PART LIST—Model No. PFEVEX49831
Key No. Qty.
Description
1
1
Frame
2
1
Upright
3
1
Left Handlebar
4
1
Console
5
1
Right Handlebar
6
1
Handlebar Bracket
7
1
Seat Bracket
8
1
Seat Post
9
1
Seat
10
1
Seat Knob
11
1
Seat Carriage
12
2
Small Frame Bushing
13
1
Front Stabiliser Cover
14
1
Left Stabiliser Endcap
15
1
Front Stabiliser
16
1
Rear Stabiliser
17
2
Wheel
18
1
Right Pedal Strap
19
2
Levelling Foot
20
2
Adjustment Knob
21
1
Right Pedal
22
1
Left Pedal
23
1
Right Crank Arm
24
1
Left Crank Arm
25
1
Left Pedal Strap
26
1
Left Side Shield
27
1
Right Side Shield
28
1
Snap Ring
29
1
Pulley
30
1
Magnet
31
1
Bottle Holder
32
1
Flywheel Washer
33
2
Crank Bearing
34
1
Flywheel
35
1
"C" Magnet
36
1
Resistance Cable Assembly
37
1
Spring
38
1
Resistance Motor
39
1
Idler Assembly
40
4
M8 x 33mm Button Screw
41
2
M4 x 12mm Screw
42
1
Upper Wire Harness
Note: "#" indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of this manual for information about ordering replacement parts.
R1103A
Key No. Qty.
Description
43
1
Lower Wire Harness
44
2
Bushing Bracket
45
1
Clamp
46
1
Reed Switch/Wire
47
1
Drive Belt
48
1
Flywheel Cover
49
3
M8 Nylon Locknut
50
2
Flange Screw
51
4
M6 x 13mm Button Screw
52
2
M8 x 39mm Button Bolt
53
1
Right Belt Cover
54
2
M8 x 52mm Button Screw
55
1
Left Belt Cover
56
2
M4 x 50mm Screw
57
18
M4 x 16mm Screw
58
1
Small Pulley
59
4
M8 x 22mm Button Screw
60
8
M4 x 8mm Screw
61
1
M6 x 8mm Button Screw
62
4
M4 x 10mm Screw
63
2
M6 Nylon Locknut
64
1
Stop Bracket
65
1
M8 x 35mm Screw
66
2
M6 Washer
67
3
M4 x 38mm Screw
68
2
M8 x 70mm Button Screw
69
2
Large Frame Bushing
70
4
M4 x 12mm Flange Screw
71
1
M6 x 8mm Zinc Button Screw
72
2
Small Snap Ring
73
2
Handlebar Collar
74
1
8.5mm Spacer
75
1
M8 x 14mm Button Screw
76
1
Right Stabiliser Endcap
77
1
Steel Washer
78
2
Crank Cover
79
1
Idler Bracket
80
2
Small Pulley Washer
81
6
M8 Washer
82
1
7.5mm Spacer
#
2
Hex Key
#
1
User's Manual
22
IMPORTANT PRECAUTIONS
WARNING:
To reduce the risk of serious injury, read the following important precau-
tions before using the exercise cycle.
1. Read all instructions in this manual before
using the exercise cycle.
2. It is the responsibility of the owner to ensure
that all users of the exercise cycle are ade-
quately informed of all precautions. Use the
exercise cycle only as described in this manual.
3. Use the exercise cycle indoors on a level sur-
face. Keep the exercise cycle away from
moisture and dust. Place a mat under the
exercise cycle to protect the floor.
4. Inspect and properly tighten all parts regular-
ly. Replace any worn parts immediately.
5. Keep children under the age of 12 and pets
away from the exercise cycle at all times.
6. Wear appropriate clothing when exercising;
do not wear loose clothing that could become
caught on the exercise cycle. Always wear
athletic shoes for foot protection.
7. The exercise cycle should not be used by
persons weighing more than 115 kg (250 lbs.).
WARNING:
Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
8. Always keep your back straight when using
the exercise cycle; do not arch your back.
9. If you feel pain or dizziness while exercising,
stop immediately and cool down.
10. The exercise cycle does not have a free
wheel; the pedals will continue to move until
the flywheel stops.
11. The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
12. The exercise cycle is intended for home use
only. Do not use the exercise cycle in
a commercial, rental, or institutional setting.
13. A warning decal has been placed on the exer-
cise cycle in the location shown on page 4. If
the decal is missing, or if it is not legible,
please call our Customer Service Department
at 0345-089009 to order a free replacement
decal. Apply the decal in the location shown.
