Tennant 607647 Operator And Parts Manual

Tennant 607647 Operator And Parts Manual

1500 battery automatic carpet extractor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model No.:
607647
607653 – Pac
TENNANT COMPANY
Commercial Products
12875 RANSOM STREET
HOLLAND MI 49424 U.S.A.
FAX: 1–800–678–4240
CUSTOMER SERVICE: 1–800-982–7658
Battery Automatic Carpet Extractor
Home Find... Go To..
1500
Operator and Parts Manual
Rev. 01 (02-02)
607648

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 607647 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tennant 607647

Summary of Contents for Tennant 607647

  • Page 1 1500 Battery Automatic Carpet Extractor Model No.: Operator and Parts Manual 607647 607653 – Pac TENNANT COMPANY Commercial Products 12875 RANSOM STREET HOLLAND MI 49424 U.S.A. 607648 FAX: 1–800–678–4240 Rev. 01 (02-02) CUSTOMER SERVICE: 1–800-982–7658 Home Find... Go To..

  • Page 2: Table Of Contents

    Parts and supplies may be Serial No.- ordered by phone or mail from any authorized Service Center or Distributor. E2002 Tennant Company Printed in U.S.A. Specifications and parts are subject to change without notice. This machine will provide excellent service. However, the best results will be obtained at minimum costs if: The machine is operated with reasonable care.

  • Page 3: Safety Precautions

    Always follow safety and traffic rules. – Report machine damage or faulty operation immediately. – Follow mixing and handling instructions on chemical containers. 4. Before leaving or servicing machine: – Stop on level surface. – Turn off machine. Tennant 1500 (11–99) Home Find... Go To..

  • Page 4: Machine Components

    CONTROL PANEL SYMBOLS Main Less Brush Read Manual Fast Power Pressure Before Operating Speed More Brush Pump Slow Main Power Pressure Speed Circuit Breaker Battery Vacuum Vacuum/drive Charge Motor Circuit Reverse Meter Breaker Tennant 1500 (05–99) Home Find... Go To..

  • Page 5: Machine Installation

    (15 in) L x 356 mm (14 in) H. 1. Turn all switches to the OFF position. 2. Carefully hinge open recovery tank to access battery compartment. Remove loose battery cable from compartment (Figure 1). FIG. 3 FIG. 1 Tennant 1500 (05–99) Home Find... Go To..

  • Page 6: Machine Setup

    3. Turn on vacuum and pump switches. 2. Squeeze levers together and lift or lower control NOTE: The brush and pump will start once control grips to a comfortable operating height grips are rotated. (Figure 5). Tennant 1500 (05–99) Home Find... Go To..

  • Page 7: While Operating Machine

    9. If the cleaning path leaves streaks, spray tip cleaning is required (See Weekly Maintenance). FIG. 8 8. After cleaning carpets, allow sufficient time for carpet to dry. Use a carpet blower to reduce drying time. Tennant 1500 (05–99) Home Find... Go To..

  • Page 8: Circuit Breakers

    6. Turn on main, pump and vacuum switches. 7. Take accessory tool and begin cleaning at top of area and work backwards toward machine. WARNING: Flammable materials or reactive metals can cause explosion or fire. Do not pick Tennant 1500 (02–02) Home Find... Go To..

  • Page 9: Draining Tanks

    Vacuum damage due to foam or water 3. When reconnecting clear hose to hose barb, be is not covered by warranty. certain hose is completely pushed onto hose barb. Tennant 1500 (11–99) Home Find... Go To..

  • Page 10: Battery Charging

    6. Then plug the charger’s power supply cord into a grounded wall outlet (Figure 19). Grounded Grounded Outlet 3 Hole Outlet Grounding Edge/hole Ground Pin (120V) (230V/240V) FIG. 16 FIG. 19 FOR SAFETY: Do not operate charger unless cord is properly grounded. Tennant 1500 (02–02) Home Find... Go To..

  • Page 11: Machine Maintenance

    DAILY MAINTENANCE (Every 4 Hours of Operation) 1. Recharge batteries if discharged below 50%. 2. Remove float shut-off screen and rinse off. Screen is located in recovery tank (Figure 21). FIG. 22 Tennant 1500 (02–02) Home Find... Go To..

  • Page 12: Monthly Maintenance

    Next day, operate pump to disperse remaining 1. Always follow proper charging instructions (See acetic acid solution. Battery Charging). g. Then rinse out solution tank and solution lines with clean water. h. Reset drive circuit breaker button when completed. Tennant 1500 (02–02) Home Find... Go To..

