Summary of Contents for Induction Dynamics S1.8Swd
- Page 2 *Page Intentionally Left Blank*...
-
Page 3: Table Of Contents
Speaker Wire Speaker Information S4X Crossover Wide Angle Phase Alignment Multi-Channel (Home Theater) Installation Speaker Placement Tools and Materials You Will Need Installing the Easy-Mount Box Onto the Wall Installing the Faceplate Connecting to an Amplifier S1.8Swd Specifications Warranty Contacts... -
Page 4: Introduction
S4X technology, any of Induction Dynamics’ speakers can be used to build a custom home theater system. Your S1.8Swd can be combined with any of our center and surround speakers, be they in-wall, on-wall, or free-standing. For more details on S4X technology, see the “speaker information”... -
Page 5: General Information
The S1.8Swd mounts on drywall, preferably over studs, and should be placed in accordance with the type of system you are installing as discussed on page 7. The S1.8Swd was designed in such a way that the tweeter will be at ear level when the audience is sitting. The tweeter reproduces high-frequency audio, which our ears perceive as most directional, so we are most attuned to their level and placement. -
Page 6: Speaker Wire
Use approved wire designed for in-wall or exposed use, as appropriate for your installation. For the S1.8Swd, we recommend using high-quality speaker wire that is 14 gauge or lower, with easily visible polarity coding to make your connections. The following chart identifies minimum gauge requirements for various lengths. -
Page 7: Speaker Information
Speaker Information S4X™ Crossover The heart of Induction Dynamics is found in the S4X™ Super Fourth-Order Crossover. The patented S4X inductively couples crossover coils and optimizes each driver’s performance, individually and interactively with the other drivers. This greatly increases control over driver range, frequency response, phase and impedance. -
Page 8: Wide Angle Phase Alignment
Induction Dynamics reduces phase differences both horizontally and vertically through our Wide Angle® Phase Alignment technology. Because our patented circuitry provides additional variables that can help control phase, Wide Angle finds the one optimized solution that produces a flat frequency response along both the horiztonal and vertical axis. -
Page 9: Multi-Channel (Home Theater) Installation
A 5.1 system consists of a front left, front right, surround left, suround right, center channel, and subwoofer channel. An S1.8Swd functions as a rear surround speaker. In a home theater configuration, the main left and right channels should be placed a few feet from the front wall as close to listening height as possible. -
Page 10: Installing The Easy-Mount Box Onto The Wall
1. The S1.8Swd is shipped pre-assembled with the faceplate attached to the easy-mount box with bolts. In order to install the S1.8Swd onto the wall, you will first need to separate the faceplate from the box. First, remove the grille mounting flanges, using the grille mount- ing flange driver. -
Page 11: Installing The Faceplate
Installing the Faceplate 1. Attach the speaker wires to the terminal block on the back of the faceplate, observing the proper polarity (red to red and black to black). To make connections, solder or crimp with high pressure the insulated fork terminals provided in your parts packet. Soldering is best. 2. -
Page 12: S1.8Swd Specifications
S1.8Swd Specifications 3-way/dARTS on-wall surround loudspeaker. Type: Crossover: Exclusive patented S4X Driver Control Technology. Crossover Frequencies: 500 Hz and 3,700 Hz Nominal Impedance: 4 Ohms (2.5 minimum) Frequency Response: 50-20,000 Hz 90 dB Sensitivity (2.83 V @ 1M): 87 dB... -
Page 13: Warranty
The warranty is void if the S1.8Swd is serviced or altered by anyone other than Induction Dynamics, Inc. the sole remedy for breach of this warranty shall be repair or replacement. -
Page 14: Contacts
Contacts Manufacturer Information If you have any questions, contact Induction Dynamics by phone at 855-663-5600, 8:00 a.m.- 5:00 p.m. CST, fax at 913-663-3200, email at sales@inductiondynamics.com, or write to: Induction Dynamics Customer Service Department 8005 W. 110th St., Suite 208... - Page 15 To simplify your record keeping, please glue, staple, or tape your receipt to this page.
- Page 16 8005 W. 110th Street, Suite 208 Overland Park, KS 66210 Tel: (855) 663-5600 Fax: (913) 663-3200 www.inductiondynamics.com © Induction Dynamics®, August 2013 ™...
