Multi-Channel (Home
Theater) Installation

Speaker Placement

5.1 System
A 5.1 system consists of a front left, front right, surround left, suround right, center channel,
and subwoofer channel. A C2.w is intended as a center channel. In a home theater
configuration, the center channel should be centered between the left and right front
channels and as close to listening height as possible, either above or below the screen
(preferably below the screen). The surround channels should be placed to either side of the
listening area or behind the listening area at listening height.
6.1 System
A 6.1 system has the same basic channels as a 5.1 system, with the addition of a rear center
channel placed directly behind the listening area.
7.1 System
A 7.1 system has the same basic channels as a 5.1 system, with the addition of a left rear
surround and right rear surround.

Speaker Wire

Use approved wire designed for in-wall or exposed use, as appropriate for your installation.
For the C2.w, we recommend using high-quality speaker wire that is 12 gauge or lower,
with easily visible polarity coding to make your connections. The following chart identifies
minimum gauge requirements for various lengths. See your local dealer or installation
contractor for more information.
