Summary of Contents for Induction Dynamics S1.8TD
-
Page 2: Table Of Contents
General Care of Your Loudspeaker and Amplifier Bass and Loudness Contour Controls S1.8Td Location Carpet Spikes Speaker Wire Speaker Information S4X Crossover Wide Angle Phase Alignment Multi-Channel (Home Theater) Installation Speaker Placement S1.8Td Speaker Connection S1.8Td Specifications Warranty Contacts Audio Perfection Realized ™... -
Page 3: Introduction
Induction Dynamics’ speakers can be used to build a custom home theater system. Your S1.8Td can be combined with any of our center and surround speakers, be they in-wall, on-wall, or free-standing. For more details on S4X technology, see the “speaker information”... -
Page 4: General Information
“boomy”, obscure higher frequencies, and possibly cause damage. S1.8Td Location S1.8Td speakers are freestanding and were designed in such a way that the tweeter will be at ear level when the audience is sitting. The tweeter reproduces high-frequency audio which our ears perceive as most directional, so we are most attuned to their level and placement. -
Page 5: Carpet Spikes
Carpet spikes are not required with the S1.8Td. However, they have been provided if you would prefer to use them. Should you choose to do so, lay the S1.8Td on its back side, then screw the carpet spikes into the threaded holes under the base of each speaker. -
Page 6: Speaker Information
Speaker Information S4X™ Crossover The heart of Induction Dynamics is found in the S4X™ Super Fourth-Order Crossover. The patented S4X inductively couples crossover coils and optimizes each driver’s performance, individually and interactively with the other drivers. This greatly increases control over driver range, frequency response, phase and impedance. -
Page 7: Wide Angle Phase Alignment
Induction Dynamics reduces phase differences both horizontally and vertically through our Wide Angle® Phase Alignment technology. Because our patented circuitry provides additional variables that can help control phase, Wide Angle finds the one optimized solution that produces a flat frequency response along both the horiztonal and vertical axis. -
Page 8: Multi-Channel (Home Theater) Installation
A 5.1 system consists of a front left, front right, surround left, suround right, center channel, and subwoofer channel. An S1.8Td generally functions as mains, but may also be used as surrounds. In a home theater configuration, the main left and right channels should be placed a few feet from the front wall as close to listening height as possible. -
Page 9: S1.8Td Specifications
S1.8Td Specifications 3-way/dARTS freestanding tower loudspeaker. Type: Crossover: Exclusive patented S4X Driver Control Technology. Crossover Frequencies: 700 Hz and 3,800 Hz Nominal Impedance: 4 Ohms (2.5 minimum) 45-20,000 Hz Frequency Response: 90 dB Sensitivity (2.83 V @ 1M): 87 dB... -
Page 10: Warranty
The warranty is void if the S1.8Td is serviced or altered by anyone other than Induction Dynamics, Inc. the sole remedy for breach of this warranty shall be repair or replacement. -
Page 11: Contacts
Contacts Manufacturer Information If you have any questions, contact Induction Dynamics by phone at 855-663-5600, 8:00 a.m.- 5:00 p.m. CST, fax at 913-663-3200, email at sales@inductiondynamics.com, or write to: Induction Dynamics Customer Service Department 8005 W. 110th St., Suite 208... - Page 12 8005 W. 110th Street, Suite 208 Overland Park, KS 66210 Tel: (855) 663-5600 Fax: (913) 663-3200 www.inductiondynamics.com © Induction Dynamics®, August 2013 ™...
