Tennant 607853 Operator And Parts Manual
  1. Manuals
  2. Brands
  3. Tennant Manuals
  4. Floor Machine
  5. 607853
  6. Operator and parts manual
Tennant 607853 Operator And Parts Manual

Tennant 607853 Operator And Parts Manual

Self-contained carpet extractor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model No.:
607853
TENNANT COMPANY
Commercial Products
12875 RANSOM STREET
HOLLAND MI 49424 U.S.A.
FAX: 1–800–678–4240
CUSTOMER SERVICE: 1–800-982–7658
1220
Self-Contained Carpet Extractor
Operator and Parts Manual
607860
Rev. 00 (11-99)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 607853 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tennant 607853

Summary of Contents for Tennant 607853

  • Page 1 1220 Self-Contained Carpet Extractor Model No.: Operator and Parts Manual 607853 TENNANT COMPANY Commercial Products 12875 RANSOM STREET HOLLAND MI 49424 U.S.A. 607860 FAX: 1–800–678–4240 Rev. 00 (11-99) CUSTOMER SERVICE: 1–800-982–7658...

  • Page 2: Table Of Contents

    Parts and supplies may be ordered by phone or mail Serial No.- from any authorized parts and service center, distributor or from any of the manufacturer’s E1999 Tennant Company Printed in U.S.A. subsidiaries. This machine will provide excellent service. However, the best results will be obtained at minimum costs if: The machine is operated with reasonable care.

  • Page 3: Safety Precautions

    – Do not stretch cord. – Do not handle plug with wet hands. – Keep cord away from heated surfaces. – Report machine damage or faulty operation immediately. – Follow mixing and handling instructions on chemical containers. Tennant 1220 (11–99)

  • Page 4: Machine Setup And Operation

    9. Recovery tank will fill with dirty water during cleaning. Watch for foam buildup. If foam does appear, shut off machine. Remove recovery dome and pour a recommended defoamer solution into the recovery tank (Figure 4) . FIG. 2 Tennant 1220 (11–99)

  • Page 5: Maintenance

    Do not pick NOTE: Be careful not to overwet upholstery. NOTE: When cleaning upholstery, always check cleaning instructions sewn in furniture by manufacturer. 5. When finished cleaning, turn off machine and drain recovery tank. Tennant 1220 (11–99)

  • Page 6: Storing Machine

    Next day, spray out remaining solution and flush system with 11L (3 gal) of clean water. Tennant 1220 (11–99)

  • Page 7: Trouble Shooting

    Solution tank low or empty. Refill solution tank. Faulty solution pump. Contact Service Center. Plugged solution tank filter. Clean filter. Drain valve leaks. Drain valve gaskets worn. Replace gaskets. Lint or dirt in drain valve. Clean valve. Tennant 1220 (05–99)

  • Page 8: Specifications

    SOLUTION PUMP 120V, 6.9bar (100psi), 1A VACUUM MOTOR 120V, 1.66 hp, 10.3A, 1236W, 3 stage SEALED WATER LIFT 2972 mm (117 in) TOTAL POWER CONSUMPTION 120V, 12.7A, 1524W DECIBEL RATING AT OPERATOR’S EAR, >70dB(A) INDOORS ON CARPET Tennant 1220 (07–99)

  • Page 9: Electrical Diagram

    ELECTRICAL DIAGRAMS 120V PUSH BUTTON SWITCH MASTER SWITCH CONDUIT POWER CORD SOLENOID CORD 18/3 VACUUM (Chassis to MOTOR Brush Housing) SOLUTION PUMP GRN/YLW BRUSH MOTOR Tennant Roadrunnert 1220 (07–99)

  • Page 10: Parts List

    PARTS LIST TANK GROUP Tennant 1220 (07–99)
  • Page 11 GASKET, RECOVERY DOME 160421 HOSE, VAC. 1 1/2” X 19–1/8 W/ CUFFS DECAL LIST (not shown) PART # DESCRIPTION QTY. 608136 DECAL, TENNANT LOGO 608158 DECAL, 1220 120399 DECAL, DO NOT ALLOW FOAM 120617 DECAL, HEIGHT ADJUSTMENT 602505 DECAL, INSTRUCTION 120906 DECAL, IMPORTANT –...
  • Page 12 PARTS LIST CHASSIS GROUP Tennant 1220 (07–99)
  • Page 13 140554 SCREW, HEX 1/4–20 X 3/4 607415 HOSE, 3/8” X 4” 140016 WASHER, LOCK 1/4” 606163 HOSE, 3/8” X 22” 140554 SCREW, HEX 1/4–20 X 3/4 140310 CLAMP, HOSE 150412 ELBOW, 90_ NYL 3/8 MPT X 3/8 Tennant 1220 (07–99)
  • Page 14 PARTS LIST BRUSH GROUP Tennant 1220 (07–99)
  • Page 15 SOLUTION PUMP BREAKDOWN PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 190129 PRESSURE SWITCH 190130 LOWER PUMP HOUSING KIT 190128 UPPER PUMP HOUSING KIT 190171 KIT, PUMP VALVE (VITON) 190131 SERVICE KIT 180103 SOLUTION PUMP 100 PSI (COMP.) Tennant 1220 (07–99)

  • Page 16: Options

    200994 CAP, SPRAY BODY CREVICE TOOL PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 200517 TOOL, CREVICE (COMPLETE) 160106 HOSE, ASM. 200436.BK TOOL 150100 FITTING, 1/4MX1/8F 200975 NOZZLE 150913 COUPLER 210014 VALVE, TOGGLE 210020 CAP, VALVE POSITIONER Tennant 1220 (06–99)

  • Page 17: Solution And Vacuum Hoses

    PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 160185 HOSE, SOLUTION 15’ 160400 HOSE, VACUUM 15’ 150913 COUPLER, QUICK 160430 CUFF, HOSE 1–1/2” 150933 PLUG, QUICK COUPLER 160451 CONNECTOR, VAC HOSE 150615 NIPPLE ASSEMBLY INCLUDED IN ASSEMBLY Tennant 1220 (06–99)
  • Page 18 NUT, PUSH (NOT SHOWN) 200996 SCREEN, SPRAY BODY 210150 VALVE, FLOW CONTROL 200964 190603 KIT, VALVE PIN & SPRING 200994 CAP, SPRAY BODY CAP, HEX, VALVE ASSEMBLY 150403 ELBOW, 1/4–45 INCLUDED IN ASSEMBLY 150615 NIPPLE, CLOSE 1/4 Tennant 1220 (06–99)
