Page 1: Operation Manual
CPLUS-VHHE 4K2K HDMI to HDMI Enhancer Operation Manual Operation Manual... - Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 4: Safety Precautions
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 5: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Front and Rear Panels .....3 6.2 Top Panel ..........4 6.3 Side Panel .........5 7. -
Page 6: Introduction
1. INTRODUCTION The 4K2K HDMI to HDMI Enhancer is a handy device for your HDMI signal extension. With bandwidth, HDCP analyzing, EDID and YUV420 selections this device allows you with fast and clear viewing on the HDMI signal status. Further, this device allows user to upload EDID for selection which create alternative EDID selection for specific usage. -
Page 7: Features
5. FEATURES • HDMI with 4K2K 6G supported, HDCP 2.2/1.4 and DVI compliant • Supports video source and output display signal analysis up to 6G 4K2K • Supports HDMI 2.0 • Supports HDCP v1.4 & v2.2 a • Supports EDID selection from internal, external and user’s EDID to be insert •... -
Page 8: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front and Rear Panels Front Rear SERVICE HDMI IN HDMI OUT HDMI IN: Connect with HDMI source equipment such as Blue-ray/ PS4 player with HDMI cable. DC 5V: Plug the 5V DC power supply into the unit and connect the adaptor to an AC outlet. -
Page 9: Top Panel
6.2 Top Panel SYNC HDCP EDID USER LINK PWR LED: This LED will illuminate when the device is connected with power supply from the AC outlet. SYNC LEDs: These LEDs will illuminate according to both HDMI input and output signal’s current bandwidth. HDCP LEDs: These LEDs will illuminate according to both HDMI input and output’s HDCP encrypted signal. -
Page 10: Side Panel
6.3 Side Panel YUV420 EDID ACTIVE SRC YUV420: Press this button to allows HDMI input 6G signal to be subsampling to YUV420 from YUV444. EDID: Press this button to select EDID of INTernal/EXTernal or USER where internal EDID is 1080p at 2CH, external EDID is depending on the connected HDMI output display and USER is for upload EDID. -
Page 11: Connection Diagram
7. CONNECTION DIAGRAM DVD or Blu-ray Player HDMI Input (Up to 5m@4K) Power Supply HDMI IN SERVICE HDMI OUT HDMI Output (Up to 5m@4K) UHDTV... -
Page 12: Specifications
8. SPECIFICATIONS Video Bandwidth 600 MHz/6 Gbps Input Ports 1×HDMI Output Ports 1×HDMI HDMI Resolutions VGA~WUXGA (RB), 408i~1080p@24/50/60, 4K@24/25/30, 4K@50/60 (YUV444) HDMI Cable Distance 10 m@1080p/8-bit, 10 m@1080p/12-bit, 5 m@4K Power Supply 5 V/2.6 A DC (US/EU standards, CE/FCC/UL certified) ESD Protection Human body model: ±8 kV (air-gap discharge) -
Page 13: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM Consumer Electronics Control Digital Visual Interface EDID Extended Display Identification Data HDCP High-bandwidth Digital Content Protection HDMI High-Definition Multimedia Interface Universal Serial Bus Video Graphics Array WUXGA (RB) Widescreen Ultra Extended Graphics Array (Reduce Blanking) - Page 16 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw...
