. Check whether there is any ink left inside the ink pack as soon as possible.

  • Page 145: When The Ink Remain Setting Message Is Displayed

    Troubleshooting When the INK REMAIN Setting Message is Displayed If the remaining amount of ink inside the cartridge falls below a specified level when [SET UP] in INK REMAIN of MACHINE SETUP is set to “ON” ( P.3-31), a warning message appears on the display. When the message appears, perform the following steps to adjust the ink cartridge weight.

  • Page 146: When Error 618 To 61B Occur

    When Error 618 to 61b occur Error 618 to 61b are errors related to the damper. Execute following procedures when an error about damper occurs, or when the nozzle is not unclogged after cleaning. Select [DAMPER] of the maintenance menu. (1) Press the key in LOCAL.

  • Page 147: Regular Maintenance Of White Ink

    Troubleshooting Regular maintenance of white ink White ink precipitates easier than other inks. • If not printing more than two weeks, white ink may precipitate in the ink cartridge or inside of this machine. • When an ink precipitates, the nozzle may be clogged and it can not draw normally. •...

  • Page 148: When Media Heaves Up At Feeding

    Troubleshooting When media heaves up at feeding We call the status of heaving media at feeding “cockling”. When media cockling occurs, check the following items: Note/ checking items Measures Checking media set status (1) Check that the media is set straight and reset it. (1) Raise the pre-heater temperature by 5 to 10 degrees.

  • Page 149: Warning / Error Messages

    Warning / Error Messages If some trouble occurs, the buzzer sounds and the display shows a corresponding error message. Take an appropriate remedy for the displayed error. Warning messages Errors when performing operations Message Cause Solution • Check the front cover and maintenance covers.
  • Page 150 Message Cause Solution • Press the key to perform print- < L OC A L > The data has been received. ing. Or, perform data clear. D A T A R EMA I N • Press the key to check the rele- The ink of the ink cartridge has been <...
  • Page 151 Warning / Error Messages Message Cause Solution • Open the maintenance cover and check C h e c k J a m S e n s o r The jam sensor detects an error. around the carriage. • Close the cover or eliminate the media Print interrupted by the cover open or P R I N T I NG P A U S E jam.Select the action by the right or left...

  • Page 152: Error Messages

    Error messages When an error message is displayed, eliminate the error according to the chart below. If the same error message appears again, contact your dealer or an office of MIMAKI to call for service. Message Cause Solution E R ROR 1 0 8 Head connection can not be confirmed.
  • Page 153 Warning / Error Messages Message Cause Solution An error occurred in the main PCB E R ROR 1 6 e 3.3VB power supply. M a i n P C B V 3 R 3 B COM driver becomes the high tempera- E R ROR 1 5 f ture.
  • Page 154 Message Cause Solution E R ROR 3 0 4 USB device initialization failure. U S B I N I T E R R Occurrence of a time out error on a E R ROR 3 0 5 USB device. U S B T I ME OU T An excessive load was applied to the X E R ROR 4 0 1 •...
  • Page 155 Warning / Error Messages Message Cause Solution Though a certain amount was con- Perform “DAMPER ( P.5-8) ” of the E R ROR 6 1 9 sumed, there is no change in the D AMP E R / L OW : 1 2 3 4 5 6 7 8 maintenance.
  • Page 156 Warning / Error Messages SYSTEM HALT Message Solution Turn off the main power to the machine and turn it on after a while. S Y S T EM H A L T If the same error message appears again, check the number and contact your local dis- 0 0 0 : ME S S A G E tributor to call for service.
  • Page 157 Chapter 6 Appendix This chapter contains the lists of the specifications and functions of this machine. Specifications ..................6-2 Machine specifications ..............6-2 Ink specifications ................6-3 Setting orders depending on ink type ..........6-4 Setting orders of ink cartridges ............6-4 Sheet for inquiry ................6-5 Warning labels .................6-6 Function Flowchart ................6-8...

  • Page 158: Specifications

    Specifications Machine specifications Item JV400-130LX JV400-160LX Method Drop-on-demand piezoelectric print heads Print head Specification 2 head 600x900 : Bi/Uni 6/12/24pass 900x900 : Bi/Uni 6/12/24pass 4-color 900x1200 : Bi/Uni 8/16/32pass 1200x900 : Bi/Uni 6/12/24pass 1200x1200 : Bi/Uni 8/16/32pass Drawing mode (scan...

  • Page 159: Ink Specifications

    Specifications Item JV400-130LX JV400-160LX Cutting of Y direction by the head cutter, Cutting of media Cutting accuracy (steps) : 1.0 mm or less. Take-up device supplied as a standard accessory Media delivery (switching possible between face in and face out).

  • Page 160: Setting Orders Depending On Ink Type

    Setting orders depending on ink type The setting value and the setting orders of the ink cartridges differ depending on the ink type you use. Setting orders of ink cartridges The orders of ink cartridges set in the ink station differ depending on the ink set you use. •...

  • Page 161: Sheet For Inquiry

    Sheet for inquiry Use this sheet for troubles and abnormal functions of the machine. Fill in the following necessary items, and then fax the sheet to our sales office. Company name Person in charge Telephone number machine model Operating OS Machine information Error message Contents of inquiry...

  • Page 162: Warning Labels

    Warning labels Warning labels are stuck on the machine. Be sure to fully understand the warning given on the labels. If a warning label is illegible due to stains or has come off, purchase a new one from a distributor or our sales office.

