2.3.1 PL600/ PL1000 Electromechanical Gearmotor
PL600/PL1000 consists of an electronic control unit and
connector for the optional radio control receiver. The
gearmotor could be released manually by special
release keys when there is power failure. Besides, it has
a back-up battery (optional) which can be used during
the power failure as well.

2.3.2 Release Keys

The two keys enable the gearmotor to be released when
there is power failure.
2.3.2.1 Release Gearmotor
4
INSTRUCTIONS PL600/PL1000
1) Slide the lock cover disc.
3) Pull the release handle.
Figure 3
A
Fuse knob
B
Terminals for devices
E
RF leaning button
D
Digital led display
C
Function setting buttons
F
Back-up batteries
(optional)
Figure 4
2) Insert and turn the key clockwise.
4) Move the leaf manually.
