Sandpiper Installation Guide
Fan speed display
High / Medium / Low / Auto
Clock & Timer display
Real time clock
Timer ON / Timer OFF
On / Off
Turns unit from standby to
ON and vice versa
Mode
COOL – decrease air temperature
DRY – dehumidify the air
HEAT – increase room temperature
AUTO – automatically selects heat
or cooling mode as required
FAN – circulates air
Sleep
Allows the controller to gradually
depart from the set point
temperature while you sleep
Timer on & timer off
These timer buttons will not set the
timer on the actual unit.
th
28 May 2013 – Revision 7
Figure 11-Remote control functions
Clock
Used to set local
time on the
remote
Temperature set point display
COOL / DRY / HEAT/ AUTO / FAN
Increase or decrease the desired
temperature set point for your
Also acts to increase / decrease time
during timer & clock setting
Select from High, Medium and Low
In cooling and heating mode AUTO
FAN speed can be selected
Transmit the remotes settings
Set
Used to finish
clock & timer
settings
Page 15 of 22
16 °C – 30 °C
Mode display
Sleep function display
Temperature up / down
comfort.
Fan speed
Send
to the air conditioner
Backlight display
Turn on display back
light for 5 seconds