  • Page 163: Warning Labels

    Be careful of the cutter blade. M907935 Be careful with electric shocks as the voltage is hazardous. M906031 This product has multiple power cords. To turn off the power to this product completely, remove all power plugs. M908546 (JV400-130LX) M908545 (JV400-160LX)

  • Page 164: Function Flowchart

    Function Flowchart < L OC A L > WH I D T H : * * * * mm OR I G I N S E T U P OR I G I N S E T U P 0 . 0 - - - - * * OR I G I N * * ME D I A CU T...
  • Page 165 Function Flowchart F A N H E A T E R 1 0 ° C ) : R E A D Y ( * * C L E A N I NG * * P L E A S E WA I T T E S T F E E D * * T E S T F E E D * * [ E N T ]...
  • Page 166 From P.6-8 F E E D COMP . F E E D COMP . ADJUST [ E N T ] P R I N T [ E N T ] ADJUST DROP . POS c o r r e c t DROP .
  • Page 167 Function Flowchart * * P R I N T I NG * * F E E D COMP . P L E A S E WA I T -9999 to 9999 * * P R I N T I NG * * P A T T E RN 1 P A T T E RN 2 P L E A S E WA I T...
  • Page 168 < L OC A L > F UNC T I ON SETUP WH I D T H : * * * * mm S E T U P [ E N T ] F UNC T I ON MAINTENANCE MA I N T E N A NC E [ E N T ] F UNC T I ON MACHINE SET...
  • Page 169 Function Flowchart To P.6-14 To P.6-18 To P.6-22 W I P I NG WA S T E I N K T A N K P R I N T L E NG T H P R I N T A R E A U S E T I ME F I L T E R ( Wh i t e ) F I L T E R...
  • Page 170 SETUP S E T U P F E E D COMP . * * P R I N T I NG * * F E E D COMP . [ E N T ] P R I N T [ E N T ] P L E A S E WA I T S E T U P DROP .
  • Page 171 Function Flowchart F E E D COMP . Print end -9999 to 9999 P A T T E RN 1 P A T T E RN 2 Print end 0 . 0 0 . 0 -40.0 to 40.0 -40.0 to 40.0 POS T F A N H E A T E R O F F...
  • Page 172 From P.6-14 S E T U P F E E D S P E E D F E E D S P E E D [ E N T ] HOS T HOST / 10 to 200% S E T U P MA P S P R I N T S P E E D A D J U S T MA P S...
  • Page 173 Function Flowchart Displayed when “MANUAL” is set. T Y P E 1 9 0 s e c 90 to 600 sec T Y P E 2 1 0 m i n 10 to 90 min 6-17...
  • Page 174 MAINTENANCE MA I N T E N A NC E S T A T I ON MOV E POS I T I ON S T A T I ON [ E N T ] C A RR I AGE OU T [ E N T ] S T A T I ON MA I N T .
  • Page 175 Function Flowchart C A RR I AGE OU T C l o s e a c o v e r To Local after initializing COMP L E T E D [ E N T ] C A P C L E A N I NG F i l l t h e l i q u i d .
  • Page 176 From P.6-18 MA I N T E N A NC E A U T O MA I N T . R E F R E S H A U T O MA I N T . [ E N T ] R E F R E S H [ E N T ] : L v .
  • Page 177 Function Flowchart T Y P E : NORMA L NORMAL / SOFT / HARD T Y P E : NORMA L NORMAL / SOFT / HARD * * C L E A N I NG * * * * F I L L I NG * * P L E A S E WA I T P L E A S E WA I T A I R PG...
  • Page 178 MACHINE SET MA CH I N E S E T U P A U T O P o w e r - o f f A U T O P o w e r - o f f [ E N T ] 3 0 m i n none/ 10 to 600min MA CH I N E S E T U P...
  • Page 179 Function Flowchart C a r t . S l o t C a r t . S l o t 6 4 0 g OK ? [ E N T ] I n k L e v e l S e t = 6 4 0 g C a r t .
  • Page 180 From P.6-22 From P.6-22 N E TWOR K DHC P DHC P [ E N T ] : ON ON, OFF N E TWOR K A u t o I P A u t o I P [ E N T ] : ON ON, OFF Settable when [DHCP] and [AutoIP] are both OFF...
  • Page 181 Function Flowchart P r i n t E n d E v e n t E r r o r E v e n t Wa r n i n g E v e n t : O F F : O F F : O F F ON, OFF...
  • Page 182 From P.6-24 From P.6-24 E V E N T MA I L S E R V E R S E T U P S e r v e r S e t u p [ E N T ] SMT P A d d r e s s [ E N T ] S E R V E R S E T U P SMT P P o r t N o .
  • Page 183 Function Flowchart SMT P A d d r e s s SMT P P o r t N o . S E ND E R A DDR E S S A u t h e n t i c a t i o n : O F F OFF, POP before SMTP, SMTP Authentication...
  • Page 184 6-28...
  • Page 185 JV400-130LX/160LX Operation Manual December, 2015 MIMAKI ENGINEERING CO.,LTD. 2182-3 Shigeno-otsu, Tomi-shi, Nagano 389-0512 JAPAN D202283-26-22122015...
  • Page 186 FW : 3.4 © MIMAKI ENGINEERING CO., LTD.2015...

This manual is also suitable for:

Jv400-160lx

Table of Contents
