HearthStone Champlain 8302 Owner's Manual

Gas-fired direct vent heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

WARNING: FOLLOW THE INFORMATION IN
THESE INSTRUCTIONS EXACTLY, IF NOT, A FIRE
OR EXPLOSION MAY RESULT CAUSING
PROPERTY DAMAGE, PERSONAL INJURY OR
LOSS OF LIFE.
WARNING: DO NOT STORE OR USE GASOLINE
OR ANY OTHER FLAMMABLE VAPORS AND
LIQUIDS NEAR THIS OR ANY OTHER GAS
APPLIANCE.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch electrical switches; do not use the phone
in your building.
Immediately call your gas supplier from a phone
outside the structure. Follow your gas supplier's
instructions.
If you cannot reach your gas supplier, call the fire
department or 911.
A qualified installer, service agency, or gas supplier must
perform installation and service of this appliance. In the
Commonwealth of Massachusetts, all installation of gas
lines and gas fittings must be performed by a licensed gas
fitter or licensed plumber.
Champlain
Gas-Fired Direct Vent Heater
Owner's Manual
Operation & Installation Guide
Read This Owner's Manual
Operate and Maintain This Gas Heater
According to This Instruction Manual.
Save These Instructions!
AVERTISSEMENT:
SUIVRE
LES
INSTRUCTIONS
CETTE NOTICE POUR RÉDUIRE AU MINIMUM LE
RISQUE D'INCENDIE OU POUR ÉVITER TOUT
DOMMAGE MATÉERIEL, TOUTE BLESSURE OU
LA MORT.
AVERTISSEMENT: NE PAS ENTRESPOSER NI
UTILISER D'ESSENCE NI D'AUTRE VAPERURS
OU
LIQUIDES
INFLAMMABLES
VOISINAGE DE CET APPRAREIL OU DE TOUT
AUTRE APPAREIL.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
Ne pas tenter d'allumer d'appareil.
Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones se trouvant dans le batiment où vous
vous trouvez.
Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installation et service doit être exécuté par un qualifié
installer, agence de service ou le fournisseur de gaz.
(Model 8302)
ASSUREZ-VOUS
DE
BIEN
DONNÉ
DANS
DANS
Champlain Model 8302
Manual: 6400-40421
R: 06-15-15
LE
