Multi-Channel (Home
Theater) Installation

Speaker Placement

5.1 System
A 5.1 system consists of a front left, front right, surround left, suround right, center channel,
and subwoofer channel. An S1.8Twd generally functions as mains, but may also be used
as surrounds. In a home theater configuration, the main left and right channels should be
placed a few feet from the front wall as close to listening height as possible. The surround
channels should be placed to either side of the listening area or behind the listening area at
listening height.
6.1 System
A 6.1 system has the same basic channels as a 5.1 system, with the addition of a rear center
channel placed directly behind the listening area.
7.1 System
A 7.1 system has the same basic channels as a 5.1 system, with the addition of a left rear
surround and right rear surround.
A certified installer will finalize the placement of your dARTS speakers in accordance with
the Audyssey MultEQ XT software. For more information, refer to the SX7000d instruction
manual.

Tools and Materials You Will Need

Stud Finder
5/16" hex key or hex driver
Slotted Screwdriver
#2 Square Drive Screwdriver
Speaker cable (fire rated if run inside walls)
Flashlight
Level
