Binks 95AR Service Manual

SERVICE MANUAL
BINKS MODEL 95AR
AND 95ARV AUTOMATIC
CONVENTIONAL
AIR SPRAY GUN
(95ARV FOR CERAMIC COATINGS)
95AR 6467-XXXX-X
95ARV 6489-XXXX-X
MODEL 95AR AND 95ARV AUTOMATIC AIR
SPRAY GUNS
Ideal for coating test laboratories and where repeated fluid
flow adjustments are required. The 95AR Automatic Spray
Gun is a conventional style air spray gun. It incorporates all
stainless steel fluid inlet, fluid nozzle, and fluid needle;
95ARV incorporates stainless steel fluid inlet, fluid nozzle
with T.C. insert and fluid needle with T.C. tip for spraying a
wide variety of conventional and waterborne coatings. It
is also pneumatically activated for application with recipro-
cating, rotary, spindle machines, and in stationary gun set-
ups. Exceptionally rugged in construction, the Binks
77-2655-R4.1 (1/2015)
AIR SPRAY GUN WITH STAINLESS STEEL FLUID INLET
STANDARD SET-UPS AVAILABLE (See page 9).
OPTIONAL SET-UPS PLEASE ORDER SEPARATELY
(See pages 8 and 9).
Models 95AR and 95ARV automatic guns are built to stand
up under hard, continuous use. However, like any other
fine precision instruments, their most efficient operation
depends on a knowledge of their construction, operation,
and maintenance.
Properly handled and cared for, these guns will produce
beautiful, uniform finishing results long after other spray
guns have worn out.
CAUTION
!
Before removing any components from spray gun, shut
off air and material pressure.
1 / 16
