Summary of Contents for Induction Dynamics C2.w

  • Page 1 C2.w 2-Way On-Wall Center Channel...
  • Page 2: Table Of Contents

    Table of Contents Introduction General Information Check Speaker and Parts General Care of Your Loudspeaker and Amplifier Bass and Loudness Contour Controls C2.w Location Speaker Information S4X Crossover Wide Angle Phase Alignment Multi-Channel (Home Theater) Installation Speaker Placement Speaker Wire Tools and Materials You Will Need...
  • Page 3: Introduction

    Because of S4X technology, any of Induction Dynamics’ speakers can be used to build a custom home theater system. Your C2.w can be combined with any of our main and surround speakers, be they in-wall, on-wall, or free-standing.
  • Page 4: General Information

    “boomy”, obscure higher frequencies, and possibly cause damage due to excessive cone excursion. C2.w Location Ideally, the C2.w should be placed behind a perforated video projection screen. For use with a flat-screen or other video monitor, the best placement is usually below the screen. If it is not possible to place the speaker below the screen, placement above the screen is acceptable.
  • Page 5: Speaker Information

    Above: The S4X crossover routes audio signal to their intended drivers at specific frequen- cies (the C2.w utilizes a single crossover at 2500 Hz). Because the S4X produces such a steep crossover slope, Induction Dynamics is able to use the best possible drivers for each frequency range. Subwoofer crossover points are generally selectable through your sub- woofer amplifier. Induction Dynamics recommends a subwoofer crossover point between 50-60 Hz.
  • Page 6: Wide Angle Phase Alignment

    Induction Dynamics® eliminates phase differences with respect to height through our Wide Angle™ phase alignment technology. Because our patented circuitry provides additional variables that can help control phase, Wide Angle finds the one optimization solution that produces a flat frequency response along the vertical axis, when the microphone (or listener’s...
  • Page 7: Multi-Channel (Home Theater) Installation

    A 5.1 system consists of a front left, front right, surround left, suround right, center channel, and subwoofer channel. A C2.w is intended as a center channel. In a home theater configuration, the center channel should be centered between the left and right front channels and as close to listening height as possible, either above or below the screen (preferably below the screen).
  • Page 8: Tools And Materials You Will Need

    Speaker cable (fire rated if run inside walls) Flashlight Level Installing the Easy-Mount Box Onto the Wall 1. The C2.w is shipped pre-assembled with the faceplate attached to the easy-mount box with bolts. In order to install the C2.w onto the wall, you will first need to separate the faceplate from the box. First, remove the grille mounting flanges, using the grille mount- ing flange driver. Note that there may be shims under some of the grille mounting flanges. You will need to save these shims for use when you reinstall the faceplate. Once the grille mounting flanges and shims are removed, use a 5/16” hex key or driver to unscrew the...
  • Page 9: Installing The Faceplate

    6. If you cannot screw into a wall stud, use 4 dry wall anchor bolts that spread out behind the drywall. Select grommets that fit snugly around the bolts you have chosen. Be sure to put a metal washer between the head of the bolt and the grommet. Installing the Faceplate 1. Attach the speaker wire to the terminal block on the back of the faceplate, observing the proper polarity (red to red and black to black).
  • Page 10: C2.W Specifications

    C2.w Specifications 2-way on-wall center channel loudspeaker. Type: Exclusive patented S4X Driver Control Technology. Crossover: 2,500 Hz Crossover Frequencies: Nominal Impedance: 4 Ohms 55-22,000 Hz Frequency Response: 88 dB Sensitivity (2.83 V @ 1M): 85 dB SPL (1 W / 1 M):...
  • Page 11: Warranty

    The warranty is void if the C2.w is serviced or altered by anyone other than Induction Dynamics, Inc. the sole remedy for breach of this warranty shall be repair or replace- ment.
  • Page 12: Contacts

    Contacts Manufacturer Information If you have any questions, contact Induction Dynamics by phone at 855-663-5600, 8:00 a.m.- 5:00 p.m. CST, fax at 913-663-3200, email at sales@inductiondynamics.com, or write to: Induction Dynamics Customer Service Department 8005 W. 110th St., Suite 208...
  • Page 13 To simplify your record keeping, please glue, staple, or tape your receipt to this page. Audio Perfection Realized ™...
  • Page 14 8005 W. 110th Street, Suite 208 Overland Park, KS 66210 Tel: (855) 663-5600 Fax: (913) 663-3200 www.inductiondynamics.com © Induction Dynamics®, August 2013 ™...
