Table Of Contents - PowerTech KIT PL600 Instructions Manual

1. Warnings
2. Product Description and Applications
2.1 Applications...........................................3
2.2 Description of The Automation...............3
2.3 Description of Devices............................3
2.3.1 PL600/PL1000 Electromechanical
Gearmotor..............................................4
2.3.2 Release Keys.........................................4
2.3.2.1 Release Gearmotors...........................4
2.3.3 PH-1 Photocells......................................5
2.3.4 PR-1 Radio Transmitter..........................5
2.3.5 PF-1 Flashing Light................................5
2.3.6 PKS-1 Key selector................................5
2.3.7 PPB-1 Push Button...............................5
3. Installation
3.1 Notes of Motors in Operation.................6
3.1.1 Tools in Installing....................................6
3.1.2 Motors, Components and Its Installation
in Illustration...........................................6
3.2 Power Connection..................................6
3.2.1 Notes for Power Connection..................6
3.3 Preparation for Motor Installation...........7
3.3.1 Installation of The Gearmotor.................9
3.3.1.1 Installing on Gates without Rack............9
3.3.1.2 Installing on Gates with Rack..............11
3.3.2 PH-1 Photocells....................................12
3.3.3 PF-1 Flashing Light..............................13
3.3.4 PKS-1 Key selector..............................14
3.3.5 PPB-1 Push Button..............................15
3.4 Power Supply Connections..................15
4. Final Checks and Start Up
4.1 Initial Checks........................................16
4.1.1 Design of PL600/PL1000 control unit...16
4.1.2 Recognition of LED Indication.............17
4.1.3 Checking the Gate Movements...........17
4.2 Programmable Functions List..............17
4.2.1 Programmable Functions of
LED Display..........................................19
4.2.2 Operations for Function Settings.........20
Index
2
5. Testing
3
6. Maintenance and Disposal
6.1 Maintenance.........................................21
6.2 Disposal................................................21
7. Additional Information
7.1 Adding or Removing Device.................21
8. Technical Characteristics
8.1 PL600/PL1000......................................21
8.2 PH-1 Photocells....................................21
8.3 PR-1 Transmitter...................................22
8.4 PF-1 Flashing Light...............................22
8.5 PKS-1 Key Selector..............................22
8.6 PRB-1 Push Button..............................22
CE Declaration of Conformity
6
16
INSTRUCTIONS PL600/PL1000
20
21
21
21
23