  • Page 13: Storing Machine

    1. Before storing machine, be certain to rinse tanks and drain machine of all water. 2. Store machine in a dry area. 3. Remove recovery lid to promote air circulation. 4. Raise the brush/pickup head off the floor. Tennant 1500 (02–02) Home Find... Go To..

  • Page 14: Trouble Shooting

    Faulty pump or solenoid. Contact Service Center. Short run time. Batteries not fully charged. Charge batteries. Bad cell in one or more batteries. Replace battery. Batteries need maintenance. See Battery Maintenance. Faulty charger. Replace battery charger. Tennant 1500 (05–99) Home Find... Go To..

  • Page 15: Specifications

    VACUUM MOTOR 1 h.p., 2–stage 7.2”, 24V, 30A, 720W WATERLIFT 2057 mm (81 in) BATTERIES 2–12V, 215AH RUN TIME PER CHARGE Up to 4.5 hours DECIBEL RATING AT OPERATOR’S EAR, 75dB(A) INDOORS ON CARPET Tennant 1500 (05–99) Home Find... Go To..

  • Page 16: Electrical Diagrams

    MAIN DRIVE VACUUM CIRCUIT CIRCUIT MOTOR BREAKER BREAKER DRIVE MOTOR PUMP BRUSH SPEED MOTOR CONTROL BOARD SOLUTION SOLENOID POSITIVE STANDOFF NEGATIVE STANDOFF CHARGER CUTOFF SWITCH CHARGER PLUG (2) 12 VOLT BATTERIES 24 VDC Tennant 1500 (02–97) Home Find... Go To..

  • Page 17: Electrical Diagram

    -31- -BLK- -15- -BLK- "BRUSH/ BRUSH PUMP" MOTOR -38- -48- -WHT- -BLK- -23- -28- -BLU- -BLK- -GRN- -RED- ROLL SWITCH -26- -41- -BLK- -BLU- SOLUTION SOLENOID -36- -36- SOLUTION -RED- -RED- -BLK- PUMP Tennant 1500 (02–97) Home Find... Go To..

  • Page 18: Parts List

    PARTS LIST SOLUTION TANK GROUP 19 20 22 18 Tennant 1500 (02–02) Home Find... Go To..
  • Page 19 CLAMP, HOSE 2 WIRE 630011 TUBE, ADAPTER 612056 CASTER 4” 630267 SPRING, COMP 140036 WASHER, FLAT 630016 RING, RETAINING 140333 WASHER, LOCK 608706 BRACKET, VAC TUBE 140277 SCREW, M10X1.5X20MM 140027 WASHER, FLAT D RECOMMENDED STOCK ITEMS Tennant 1500 (02–02) Home Find... Go To..

  • Page 20: Recovery Tank Group

    PARTS LIST RECOVERY TANK GROUP Tennant 1500 (02–02) Home Find... Go To..
  • Page 21 140052 WASHER, LOCK 200031441 SCREW M6X1.0X25 HXHDCP 140000 WASHER, FLAT 603962 SCREW M6X1.0X60 HXHDCP DHINGE, RECOVERY TANK 140960 CABLE, SUPPORT 600311 140027 WASHER, FLAT ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS Tennant 1500 (02–02) Home Find... Go To..

  • Page 22: Lift Group

    PARTS LIST LIFT GROUP 24 22 Tennant 1500 (02–02) Home Find... Go To..
  • Page 23 BRACKET, BUMPER WHEEL 140516 NUT, NYLOCK 630477 WHEEL, 2” GRAY 140045 WASHER, FLAT 140515 NUT, NYLOCK 602567 BRACKET, SPRING 36758 BOLT, SHOULDER 602882 BUSHING 140046 WASHER, 1.00X.392X.090 140024 WASHER, LOCK D RECOMMENDED STOCK ITEMS Tennant 1500 (02–02) Home Find... Go To..

  • Page 24: Brush Base Group

    DBELT, TIMING 100049 SEAL, BRUSH BEARING 230409 140125 BEARING, BRUSH 130154 DOME PLUG 230261 BLOCK, BEARING 140859 SCREW, SET 1/4–20X1/4 100005 GASKET, BEARING BLOCK ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS Tennant 1500 (02–02) Home Find... Go To..

