  • Page 1 TCS 720/20 Art. 8868 Operation Instructions Návod na obsluhu Telescopic Pruner Teleskopický odvetvovač Betriebsanleitung Οδηγίες χρήσης Teleskop-Hochentaster Τηλεσκοπικό αλυσοπρίονο Mode d’emploi Инструкция по эксплуатации Élagueuse sur perche Высоторез телескопический Gebruiksaanwijzing Navodilo za uporabo Telescopische stokzaag Teleskopski obrezovalnik za veje Bruksanvisning Teleskopkvistsåg...

  • Page 2: Table Of Contents

    Children should be supervised to ensure that they do not play with the unit. Intended use: The GARDENA Telescopic Pruner is used to delimb trees, hedges, shrub and bushes with limbs of up to 12 cm in diameter in private domestic gardens or allotments.
  • Page 3 There is an increased risk of electric shock if Disconnect the mains cable if the your body is earthed or grounded. cable becomes damaged or cut. c) Do not expose power tools to rain or wet conditions. Water entering a power tool will Risk of fatal injury due to electric increase the risk of electric shock.
  • Page 4 ensure these are connected and properly ing. Make sure the switch is off when used. Use of dust collection can reduce dust- clearing jammed material. related hazards. A moment of inattention while operating the pruner may result in serious personal injury. 4) Power tool use and care •...
  • Page 5 – before clearing a blockage; plug is connected, disconnect the mains at once. – before checking, cleaning or working on the Contact GARDENA Service to check the unit. appliance; Warning! This unit makes an electromagnetic field – if you hit an object. Do not use your unit until you while it operates.

  • Page 6: Assembly

    2. ASSEMBLY The Pruner, chain, bar, protective cover complete with Allen key and the operation instructions are included in the scope of delivery. DANGER! Risk of physical injury! Cut injury when the unit starts accidentally. v Before you assemble the unit, make sure that the mains cable is disconnected and the protective cover is slid over the bar...

  • Page 7: Operation

    Check whether sufficient quantities of chain oil are delivered prior to each use. We recommend to use Art. 6006 GARDENA Oil or an equivalent mineral chain oil from a specialist supplier. 1. Unscrew the lid of the oil tank 2.
  • Page 8 Work positions: The unit can be operated in 2 work positions (above / below). To ensure a tidy cutting edge, thick branches should be cut in 2 steps (Illustrations similar). Above Above Below: ß (thick branches): (thick branches): Cut off from above 1.

  • Page 9: Maintenance

    When the cutting performance reduces significantly (dull chain), the chain must be replaced. The Allen key for the screws is situated inside the protective cover . Only the original GARDENA Spare Chain and Bar Art. 4048 or Spare Chain Art. 4049 can be used.
  • Page 10 1. Open the lock and remove the lid ß 2. Remove the bar along with the chain and release the used chain from the bar. 3. Clean the motor unit , the bar and the lid . In doing so, pay particular attention to the rubber washers in the casing and the lid.

  • Page 11: Storage

    Hedge is not cleanly cut Chain dull or damaged. v Replace chain. For any other malfunctions please contact the GARDENA service department. Repairs must only be done by GARDENA service departments or specialist dealers approved by GARDENA. 8. TECHNICAL DATA Telescopic pruner TCS 720/20 (Art.

  • Page 12: Accessories

    Please contact the address on the back page. Guarantee: GARDENA guarantees this unit for 2 years (from date of purchase). This guarantee includes all important defects of the unit that can be proved to be material or manufacturing faults. Under warranty we...
  • Page 13 We expressly point out that, in accordance with the product liability law, we are not liable for any damage caused by our units if it is because of improper repair or if parts replaced are not original GARDENA parts or approved parts, and, if the repairs were not done by a GARDENA Service Centre or an approved specialist.
  • Page 14 škodo ki bi nastala zaradi nepravilnega popravila izdelka ali pri napačni zamenjavi delov, ki niso originalni deli GARDENA ali pri uporabi z naše strani potrjenih delov, ki pa niso bili vgrajeni v servisu GARDENA ali v naši pooblaščeni servisni službi.
  • Page 15 Toute modification portée sur ce produit sans l’accord express de Pri zmene zariadenia, ktorá nebola odsúhlasená výrobcom stráca toto vyhlásenie GARDENA supprime la validité de ce certificat. platnosť. EU-overeenstemmingsverklaring Δήλωση Συμμόρφωσης προς τις Οδηγίες της ΕΕ Ondergetekende Husqvarna AB, 561 82 Huskvarna, Sweden bevestigt, dat de Η...
  • Page 16 Numéro du certificat : Označení přístrojů: Teleskopická vyvětvovací pilka Označenie zariadenia: Teleskopický odvetvovač Deposited Documentation: Ονομασία της συσκευής: Τηλεσκοπικό αλυσοπρίονο GARDENA Technical Documentation, Opis naprave: Teleskopski obrezovalnik za veje M. Kugler, Hans-Lorenser-Straße 40, Oznaka uređaja: Teleskopska pila 89079 Ulm Descrierea articolelor: Foarfeca telescopică...
  • Page 17 8868-20.960.02/0915 Temuco, Chile France Consumer Outdoor Products Autoput za Novi Sad bb © GARDENA © GARDENA http : // www.gardena.com / fr Avda. Valparaíso # 01466 Ateities pl. 77C 11273 Belgrade Manufacturing GmbH Manufacturing GmbH D-89070 Ulm Phone: (+56) 45 222 126 N°...
