To reset the displays, press the On/Reset button.
Note: The con-
sole can show
speed and dis-
tance in either
miles or kilome-
tres. The letters
MPH or KM/H will appear in the lower section of
the large display to show which system of mea-
surement is selected. To change the system of
measurement, hold down the On/Reset button for
about six seconds. Note: When the button is held
down, the fan will turn on for a moment. When the
batteries are replaced, it may be necessary to res-
elect the desired system of measurement.
Measure your heart rate if desired.
5
If there are
thin sheets of
Metal
plastic on the
Contacts
metal contacts
on the hand-
grips, peel off
the plastic. To
use the hand-
grip pulse sen-
sor, hold the handgrips with your palms resting
against the metal contacts. Avoid moving your
hands. When your pulse is detected, the heart-
shaped indicator in the large display will flash
each time your heart beats. After a moment, two
dashes (– –) will appear and then your heart rate
will be shown.
For the most accurate heart rate reading, continue
to hold the handgrips for about 30 seconds. Note:
When you first hold the handgrips, the large dis-
play will show your heart rate continuously for 30
seconds. The display will then show your heart
rate along with other feedback modes.
Turn on the fan if desired.
6
To turn on the
fan at low speed,
press the fan
button. To turn
Thumb
on the fan at
Wheel
high speed,
Fan
press the fan
Button
button a second
time. To turn off
the fan, press the fan button a third time. Note: If
the fan is turned on and the pedals are not
moved for about half a minute, the fan will turn
off to conserve the batteries.
Rotate the thumb wheel on the right side of the
console to pivot the fan to the desired angle.
When you are finished exercising, the console
7
will automatically turn off.
If the pedals are not moved for a few seconds,
the displays will pause and the time will flash in
the large display.
If the pedals are not moved and the console but-
tons are not pressed for a few minutes, the con-
sole will turn off to conserve the batteries.
12
HOW TO USE A SMART PROGRAM
Each Smart program will automatically change the
resistance of the pedals and prompt you to increase or
decrease your pace as it guides you through an effec-
tive workout. Programs 3 and 4 are weight loss pro-
grams, program 5 is an aerobic program, and program
6 is a high-performance interval-training program.
Follow the steps below to use a Smart program.
Turn on the console.
1
See step 1 on page 11.
Select one of the Smart programs.
2
Each time the console is
turned on, the manual
mode will be selected. To
select a Smart program,
press the Program button
repeatedly until the num-
ber 3, 4, 5, or 6 appears in
the small display.
Begin pedalling to start the program.
3
To start the program, simply begin pedalling.
Each Smart program consists of 20 or 30 one-
minute periods. One resistance level and one tar-
get pace are programmed for each period. (The
same resistance level and/or target pace may be
programmed for two or more consecutive periods.)
At the end of each period of the program, the
resistance of the pedals will automatically change
if a different resistance level is programmed for
the next period. Note: If the resistance level is too
high or too low, you can change it by pressing the
+ and – buttons below the large display. However,
when the current period is completed, the resis-
tance of the pedals will automatically change if a
different resistance level is programmed for the
next period.
The target pace
for the current
Indicator
period will be
Bar
shown by the
arrows in the
Arrows
small display. To
pedal at the target
pace, simply
increase or decrease your pace until one seg-
ment of the indicator bar appears at the tip of
each arrow (see the drawing above). At the end
of each period, the number of arrows will change
if a different target pace is programmed for the
next period. When the number of arrows
changes, change your pace until there is again
one segment of the indicator bar at the tip of each
arrow. Important: The target pace is intended
only to provide a goal. Your actual pace may
be slower than the target pace, especially dur-
ing the first few months of your exercise pro-
gram. Make sure to pedal at a pace that is
comfortable for you.
During the program, the centre of the large dis-
play will show the time remaining in the program.
If you stop pedalling for a few seconds, the dis-
plays will pause and the time will flash. If you
continue pedalling after the program is complet-
ed, the displays will continue to show exercise
feedback.
Follow your progress with the large display.
4
See step 4 on page 11.
Measure your heart rate if desired.
5
See step 5 on page 12.
Turn on the fan if desired.
6
See step 6 on page 12.
When you are finished exercising, the console
7
will automatically turn off.
See step 7 on page 12.
13
