BODY EXPLODED VIEWS

Dash Instruments / Controls (RZR / RZR S)

A. Instrument Cluster (Speedo)
B. Headlight Switch
C. 2WD/AWD Switch
D. 12 Volt Accessory Receptacle
E. Speedometer "Mode" Button
F. Key Switch
BODY / STEERING / SUSPENSION
F
A
5
E
D
C
B
5.5
