Induction Dynamics C1.8wd Owner's Manual

3-way/darts on-wall center channel loudspeaker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C1.8wd and is the answer not in the manual?

Questions and answers

Related Manuals for Induction Dynamics C1.8wd

Summary of Contents for Induction Dynamics C1.8wd

  • Page 2 *Page Intentionally Left Blank*...

  • Page 3: Table Of Contents

    Table of Contents Introduction General Information Check Speaker and Parts General Care of Your Loudspeaker and Amplifier Bass and Loudness Contour Controls C1.wd Location Speaker Information S4X Crossover Wide Angle Phase Alignment Multi-Channel (Home Theater) Installation Speaker Placement Speaker Wire Tools and Materials You Will Need Installing the Easy-Mount Box Onto the Wall Installing the Faceplate...

  • Page 4: Introduction

    Because of S4X technology, any of Induction Dynamics’ speakers can be used to build a custom home theater system. Your C1.wd can be combined with any of our main and surround speakers, be they in-wall, on-wall, or free-standing.

  • Page 5: General Information

    (like you would use on clothes). Bass and Loudness Contour Controls Do not use bass or loudness contour controls. Induction Dynamics’ subwoofers produce very low frequencies without these controls. Use of these controls will make the bass sound “boomy”, obscure higher frequencies, and possibly cause damage due to excessive cone excursion.

  • Page 6: Speaker Information

    Speaker Information S4X™ Crossover The heart of Induction Dynamics is found in the S4X™ Super Fourth-Order Crossover. The patented S4X inductively couples crossover coils and optimizes each driver’s performance, individually and interactively with the other drivers. This greatly increases control over driver range, frequency response, phase and impedance.

  • Page 7: Wide Angle Phase Alignment

    Induction Dynamics reduces phase differences both horizontally and vertically through our Wide Angle® Phase Alignment technology. Because our patented circuitry provides additional variables that can help control phase, Wide Angle finds the one optimized solution that produces a flat frequency response along both the horiztonal and vertical axis.

  • Page 8: Multi-Channel (Home Theater) Installation

    Multi-Channel (Home Theater) Installation Speaker Placement 5.1 System A 5.1 system consists of a front left, front right, surround left, suround right, center channel, and subwoofer channel. A C1.wd is intended as a center channel. In a home theater configuration, the center channel should be centered between the left and right front channels and as close to listening height as possible, either above or below the screen (preferably below the screen).

  • Page 9: Tools And Materials You Will Need

    Tools and Materials You Will Need Stud Finder 5/16” hex key or hex driver Slotted Screwdriver #2 Square Drive Screwdriver Speaker cable (fire rated if run inside walls) Flashlight Level Installing the Easy-Mount Box Onto the Wall 1. The C1.wd is shipped pre-assembled with the faceplate attached to the easy-mount box with bolts.

  • Page 10: Installing The Faceplate

    6. If you cannot screw into a wall stud, use 4 dry wall anchor bolts that spread out behind the drywall. Select grommets that fit snugly around the bolts you have chosen. Be sure to put a metal washer between the head of the bolt and the grommet. Installing the Faceplate 1.

  • Page 11: C1.Wd Specifications

    C1.8wd Specifications 3-way/dARTS, on-wall, center channel loudspeaker Type: Exclusive patented S4X Driver Control Technology Crossover: 500, 3,700 Hz Crossover Frequencies: 4 Ohms Nominal Impedance: 70-20,000 Hz Frequency Response: 91 dB Sensitivity (2.83 V @ 1M): 88 dB SPL (1 W / 1 M):...

  • Page 12: Warranty

    The warranty is void if the C1.8wd is serviced or altered by anyone other than Induction Dynamics, Inc. the sole remedy for breach of this warranty shall be repair or replacement.

  • Page 13: Contacts

    Contacts Manufacturer Information If you have any questions, contact Induction Dynamics by phone at 855-663-5600, 8:00 a.m.- 5:00 p.m. CST, fax at 913-663-3200, email at sales@inductiondynamics.com, or write to: Induction Dynamics Customer Service Department 8005 W. 110th St., Suite 208...
  • Page 14 *Page Intentionally Left Blank*...
  • Page 15 To simplify your record keeping, please glue, staple, or tape your receipt to this page.
  • Page 16 8005 W. 110th Street, Suite 208 Overland Park, KS 66210 Tel: (855) 663-5600 Fax: (913) 663-3200 www.inductiondynamics.com © Induction Dynamics®, August 2013 ™...