  • Page 25: Drive Group

    HUB, WHEEL TRANSAXLE 607452 WHEEL, 8” 140552 NUT, 10–24 NYLOCK 140000 WASHER, FLAT 31249 BOLT, SHOULDER .25X1.25 140501 NUT, 1/4–20 NYLOCK 32982 WASHER, INT. LOCK ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS Tennant 1500 (02–02) Home Find... Go To..

  • Page 26: Plumbing Group

    PARTS LIST PLUMBING GROUP PUMP BREAKDOWN Tennant 1500 (02–02) Home Find... Go To..
  • Page 27 700423 ASM., SPRAY BAR 190131 DKIT, PUMP LOWER HOUSING 150921 PLUG, QUICK COUPLER 190130 150422 FITTING, 1/8MX1/8F ELB STRT 45° 130096 TERMINAL, MALE .25 ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS Tennant 1500 (02–02) Home Find... Go To..

  • Page 28: Console Group

    PARTS LIST CONSOLE GROUP Tennant 1500 (02–02) Home Find... Go To..
  • Page 29 200031488 SCREW, M8X1.25X20MM 140155 BUSHING 606549 DECAL, SPEED CONTROL DHARNESS, WIRE MAIN 606550 KNOB, SPEED CONTROL 613092 603007 BUSHING, SNAP 604486 ASM., DIODE SPLICED ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS Tennant 1500 (02–02) Home Find... Go To..

  • Page 30: Electrical / Battery Group

    PARTS LIST ELECTRICAL / BATTERY GROUP Manual Update #604486 Tennant 1500 (02–02) Home Find... Go To..
  • Page 31 CONNECTOR, 50A WO/CONTACTS 611221 BOOT, BATTERY CABLE BLK 605823 O RING .926ID X .996OD 611222 BOOT, BATTERY CABLE RED 140018 WASHER, #10 INT 45962 COVER, BATTERY TERMINAL 130698 BUSHING, SNAP D RECOMMENDED STOCK ITEMS Tennant 1500 (02–02) Home Find... Go To..

  • Page 32: Options

    TOOL, CREVICE BLACK 160106 HOSE, SOLUTION DFITTING, TIP #5002 V–JET 200975 150100 FITTING, 1/4MX1/8F BUSHING DVALVE, TOGGLE W/NUT 210014 150913 FITTING, 1/4F QD FML COUPLER ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS Tennant 1500 (02–02) Home Find... Go To..

  • Page 33: Upholstery Tool Group

    FITTING DKIT, VALVE ASM. 190631 200842 FILTER DVALVE, LP 210226 200841 SCREEN, FILTER DNOZZLE 200991 150606 FITTING, 1/4MX1/4M DCOUPLER 200838 SCREW 150913 200840 TRIGGER ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS Tennant 1500 (02–02) Home Find... Go To..

  • Page 34: 330Mm (13 In) Wand Group

    OPTIONS 330mm (13 in) LOW PRESSURE WAND GROUP Tennant 1500 (02–02) Home Find... Go To..
  • Page 35 NUT, 1/4 PUSH BLK 200964 DCAP, SPRAY BODY 150403 FITTING, 1/4MX1/4F 45 STR 200994 DFITTING, 1/4F QD CPLR SER 60 150913 150615 FITTING, 1/4MX7/8 CLSNIP ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS Tennant 1500 (02–02) Home Find... Go To..

  • Page 36: 406Mm (16 In) Floor Tool

    OPTIONS 406mm (16 in) LOW PRESSURE FLOOR TOOL Tennant 1500 (02–02) Home Find... Go To..
  • Page 37 NUT, 1/4 PUSH BLK 200996 DFITTING, TIP 11003 T–JET 150403 FITTING, 1/4MX1/4F 45 STR 200964 DCOUPLER, SER. 60 DCAP, SPRAY BODY 150913 200994 150615 NIPPLE, CLOSE 1/4 ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS Tennant 1500 (02–02) Home Find... Go To..

  • Page 38: Solution And Vacuum Hoses Group

    DCONNECTOR, VAC HOSE 1–1/2” 160186 HOSE, SOLUTION 7.6M (25’) 160451 160187 HOSE, SOLUTION 15.2M (50’) DCOUPLER, QUICK SER. 60 150913 150933 PLUG, QUICK COUPLER 150615 NIPPLE ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS Tennant 1500 (02–02) Home Find... Go To..

This manual is also suitable for:

607653-pac

Table of Contents
